Becker VARIAIR VASF 2.50/1-0.DC024 BASIC User manual

BETRIEBSANLEITUNG

OPERATING INSTRUCTIONS

INSTRUCTIONS DE SERVICE

ISTRUZIONI D’USO

HANDLEIDING

INSTRUCCIONES PARA EL MANEJO

MANUAL DE INSTRUÇÕES

NAUDOJIMOSI INSTRUKCIJA

KASUTUSJUHEND

LIETOŠANAS INSTRUKCIJA

DRIFTSINSTRUKS

DRIFTSINSTRUKTIONER

DRIFTSVEJLEDNING

INSTRUKCJA OBSŁUGI

KEZELÉSI ÚTMUTATÓ

NÁVOD K OBSLUZE

NAVODILO ZA UPORABO

NÁVOD NA OBSLUHU

UPUTE ZA RAD

MANUAL DE OPERATII

TREORACHA OIBRIÚCHÁIN

ΟΔΗΓΊΕΣ ΧΡΗΣΗΣ

EL KITABI

ИНСТРУКЦИИ ЗА ЕКСПЛОАТАЦИЯ

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

取扱説明書

사용설명서

使用说明书

VASF 2.50/1-0.DC024 BASIC

MAKE IT BECKER.

2 I VASF 2.50/1-0.DC024 BASIC

Type 1Type 2

Type 3

max. 3m

Cable: option

814



1 2

Type 1

7.3 kg

16.1 lbs

Type 2

7.6 kg

16.8 lbs

Type 3

8.2 kg

18.1 lbs

1.6 kg

3.5 lbs





AIR

Mounting position - permitted only horizontally

Position de montage - uniquement à l'horizontale

Some parts can get hot. Do not touch!

Quelques pièces peuvent devenir brûlantes.

Ne pas toucher la machine!

Transport - Use the eyelet!

Transport - Utilisez l'œillet!

Remove protective cap

Retirer les capuchons de protection

Risk by suction and rotating parts!

Do not reach into the openings.

Risque par aspiration et pièces en rotation!

Ne pas mettre les mains dans les ouvertures.

Caution

The pump is used for generating vacuum or pressure.

Cette pompe sert à générer du vide ou de la pression.

Operation is exclusively intended for normal

atmospheric air.

L'utilisation est prévue uniquement pour de l'air

atmosphérique normal.

Store in a dry place. Protect against splash water.

À remiser dans un endroit sec. À protéger contre les

éclaboussures d'eau.

The pump operates oil-free.

La pompe fonctionne sans huile.

A feeding of ﬂuids, toxic, ﬂammable or explosive media

is not permitted.

Il est interdit d'alimenter la machine avec des liquides

toxiques, inﬂammables ou explosifs.

VASF 2.50/1-0.DC024 BASIC I 3

mpere

olt, ...

top

Made in Germany

year

type

frequency

current FLA max

power required + /-

output frequency

voltage

D-42279 Wuppertal

www.becker-international.com

WN88.1-49



WARNING

Electrical connection only by professional

electrician!

Le raccordement électrique ne doit être

eectué que par un électricien professionnel !

Install a pre-fuse (J-class)

or circuit breaker according to UL489

Installer une fusible en amont (classe J) ou

disjoncteur selon la directive UL489.

2x LED

Operation

Malfunction

m3/h

mbar

MAX. Sound level Niveau sonore

LpA = 80.0 dB(A) - Type 1+2 *

LpA = 57.0 dB(A) - Type 3 **

* consumer side piped, other

side open (without silencer)

côté consommateur connecté,

l'autre côté ouvert

both sides piped (with silencer)

deux côtés ouverts

D-42279 Wuppertal

www.becker-international.com

year

Made in Germany

type

speed min

-1

power required kW / hp

inlet capacity m³/h / cf

pressure/vaccum

current FLA A

mbar

voltage

protection fuse / SCCR A / kA

DIN EN ISO 11203

Accuracy Class 2

KpA = 3 dB(A)



45°C/113°F 45°C/113°F

0°C/32°F

INLET GAS

A > 100mm

A > 4"

0°C/32°F

max. 90%

800m

max.

l m

PRESSURE

-p

VACUUM

Ø 1“

Caution

Ambient temperature: 0-45°C / 32-113°F

Température ambiante : 0-45 °C/32-113 °F

Air/Inert gas temperature: 0-45°C / 32-113°F

Température de l'air/gaz inerte : 0-45 °C/32-113 °F

The characteristics depend on the installation site and are

valid up to an elevation of 800 meters above sea level.

Les caractéristiques dépendent du site d'installation et sont

valides jusqu'à une altitude de 800 mètres au-dessus du niveau

de la mer.

