Becca ACCEL-COOL User manual
Feb 2022, Rev. 1.0 BECCA INC. Instruction Manual Accel-Cool
1
Instruction Manual
ACCEL-COOL™
17.5 Gallon
Technical Assistance call (800) 655-5649
Approved to
UL2208 &
Class I Div 1
Feb 2022, Rev. 1.0 BECCA INC. Instruction Manual Accel-Cool
2
ACCEL-COOL™
Start-up Procedure
After positioning the unit, installing the
electrical, and connecting power, please use
the following procedure:
1) Remove cover to the lower electrical
explosion proof box
ACCEL-COOL™
2) Assure the timers per the following picture
Blower Cycle
Timer
Delay Time to
Cycle Timer
Set at 1 Hr
•Calibration Set Point
- “1” (5 Min)
•Running Set Point
- “5” (30 Min)
Set at “B”
Set at “N”
Set at 10 Min M
in
Set at “1” (1 Min)
Set at “C”
Set at “N”
Power Supply
Board Box
Feb 2022, Rev. 1.0 BECCA INC. Instruction Manual Accel-Cool
3
3)
Initial Start-up to set Timers –The timers need to be set when power is first
provided to the unit. Please use the following procedure:
a) The Blower Cycle Timer (left timer) should be on “1” (5 Minutes)
b) Turn on the power to the unit
c) The Blower will cycle for 5 Minutes
d) When blower stops, set Blower Cycle Timer to “5” (30 Minutes) for
running the unit.
The timers are now set-up and ready to use!
NOTE: Anytime power is lost to the Recycler, this procedure will need to be
completed to reset the timers.
•Running Set Point
–“5” (30 Min)
Blower Cycle
Timer
Delay Time to
Cycle Timer
Feb 2022, Rev. 1.0 BECCA INC. Instruction Manual Accel-Cool
4
MAINTENANCE SCHEDULE
Semi-Annually
-Clean Venturi System with Simple Green
To maintain performance
Annually
- Clean Ventrui System with Simple Green
To maintain performance
Amplified Air
Compressed Air
Shop Air
Contamination
Build up
Feb 2022, Rev. 1.0 BECCA INC. Instruction Manual Accel-Cool
5
WARRANTY INFORMATION / TECHNICAL ASSISTANCE
The Warranty of your system begins with the Certified Start-up by your local BECCA Distributor. Make
sure this is completed and you receive a copy of the Certified Start-up document.
For more information, prices or technical assistance,
contact your local BECCA distributor or call / fax our
BECCA Care™ Numbers:
2010 Cobb International Blvd Ste H
Kennesaw, GA 30152
Tel:(800) 655-5649 Fax: (800) 655-5684
Copyright © 2022 by BECCA Inc. All Rights Reserved.
