Baumatic BTM25SS Operator's manual

User Instruction Manual for your

BTM25SS MICROWAVE

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING

YOUR MICROWAVE OVEN. IF YOU FOLLOW THE INSTRUCTIONS, YOUR

OVEN WILL GIVE YOU MANY YEARS OF GOOD, SAFE SERVICE. PLEASE

KEEP THIS MANUAL SAFELY FOR FUTURE REFERENCE.

* NOTE: This manual is designed to be used either as a whole

or to be used for quick set-up so you can get using your

appliance as soon as possible.

For the

8. Please also quickly see

the IMPORTANT PAGES. They are marked in bold on the

next page.

13/05/05

!>>

UICKFIRE! >>>>>>

Specifications…………………………………………………………….3

Safety Information …….……………….………..…4-5

Environmental Note ………………………….………..5

Precautions to Avoid Possible Exposure

to Excessive Microwave Energy ………….……….6

Never Use Your Microwave to: ..…..…….……..…7

Your Baumatic Microwave Oven ...…….…………8

Placing your Microwave Oven ………….……….…9

Installing your Microwave Oven ……….……….10

Before you Start Cooking with

your Microwave….…………………………..……11-12

Materials that you Can use in your Microwave…..….13

Materials that you CAN’T use in your Microwave

……………………………………………………………....14

Setting on your Microwave’s Clock……...………..………15

Setting your Microwave to Cook in the Future……….16

Notes on Microwaving Food……………….……………...….17

Using your Microwave Oven ……………...…18-32

Cleaning …………………………………………………………………33

Troubleshooting …………………………………34-37

Conditions of Guarantee ……………………………………….38

Contact Details……………….………………………………………39

Your Baumatic BTM25SS Microwave has:

96 Functions

911 Power Levels

9Touch Control Operation

9LED full programmer

9Child Safety Lock

9Stainless Steel Exterior & Cavity

9Optional Extras:

•MW1KIT Microwave rotisserie kit

•BTM25KIT Stainless Steel Building-in Kit

Cooking Features:

9General (see pages 18-19)

9Grill Cooking (see page 20)

9Microwave & Grill Cooking (see pages 21-22)

9Hot-air Convection Cooking (see pages 23-25)

9Microwave Hot-air Convection Combination Cooking

(see pages 25-26)

9Defrost Automatically (see page 27)

9Auto-function (see page 28)

9Quick Cook (see page 29)

9Stage Cooking (see pages 29-30)

ecifications

PLEASE READ BEFORE USING!

(To reduce the risk of fire, electric shock, injury or exposure

to Mircowave energy)

ELECTRICAL SAFETY

•NOTE - This appliance must be grounded. In the event of a

malfunction or breakdown, grounding will reduce the risk of electric

shock by providing a path of least resistance of electrical current. You

will be able to tell if it is because a non-grounded appliance will give

off an electrical discharge. Your Microwave’s plug must have a

grounding pin and if you use an extension cord, this must have a 3-pin

inlet/outlet as well as carry the same rating or greater than your

microwave. Only connect to a properly grounded outlet.

•Manufacturer declines all responsibility for any damage due to non-

grounding of appliance.

•DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR

AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON

THIS UNIT. THEREAFTER, IT SHOULD BE SERVICED ONLY BY QUALIFIED

TECHNICIANS.

•DO NOT USE IF THE SUPPLY CORD IS DAMAGED OR IF IT HAS BEEN

IMMERSED IN WATER.

•DO NOT USE IF THE OVEN HAS BEEN DAMAGED OR DROPPED.

•KEEP CORD AWAY FROM HEAT SOURCES.

•DON’T LET THE CORD HANG OVER THE EDGE OF TABLE.

•DO NOT USE YOUR MICROWAVE OUTDOORS OR NEAR A KITCHEN SINK,

SWIMMING POOL, IN A WET BASEMENT OR ANYWHERE CLOSE TO A SOURCE

OF WATER.

