Becken BCHVS3123 User manual
Vertical
Cooker Hood
Vertical
Cooker Hood
Campana Extractora Vertical
Campânula Vertical
INSTRUCTIONS MANUAL
MANUAL DE INSTRUCCIONES
MANUAL DE INSTRUÇÕES
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 1 03/07/17 11:25
Dear client,
Thank you for purchasing this product.
The quality of this appliance has been certified by several
laboratory tests. This instructions manual is provided to
simplify the use of the appliance as well as to guarantee a
safe use.
Please read carefully the instructions and safety measures
described in this manual.
We sincerely hope you will be satisfied when using your new
appliance.
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 2 03/07/17 11:25
3
EN
Cooker Hood | Campana extractora | Exaustor
INDEX
1. SAFETY INSTRUCTIONS 4
1.1. Power Supply 5
1.2. Power Cord and Other Cables 5
1.3. Humidity and Water 5
1.4. Cleaning 6
1.5. General Precautions 6
2. OPERATING INSTRUCTIONS 6
2.1. Product Description 8
2.2. Using the Product 8
2.3. Troubleshooting 12
3. POST-SALE SERVICE 14
4. ENVIRONMENTAL PROTECTION 14
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 3 03/07/17 11:25
4
1. SAFETY INSTRUCTIONS
Important Warnings
Before using your appliance read this instructions manual carefully and
keep it in a safe place as you may need to consult it in the future.
Before turning on your appliance, and to ensure a safe and correct
operation, do not use if:
• It has fallen to the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation.
To avoid hazards or deterioration of your appliance through incorrect
use it is advisable to read these instructions thoroughly.
Your appliance may not be used for other purposes than the ones
intended and solely for household use. Any damage resulting from
using the appliance outside this scope, any incorrect use, as well as
any manual modifications to the product will not be covered and
automatically voids the warranty.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: to avoid the risk of electric shock, do not
remove the cover. The interior does not contain any parts
that can be repaired by the user. Ask for assistance from
qualified personnel.
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 4 03/07/17 11:25
5
EN
Cooker Hood | Campana extractora | Exaustor
Assistance
In case of malfunction, take your appliance to a qualified technician
for assistance.
This appliance can be used by children from the age of 8 and by
people with reduced physical, sensorial or mental capabilities and/or
lack of experience and knowledge if they have been given instructions
on using the appliance safely and if they understand the hazards
involved. Children may not play with the appliance. Cleaning and
maintenance must not be carried out by children without supervision.
These instructions are also available at www.suporteworten.pt
1.1. Power Supply
Make sure the main voltage is compatible with the appliance’s.
If this is not the case please consult the Customer Support Service.
1.2. Power Cord and Other Cables
Do not tangle the cord or pull it to disconnect the appliance.
Also, keep the cord away from warm surfaces.
Never use the appliance if it has a damaged cable or socket.
Take it to the Technical Support Service for replacement.
1.3. Humidity and Water
Do not use your appliance in humid places. Do not allow the appliance
to become wet under any circumstances as this may be dangerous.
To avoid fire hazard or electric shock do not expose your appliance
to humidity or water. Furthermore, do not place your appliance under
water (e.g. for cleaning).
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 5 03/07/17 11:25
6
1.4. Cleaning
Before cleaning, be sure to switch o the appliance and remove the
plug from the main power supply. Always allow the unit to cool down
before cleaning.
To clean the exterior of the product use a dry soft cloth only.
1.5. General Precautions
• Please follow the instructions in the user manual which help to
properly install and operate this product and enjoy its advanced
features. Please keep the instructions for future reference.
• Read all instructions before using the product.
• Maintenance and service operations are only to be carried out by
authorized professionals.
• Any damage caused by manual modifications to the product is not
covered by the warranty.
• If this product is used for other purposes than the ones originally
intended, or if it is not correctly connected, the product may become
damaged and the warranty will be voided.
2. OPERATING INSTRUCTIONS
Warning
• Keep your children from using the cooker hood.
• Your cooker hood is for domestic use only, not suitable for barbecue,
roast shop or other commercial use.
• Any installation work must be carried out by a qualified electrician
or competent person.
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 6 03/07/17 11:25
7
EN
Cooker Hood | Campana extractora | Exaustor
• The cooker hood and its mesh filter should be cleaned regularly in
order to keep it in good working order.
• Before cleaning, always ensure that the cooker hood is
switched o.
• Clean the cooker hood according to the instruction manual and
keep the cooker hood from the danger of burning.
• Do not use fire for drying your cooker hood.
• If there is any fault with your cooker hood, please call the service
department appointed by the agent for servicing.
• Please keep the room ventilated when your cooker hood and gas
hob are working.
• Do not exhaust the cooker hood through the same heated flue used
for the gas hob or other kitchen appliances.
• Before installation and use, read all the instructions and make
sure that the voltage (V) and the frequency (Hz) indicated on
your cooker hood are exactly the same as the voltage (V) and the
frequency (Hz) in your home.
• In order to get the most out of your cooker hood, please read the
instruction manual before installing & using, and keep it in a safe
place.
• Ensure that you obtain the warranty for your cooker hood, please
provide the warranty card and purchase receipt, or the warranty will
not be oered.
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 7 03/07/17 11:25
8
2.1. Product Description
Functions and Features
• The cooker hood is made of high quality materials with streamlined
design, according to technical and physical engineering theory, with
a luxury and aged aesthetic feel, and dierent style options perfect
for your kitchen.
• Equipped with a high power, low noise electric motor and centrifugal
leaf, it produces strong, low noise suction, and a non-stick grease
filter which is easy to clean.
• With the isolated low voltage circuit board control, 12vAC input, the
lights are more concentrative and use is much safer.
• The grease filter is easy to remove and clean, wipe the motor and
other interior parts lightly.
• A special wind tunnel construction and oil collector design has been
used, avoiding grease left in the flue.
2.2. Using the Product
Installation
Installation dimensions
65 cm
|
75 cm
Image 1
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 8 03/07/17 11:25
9
EN
Cooker Hood | Campana extractora | Exaustor
1. The cooker hood should be placed at a distance of 65-75cm
(26-30inch) from the cooking surface for the best eect. See Image 1.
2. After confirming the installation height for the hood, fix the
installation hole for the hood, the inner chimney bracket and the
safety hole in accordance with the hood size. Make 6pcsφ8 holes
on the wall (See Image 2).
3. Install the exhaust pipe onto the cooker hood, see Image 3.
4. Install the chimney bracket on the chimney, see Image 4.
Extension tube
Image 2 Image 3
Inside chimney
Outside chimney bracket
Outside chimney
Image 4
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 9 03/07/17 11:25
10
5. Make the hood hang on the wall in the fixed position, adjusting
the cooker hood position, and fix it with screws (safety screws),
see Image 5.
6. Adjust the height of the inside chimney to the position of the inside
chimney bracket and fix it with a screw. See Image 6.
Image 5 Image 6
Note: The two safety vents are positioned on the back casing, with a
diameter of 6mm.
Note:
• Any installation work must be carried out by a qualified electrician
or competent person.
• Do not connect the ducting system of the hood to any existing
ventilation system which is being used for any other appliance, such
as warmer tube, gas tube, hot wind tube.
• The inclination angle of the ventilation pipe should be no less than
120º; you must direct the pipe horizontally, or, alternatively, the pipe
should go up from the initial point and led to an outer wall.
AF Manual Instruções Campanula Parede BCHVS3123 A5.indd 10 03/07/17 11:25
