Baumatic BES900BGL User manual

BES900BGL

90 cm Glass Chimney

Hood

User Manual for your Baumatic

BES900BGL

90 cm Glass Chimney hood

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 21/05/12

Contents Page

Environmentalnote 4

IMPORTANT SAFETY INFORMATION 5 – 7

Specifications of your cooker hood 8 – 9

Product dimensions 8

Specifications 8

Using your cooker hood 9 – 11

Settingthetimeofday 9

Lightcontrol 9–10

Speedselection 10

The cut-off timer 10 - 11

Cleaning your Baumatic cooker hood 11

Cleaning 11

The grease filters 11

Maintenance 12 - 15

Removing and cleaning the grease filters 12 - 13

Changingalightbulb 13-14

Fitting the carbon filter 14 - 15

Installation 15 - 25

Electricalconnection 16

Before beginning installation 16 - 17

Extraction mode or recirculation mode? 18

Installing your cooker hood 18 - 21

Connecting to external ducting 22

Fitting the chimney 22 – 24

Completing the installation 25

Troubleshooting 25 – 26

Baumatic consumables 27

Contactdetails 28

ENVIRONMENTAL NOTE

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any

plug useless. Cut the cable off directly behind the appliance to

prevent misuse. This should be undertaken by a competent

person.

CONFORMITY TO W.E.E.E. DIRECTIVE

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

oThe hood must be installed in accordance with the installation

instructions and all measurements followed.

oIf the cooker hood is installed for use above a gas appliance then

the provision for ventilation must be in accordance with the Gas

Safety Codes of Practice BS.6172, BS.5440 & BS.6891 (Natural

Gas) and BS.5482 (LP Gas) 1994, the Gas Safety (Installation &

Use) Regulations, the Building Regulations issued by the

Department of the Environment, the Building Standards

(Scotland) (Consolidated) Regulations issued by the Scottish

Development Department.

oIt is dangerous to alter the specifications or to modify this

product. Do not tamper with it or attempt to modify the

appliance in any way.

oWhen installing the hood, ensure that the following

recommended distances are observed between the highest point

on the hob top (including the burners) and the bottom of the

cooker hood:

Electric cookers: 700 mm*

Gas cookers: 700 mm*

Coal/ oil cookers: 800 mm

IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS

THAN 700mm ABOVE YOUR COOKER.

*In the case of a reduced ceiling height, it is possible to reduce the

minimum gap to 400 mm.

oWhen installed between adjoining wall cabinets, the cabinets

must not overhang the hob.

oThe edges of the cooker hood are sharp – be mindful of this as

you handle your appliance, especially during installation and

cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS!

oIf the room where the cooker hood is to be used contains a fuel

burning appliance such as a central heating boiler then its flue

must be of the sealed or balanced flue type.

oIf other types of flue or appliances are fitted, ensure that there is

an adequate supply of air in the room.

oWhen the hood is being used in its extractor function, ensure

that the ducting is fire retardant and that there are no bends

sharper than 90 degrees as this will reduce the efficiency of the

hood.

oEnsure the ducting for the extractor function has the same

diameter as the outlet hole all the way through.

oKeep young children from using, playing with

or tampering with the cooker hood. Older

children and infirm persons should be

supervised if they are using the cooker hood.

oYour cooker hood is for domestic use only.

oPlease dispose of the packing material carefully – children are

especially vulnerable to it.

oDirty oil is an even greater fire risk.

oAlways put lids on pots and pans when cooking

on a gas cooker.

oThe manufacturer refuses to accept any responsibility for

damages arising to the hood or it catching on fire, from a failure

to observe the fire safety advice contained in this instruction

booklet.

oRemember that when in extraction mode, your cooker hood is

removing air from your room. Ensure that proper ventilation

measures are being observed.

oNote: Your cooker hood is designed to remove cooking

odours from the room and not steam.

oWarning - Always ensure that the cooker

hood has been disconnected from the

power supply before carrying out any work

on the hood, including replacing light bulbs.

oDo not connect the ducting system of this appliance to any

existing ventilation system which is being used for any other

purpose.

oDo not install above a cooker with a high level grill.

oNever leave frying pans unattended during use

as overheated fats and oils might catch fire.

oThe lights on this appliance should only be used during operation

of the cooker hood. They should not be left on permanently and

used as a lighting source.

oThe cooker hood should not be exposed to a direct heat source

from the cooking device underneath it, i.e. a naked flame from a

gas burner or heat from electric hob zones without a pan on

them.

oDo not attempt to use the cooker hood if it is damaged in any

way. Never attempt to use it without the grease filters fitted or

if the filters are excessively greasy!

oNever flambé cook under this cooker hood.