•NEVER TRY TO DISASSEMBLE OR REPAIR YOUR MICROWAVE – IT RETAINS A

HIGH POWER VOLTAGE CHARGE EVEN WHEN UNPLUGGED!

Safet

Information

GENERAL SAFETY

•READ AND FOLLOW THE

“PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY”

(Page 6).

•AS WITH MOST COOKING

APPLIANCES, CLOSE SUPERVISION

IS NEEDED TO REDUCE THE RISK

OF FIRE IN YOUR MICROWAVE

OVEN.

•SHOULD A FIRE START:

1) KEEP THE OVEN DOOR

CLOSED.

2) TURN THE OVEN OFF &

UNPLUG THE APPLIANCE.

3) DISCONNECT THE POWER

AT THE FUSE OR CIRCUIT

BREAKER PANEL.

•ONLY EVER USE YOUR MICROWAVE

FOR ITS INTENDED USE

(HEATING FOODS) AND NEVER

FOR INDUSTRIAL OR

LABORATORY PURPOSES.

•COOKING UTENSILS & DISHES WILL

BE HOT WHEN YOU TAKE THEM

OUT AFTER COOKING –

HANDLE WITH CARE!

•NEVER USE CORROSIVE CHEMICALS

OR VAPOURS IN YOUR

MICROWAVE. WHEN YOU

CLEAN THE DOOR AND OVEN

SURFACES, USE ONLY MILD,

NONABRAISIVE SOAPS OR

DETERGENTS APPLIED WITH A

SPONGE OR SOFT CLOTH.

•DO NOT COVER OR BLOCK ANY

VENTS ON THE OVEN.

•ONLY PLACE YOUR OVEN ON A FLAT,

LEVEL SURFACE.

•DON’T LET CHILDREN PLAY WITH

YOUR MICROWAVE.

•MAKE SURE YOU READ THE SECTION

ON INSTALLING YOUR

MICROWAVE PROPERLY (Pages

9-10).

•MAKE SURE YOU READ THE SECTION

ON COOKING FOODS IN YOUR

OVEN. THERE ARE SOME ITEMS

WHICH SHOULD NOT BE

HEATED IN YOUR MICROWAVE.

(Page 14) AND THINGS YOU

MUST NEVER USE YOUR

MICROWAVE FOR (Page 7).

___NOTE: PLEASE READ NOTE ON SUPERHEATED LIQUIDS (P.11)

CONFORMITY TO W.E.E.E. DIRECTIVE

Safet

Information / Environmental Note

AVOIDING POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

IMPORTANT NOTES ABOUT MICROWAVE ENERGY – READING THESE PRECAUTIONS

WILL HELP YOU TO AVOID POSSIBLE EXPOSURE TO MICROWAVE ENERGY

¾NEVER ATTEMPT TO

USE YOUR OVEN

WITH THE DOOR

OPEN. THE DOOR

MUST BE FULLY

CLOSED EVERY

TIME YOU

OPERATE YOUR

OVEN OTHERWISE

YOU RISK

EXPOSING

YOURSELF AND

OTHERS TO

HARMFUL

MICROWAVE

ENERGY.

¾YOUR MICROWAVE IS

FITTED WITH

SAFETY

INTERLOCKS. IT

IS VERY

IMPORTANT THAT

THESE ARE NEVER

TAMPERED WITH!

¾DO NOT PLACE ANY

OBJECT BETWEEN

THE OVEN’S DOOR

AND THE

DOORWAY (FRONT

FACE). NEVER

ALLOW DIRT,

FOOD OR CLEANER

RESIDUE TO

ACCUMULATE ON

THE SEALING

SURFACES

BETWEEN THE

INSIDE OF THE

DOOR AND THE

PART OF THE

DOORWAY WHERE

IT MEETS.