Humidity: maximum 90%, non-condensing

Taux d'humidité : 90 % maximum, non condensée

Clearance should be no less than 100mm / 4" to ensure

sucient air ﬂow for cooling.

La distance ne devrait pas être inférieur à 100mm/ 4" aﬁn

d'assurer un débit d'air susant pour le refroidissement.

To reduce the risk of electric shock or injury use indoors only

Pour réduire le risque de choc électrique ou de blessure, utiliser

à l'intérieur seulement

8 9

VASF 2.50/1-0.DC024 BASIC I 4

EMC

immunity according to DIN EN 61800-3

Interference emission: 1st environment

category C1

Interference immunity: 2nd environment

DC-

Power U V W Signal

Shield

Clamp

Strap

Caution

Before commencing maintenance, follow

lock out procedure to avoid unintentional

restarting.

Some parts may be hot.

Do not touch / let it cool down!

Avant la maintenance, suivez la procédure

pour éviter le redémarrage involontaire.

Certaines parties peuvent être chaudes.

Ne pas toucher / Tout d'abord, laisser

refroidir

electronic pump

24VDC ±20%

21A

0.4/0.54kW/hp

25A

NEMA 1 NEMA 12

276x132x76 295x143x170

Voltage Tension:

Current FLA Courant:

Power required

Puissance requise:

Frequency Fréquence:

Protection fuse

Fusible de prot.:

Type Rating

Classiﬁcation:

Dimensions [mm]:



Additional details refer to type plate

Pour plus de détails, se reporter à la plaque

signalétique

Technical data Données techniques

* Connection required for release

not in this version

relay

digital

interface

analog

interface

external

poti

serial

interface

RS485

X500:1

Terminal Function Line type Connectors (board)

X500:2

X500:3

X500:4

X500:8

X500:5

Rel._A (14) I/0-module**

** Galvanic isolation between I/0-module and power module

power-module**

Rel._Ref (11)

Rel._B (12)

max.

14-strand cable

ﬁnely stranded

recommended

with shield

Cable cross section:

0.25-0.5mm²

AWG24-21

Stripping length:

5mm

3-strand cable

ﬁnely stranded with shield

Cable cross section:

4.0mm²-6.0mm²

AWG12-10 without ferrules

Stripping length: 15mm

GND

X500:9 GND

DIGITAL_IN 24V

ANALOG_IN 1

X800:1

X800:2

X801:1

RS485_A

RS485_B

GND

X801:2 GND

X500:6

X500:7

X500:10

X500:11

X500:12

ANALOG_OUT 1

ANALOG_OUT 2

+3V3 Poti

Signal Poti

GND Poti

power

supply X200

X201

GND

DC 24V ±20%

X500

800

801

X204

X200

X100

X101

X102

X201

Frequency actual

0-10V

Linear Poti

1kΩ...10kΩ

Impedance: 500Ω

Set point: 0-10V

Default:

Start/Stop

max. 24V

For factory setting

only

Collective

fault

message

Terminal Line type

Current feedthroughTerminal Line labeling

Connectors (device)

motor

supply

X100

X101

X102

PTC *

motor-

protection

X204:1

X204:2

U/L1/D/L+

V/L2

W/L3/D/L-

(blue)

(white)

PTC2

PTC1

Fan

VUT1

MOTOR FANPTC

T2 +-W

10 11

VASF 2.50/1-0.DC024 BASIC I 5

malfunction

acknowledgment

X500:4

X500:8

+24V

releaseacknow-

ledgment

1 2

Maintenance

OFF

=OFF



PLQ[D





OFF

ON (I)

MAX 10x

h12

≥30s

OFF (0)

Input

ANALOG_IN

X500:5

min

max

1.67V

300Hz

50Hz

0 10V

Speed set mode

if f

< f

min

→VASF 2 stops!

Caution

Before commencing maintenance, follow

lock out procedure to avoid unintentional

restarting.

Some parts may be hot.

Do not touch / let it cool down!

Avant la maintenance, suivez la procédure

pour éviter le redémarrage involontaire.

Certaines parties peuvent être chaudes.

Ne pas toucher / Tout d'abord, laisser

refroidir

Depending on the dust load

(at least twice a year), remove the dirt

from the pump.

En fonction de la charge de poussière

(au moins deux fois par an), retirez la

saleté de la pompe.

1413

28100032610

2020-05-25

MAKE IT BECKER.

www.becker-international.com

WWW.BECKER-INTERNATIONAL-SHOP.COM

Gebr. Becker GmbH

Hoelker Feld 29-31

42279 WUPPERT

GERMANY

[email protected]

www.becker-international.com
