Behringer Ultracoustic ACX1000 User manual

Version 1.3 June 2006

ULTRACOUSTIC ACX1000

Technical Specifications

ULTRACOUSTIC ACX1000

ACX1000

VPowerful2x60-Wattamplifierspecificallydesignedforacousticinstrumentsandvocals

VDedicatedtubeemulatoraddswarmthandpresencetoinstrumentsandvocals

V2independentchannelswithseparatevolumecontrols,dedicatedEQsandeachtwofeedbackfilters

VInstrumentchannelproduceswarmandtransparentsound for pickup-equipped instrumentsandfeatures

additionalAttackandFXReturncontrolsplus2tunablenotchfiltersforfeedbacksuppression

VMicrophone/Linechannelprovidesmicrophoneinputs withphantom powerforbothdynamicandcondenser

microphones, Enhancer control, FX Return control and 2 tunable notch filters optimized for suppressing

microphonefeedback

VActive,ultra-musical3-band EQ per channel

V24-bitstereo multi-FX processor withhigh-resolution24-bit converters

V23 algorithms for authentic effects such as Reverb, Delay, Rotary Speaker, Chorus, Flanger, Stereo

Panning,Tremoloand various effectscombinationsforinstrument and microphone/line channels

V99 programs stored in 4 presets that can be recalled via footswitch

VParallelTuneroutput for tunerconnection

VAdjustablestereoAuxinput on phone jacks for adding line signals (e.g. CDplayer,drumcomputer,etc.),

with Aux level control and Mute switch

VSeparateinsertoptionforexternaleffectsdevicesavailableforbothchannels as well as master section

VFootswitchFS114foreffectsswitchingincluded

VMIDIeffectsselection via programchangecommands

VMastervolumecontrolwithswitchable Phase correction

VHigh-qualitycomponentsand exceptionally rugged construction ensure long life

VConceivedand designedbyBEHRINGER Germany

ULTRACOUSTIC

2 x 60-Watt, 2-Channel Stereo Acoustic Instrument

Amplifier with Multi-FX Processor

ULTRACOUSTIC ACX1000

POWERSUPPLY

Mains voltage USA/Canada 120 V~, 60 Hz

China/Korea 220 V~, 50 Hz

U.K./Australia 230 V~, 50 Hz

Europe 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

general

export model 120/230 V~, 50 - 60 Hz

Power consumption 42 Watts min./200 Watts max.

Fuse 100 - 120 V~: T 5 A H 250 V

200 - 240 V~: T 2.5 A H 250 V

Mains connection standard IEC receptacle

PHYSICAL

Dimensions

(H x W x D) app. 17" (431.8 mm)

x 23 2/3" (600.65 mm)

x103/5"(270mm)/ 12 3/10" (312.6mm)

Weight app. 48.51 Ibs (22 kg)

BEHRINGER is constantly striving to maintain the highest professional

standards. As a result of these efforts, modifications may be made from

time to time to existing products without prior notice. Specifications and

appearance may differ from those listed or illustrated.

SPECIFICATIONS

AUDIOINPUTS

Instrument channel

Connector 1/4" phone jack

Type unbalanced, RF filtered input

Inputimpedance app. 10 MΩ

Microphon/line channel

Microphone input

Connector XLR

Type balanced, RF filtered input

Inputimpedance app. 25 kΩ

Line input

Connector 1/4" TRS jack

Type balanced, RF filtered input

Inputimpedance app. 40 kΩbalanced

20 kΩunbalanced

Aux/tape input

Connector 1/4" phone jack/RCA

Type unbalanced, RF filtered input

Inputimpedance app. 10 kΩ

AUDIOOUTPUTS

Direct out output

Connector XLR

Type balanced, low-impedance

line-level output

Output impedance app. 200 Ωbalanced

100 Ω unbalanced

Max. output level +24 dBu balanced

Tape output

Connector RCA

Type unbalanced, low-impedance

line-level output

Output impedance app. 100 Ω

Max. output level +20 dBu unbalanced

POWERAMPLIFIER

Power amp output 2 x 60 Watts

MIDIINTERFACE

Type 5-pin-DIN-socket,MIDI IN

DIGITALPROCESSING

Converters 24-bit sigma-delta, 64/128-times

oversampling

Samplingrate 46.875 kHz

DISPLAY

Type 2-digit numeric LED display

LOUDSPEAKER

Type 2 x 8" loudspeaker, special

custom-made acoustic speaker

Impedance 8 Ω(8" loudspeaker)

Power handling max. 60 Watts (8" loudspeaker)

ULTRACOUSTIC ACX1000

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of printing.The names

of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks of their respective owners. Their use

neither constitutes a claim of the trademarks by BEHRINGER nor affiliation of the trademark owners with BEHRINGER. BEHRINGER accepts no

liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained

herein. Colours and specification may vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not

agents of BEHRINGER and have absolutely no authority to bind BEHRINGER by any express or implied undertaking or representation. No part of this

manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for

any purpose, without the express written permission of BEHRINGER International GmbH. BEHRINGER®is a registered trademark.

Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