¾YOUR MICROWAVE

HAS SEVERAL

BUILT-IN

SAFETY

SWITCHES TO

ENSURE THE

POWER

REMAINS OFF

WHEN THE

DOOR IS OPEN.

NEVER TAMPER

WITH THESE

SWITCHES.

¾NEVER TRY TO

OPERATE A

DAMAGED

MICROWAVE

OVEN.

APART FROM

MAKING

SURE THAT

THE OVEN

DOOR CAN

PROPERLY,

YOU NEED TO

ALSO CHECK

THAT THERE

IS NO

DAMAGE TO

THE:

1) DOOR (EG.

DENTED)

2) HINGES &

LATCHES

(BROKEN OR

LOOSENED)

3) DOOR SEALS

& SEALING

SURFACES

¾REMEMBER THAT

YOUR

MICROWAVE

OVEN

SHOULD NOT

BE ADJUSTED

OR REPAIRED

BY ANYONE

BUT A

QUALIFIED

SERVICE

TECHNICIAN.

¾NEVER USE THE

INTERIOR OF

YOUR

MICROWAVE

OVEN FOR

STORAGE

PURPOSES.

NEVER STORE

COMBUSTIBLE

ITEMS SUCH AS

BREAD,

COOKIES,

PAPER

PRODUCTS, ETC.

INSIDE THE

OVEN TO

FACILITATE

COOKING.

ACCIDENTAL

OPERATION CAN

CAUSE THESE

ITEMS TO GO

ON FIRE AND

DO DAMAGE TO

YOUR

MICROWAVE,

THEREBY

PUTTING YOU

AT RISK IF YOU

USE IT WHILE

IT IS DAMAGED.

Avoidin

Possible Ex

osure to Microwaves

A note on the type of energy used

by your Microwave Oven

Microwaves are electromagnetic waves that transmit energy. When cooking, the

microwave energy penetrates food to a depth of 4cm (1½ inches), causing its molecules

to vibrate. The heat produced by this friction enables food to be heated, cooked or

defrosted.

How quickly a microwave oven cooks will depend on the size, quality and shape of the food

being cooked. Microwave cooking is healthy in that, without the need for large amounts

of cooking liquid, it means that food retains vitamins, nutrients, aromas and flavour.

Microwave Ovens are also more energy efficient than conventional cooking because they

use up to 70% less energy.

______________________

Never use your Microwave

Oven to:

:Dry clothes or fabrics

:Dry or warm up pets or live animals

:Warm or heat any item other than food and the appropriate

utensil

:Cook sealed containers

:Cook items where you have placed a liquid or mercury

thermometer (eg. Inside roasts or turkeys)

:Heat large quantities of cooking oil (fondue or deep frying) or

drinks with high alcohol contents

Never use

our Microwave to…

Your Baumatic Microwave Oven

oONCE YOU ARE SURE THAT YOUR OVEN IS NOT DAMAGED (EG. DENTS OR A BROKEN

DOOR) AND THAT THERE ARE NO PACKING MATERIALS AND ACCESSORIES INSIDE IT,

YOU CAN THEN INSTALL IT ON A FLAT SURFACE SUCH AS A COUNTERTOP. BE SURE

THAT THE SURFACE CAN HOLD AT LEAST YOUR MICROWAVE’S WEIGHT (17.0 kg).

oBEFORE PLACING ON YOUR COUNTERTOP: REMOVE ANY PROTECTIVE FILM ON THE

CABINET SURFACE.

oBUT DO NOT REMOVE THE LIGHT BROWN MICA COVER THAT IS SCREWED TO THE OVEN CAVITY

TO PROTECT THE MAGNETRON.

oFIND A LEVEL SURFACE THAT PROVIDES ENOUGH OPEN SPACE FOR THE INTAKE AND

OUTLET VENTS.

oYOU NEED TO LEAVE A MINIMUM OF 3.0 INCHES (7.5 CM) BETWEEN THE OVEN AND ANY

ADJACENT WALL. ONE SIDE MUST BE LEFT OPEN FOR PROPER AIR FLOW.