THE MANUFACTURER DECLINES ALL

RESPONSIBILITY IN THE EVENT OF FAILURE TO

OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR

INSTALLATION, MAINTENANCE AND SUITABLE

USE OF THE HOOD.

Specifications of your cooker hood

PRODUCT DIMENSIONS

Height: 650 mm

Width: 900 mm

Depth: 430 mm

Your cooker hood is fitted with:

oTouch control operation

oLCD display

oIntegrated centrifugal motor

oCut off timer

o3 Speeds

o2 x Washable aluminium grease filters

o2 x LED lights

oExtraction capacity: 1000 m³/hr

oOptional extras: 1 x pair S1 Carbon filters required for

recirculation. CQ4SS Decorative chimney cover

* If you are using the appliance in recirculation mode, then PLEASE

NOTE that some of the vent in the upper chimney section must be

exposed. You will have to take this into account when calculating the

minimum height of the cooker hood when installed.

Using your cooker hood

oMake sure that it has been installed by a suitably qualified

person, as per the information contained in Baumatic’s

installation instructions.

oWhen you initially connect the cooker hood to the electricity

supply, the backlight will turn on and the hood will enter stand-

by mode. If no buttons are pressed the backlight will turn off

again after 30 seconds.

Setting the time of day

oPress the timer button for about 5 seconds to enter the time

setting mode. The hour digits will begin flashing.

oUse the speed selection button to increase the number of hours

and the lamp button to decrease the number of hours shown.

oPress the timer button again to confirm the hour setting. The

minute digits will being flashing.

oAgain, use the speed selection button to increase the number of

minutes and the lamp button to decrease the number of minutes

shown.

oPress the timer button once again to confirm the minute setting.

The time of day will then be set and the hood will automatically

exit the time setting mode.

oIf you wish to change the time of day in the future, press and

hold the timer button for about 5 seconds to enter the time

setting mode and follow the above procedure.

Light control

oPress the lamp button once to turn the hood lights on. If you

press this button again they will turn back off.

oIt is highly recommended that the hood lights are only used

when the appliance is in operation. They should not be used as a

permanent lighting source for your kitchen.

Speed selection

oTo switch the cooker hood motor on you should press the speed

selection button. The motor has 3 speeds which are LOW,

MEDIUM and HIGH.

oOne press of the speed selection button will cause the motor to

run at LOW speed.

oTwo presses of the speed selection button will cause the motor

to run at MEDIUM speed.

oThree presses of the speed selection button will cause the motor

to run at HIGH speed.

oAnother press of the speed selection button will return the motor

to LOW speed.

oTo switch the hood off after use, press the power button. When

you next turn the hood on using the power button, the motor will

start to work at the speed it was set on last time.

IMPORTANT: IDEALLY YOU SHOULD TURN ON YOUR

HOOD TEN MINUTES BEFORE YOU START TO COOK,

OR AT THE VERY LEAST WHEN YOU BEGIN COOKING.

YOU SHOULD ALSO RUN YOUR HOOD FOR TEN

MINUTES AFTER YOU HAVE FINISHED COOKING.

The cut-off timer

oYou can program your cooker hood to switch off automatically

after a set time.

oTo set a cut-off time, switch the hood on and select a speed.

Then press the timer button to enter the countdown setting

mode.

oYou can then use the speed selection button to set the required

countdown time when you wish for your hood to switch off.

When you first press the speed selection button, the display will

show the minimum cut-off time of 5 minutes. Each press of the

speed selection button after this will increase the cut-off time by

1 minute.

oThe maximum countdown time that you can set is 60 minutes.