oLEAVE A MINIMUM CLEARANCE OF 12 INCHES (30CM) ABOVE THE OVEN.

oDO NOT REMOVE THE LEGS FROM THE BOTTOM OF THE OVEN.

oDON’T LET ANYTHING BLOCK EITHER THE INTAKE OR THE OUTLET OPENINGS AS

THIS CAN DAMAGE THE OVEN.

oPLACE YOUR MICROWAVE OVEN AS FAR AWAY AS POSSIBLE FROM RADIOS AND TELEVISIONS

- YOUR OVEN MAY CAUSE SIGNAL INTERFERENCE.

UNLESS YOU ARE INSTALLING YOUR MICROWAVE IN ACCORDANCE WITH THE

INSTALLATION INSTRUCTIONS ON PAGE 10

, DO NOT PUT YOUR OVEN ON

TOP OF ANY OTHER HEAT-PRODUCING APPLIANCE OR A RANGE COOKTOP.

DOING SO COULD DAMAGE YOUR OVEN AND MAKE THE WARRANTY VOID.

NOTE:

For in-unit

installation,

please see

next page.

Placin

Your Microwave Oven

Installin

our Microwave

SURROUND FRAME

NOTE: INSTALLATION KIT NOT

INCLUDED BUT MAY BE

PURCHASED AS AN ADDITIONAL

ITEM.

Table of contents

Other Baumatic Microwave Oven manuals

Baumatic

Baumatic BTWM2SS Operating instructions

Baumatic

Baumatic BTM34SS User manual

Baumatic

Baumatic BAM251TK User manual

Baumatic

Baumatic BMC253SS User manual

Baumatic

Baumatic BTM25.2M User manual

Baumatic

Baumatic BAM28TK- 2 User manual

Baumatic

Baumatic GEM252TK User manual

Baumatic

Baumatic BTM23SS Operating instructions

Baumatic

Baumatic BS099 User manual

Baumatic

Baumatic BMC460SS User manual

Baumatic

Baumatic BTM40SL Operator's manual

Baumatic

Baumatic BMIC4625 User manual

Baumatic

Baumatic BMM201SS User manual

Baumatic

Baumatic BTM30SS User manual

Baumatic

Baumatic BTM25.5SS User manual

Baumatic

Baumatic BTM23.1SS User manual

Baumatic

Baumatic B900SS-B User manual

Baumatic

Baumatic BTM17.1SS Operator's manual

Baumatic

Baumatic BTM17.2SS Operator's manual

Baumatic

Baumatic BMM201SS User manual

Baumatic

Baumatic BMIS3817 User manual

Baumatic

Baumatic BMIC4644X User manual

Baumatic

Baumatic BMMI170SS User manual

Baumatic

Baumatic BTM17.3SS User manual

Popular Microwave Oven manuals by other brands

Daewoo

Daewoo KOG-574R0S Service manual

LG MH7040SS instruction manual

Sharp

Sharp R-895(AL)M Service manual

Dometic

Dometic DOTRM13W installation instructions

Sanyo

Sanyo EM-X680 instruction manual

Sharp

Sharp R-393M quick start guide

KitchenAid

KitchenAid KMCX4510 Use and care

Smeg

Smeg S45MCX1 Instructions for use

Russell Hobbs

Russell Hobbs RHM2044 user guide

Sunbeam

Sunbeam SMW759 owner's manual

Gallet

Gallet FMOE230S instruction manual

Bosch

Bosch CEG732X.1B User manual and installation instructions

Dometic

Dometic Roadmate 230 operating manual

Samsung

Samsung SJ0396W Owner's instructions

Sanyo

Sanyo EM-P494WS Supplement of service manual

Sharp

Sharp R-240 Operation manual

Electrolux

Electrolux EMS2840 user manual

Daewoo

Daewoo KOC-984T2S13 Service manual
