BA24 - ( )AS05100 Apparecchiatura elettronica

ISTRUZIONI PER L’INSTALLAZIONE

Electronic control unit

INSTRUCTIONS FOR INSTALLATIONS

BA24

LEGGERE ATTENTAMENTE QUESTO MANUALE PRIMA DI PROCEDERE ALL’INSTALLAZIONE.

• Questo prodotto è stato collaudato in GI.BI.DI. verificando la perfetta corrispondenza delle caratteristiche

alle direttive vigenti.

• La GI.BI.DI. S.r.l. si riserva la facoltà di modificare i dati tecnici senza avviso, in funzione dell'evoluzione

del prodotto.

• This product has been tested in Gi.Bi.Di. verifying the perfect correspondence of the characteristics to the

current directive.

• Gi.Bi.Di. S.r.l. reserves the right to modify the technical data without prior notice depending on the product

development.

PLEASE READ CAREFULLY THIS MANUAL BEFORE PROCEEDING WITH THE INSTALLATION.

• Ce produit a été essayé en Gi.Bi.Di. en vérifiant la correspondance parfaite des caractéristiques aux

règles en vigueur.

• Gi.Bi.Di. S.r.l. se réserve la faculté de modifier les données techniques sans aucun préavis suivant

l’évolution de ses produits.

S’IL VOUS PLAÎT DE LIRE AVEC ATTENTION CETTE MANUAL AVANT DE PROCÉDER AVEC L’INSTALATION.

• Este producto ha sido probado en Gi.Bi.Di. averiguando la perfecta correspondencia de las

características a las normas vigentes.

• La empresa Gi.Bi.Di. S.r.l. se reserva el derecho de modificar los datos técnicos sin previo aviso, en

función de la evolución del producto.

POR FAVOR LEER CON ATENCIÓN ESTE MANUAL ANTES DE PROCEDER CON LA INSTALACIÓN.

• Dieses Produkt wurde in Gi.Bi.Di. geprüft um die perfekte Entsprechung der merkmäle an die geltende

vorschriften zu prüfen.

• Gi.Bi.Di. S.r.l. behält sich das recht vor, die technischen daten der produktentwicklung entsprechend ohne

voranzeige abzuändern.

BITTE LESEN SIE VORSICHTIG DIESEN MANUAL BEVOR MIT DER ANGLAGE VORZUGEHEN.

• Este produto foi testado em Gi.Bi.Di. verificando a correspondência perfeita das características ao

normas vigentes.

• A Gi.Bi.Di. S.r.l. reserva-se o direito de modificar os dados técnicos sem pré-aviso em função de evolução

do produto.

LER COM ATENÇÃO ESTE MANUAL ANTES DE PROCEDER COM A INSTALAÇÃO.

• Dit product werd gekeurd in Gi.Bi.Di. Er werd nauwlettend gecontroleerd of de kenmerken van het product

perfect overeenkomen met de geldige richtlijnen.

• Gi.Bi.Di. S.r.l. behoudt zich het recht voor de technische gegevens te wijzigen zonder waarschuwing

vooraf, als dat nodig is voor de evolutie van het product.

LEES DEZE GEBRUIKSAANWIJZING ZEER AANDACHTIG ALVORENS DE INSTALLATIE AAN TE VATTEN.

• Η εταιρία GI.BI.DI. S.r.l. έχει ελέγξει αυτό το προιόν όσον αφορά την τέλεια προσαρμογή των

χαρακτηριστικών του στην ισχύουσα νομοθεσία.

• Η εταιρία Gi.Bi.Di. S.r.l διατηρεί το δικαίωμα αλλαγής των τεχνικών προδιαγραφών χωρίς

προειδοποίηση, όσον αφορά ανάπτυξη των προιόντων της.

LEES DEZE GEBRUIKSAANWIJZING ZEER AANDACHTIG ALVORENS DE INSTALLATIE AAN TE VATTEN.

GND

ANT

JP1

24Vcc 10W MAX

LAMP

SW1 SW2 SW3 SW4

LCD1

24Vcc 3W MAX

+24Vcc

PED

START

FCA M1

STOP

FCA M2

FCC M2

PHOTO 2

RISERVA

COM

FCC M1

JP3

DL1

DL2

DL3

DL4

DL5

DL6

DL7

DL8

DL9

DL10

DL11

MOTOR

OPEN

MOTOR

OPEN

JP4

COM EL

EL1

EL2

GND

SPIA

24Vcc

SEC

JP5

JP2

RL1 RL2 RL3 RL5

RL4

RL6 RL7 RL8 RL9

BA24

CF1 CF2

LED STATUS

OFF

+ SK

- SK

(AS05020)

CB24

~ 230Vac

24Vac

PHOTO 1

COSTA

PED (NO)

FCA M1 (NC)

STOP (NC)

FCA M2 (NC)

FCC M2 (NC)

PHOTO 2 (NC)

PHOTO 1 (NC)

COSTA (NC)

COM

FCC M1 (NC)

START (NO)

JP3

RISERVA (NC)

JP6

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

18 19 20 21 22 23 24 25 26 27 28 29

30 31

18 19 20 21 22 23 24 25 26 27 28 29

BA24

BA24 / AS05100

Electronic control unit for the automation of one

or two motors - 24V dc - for swinging and sliding gates,

overhead garage doors and barriers

230Vac monophase 50/60 Hz

1 or 2

24 Vdc

24Vdc 10W max

24Vdc 3W max

24Vdc 8W max

including safety device power supply

24Vdc 8W max including accessories power supply

Plug-in

-20°C +60°C

Control unit

Type

Power supply

N° motors

Motor power supply

Flashing light

Warning light

Accessories power supply

Safety device power supply

Radio receiver

Operating temperature

TECHNICAL SPECIFICATIONS / FUNCTIONS

• Red warning LEDs of N.C. contacts. There isn't the safety devices LED; the possible anomaly is indicated by

the writing SAF on the LCD.

• Green warning LEDs of N.A. contacts.

• Two electrical locks management.

• Safety test run before the opening and closing movement.

• Photocell 1 test run before the opening and closing movement.

• Amperometric circuit test run before the opening and closing movement.

• Stop and motion inversion for 2 seconds after intervention of the safety devices. At the next Start pulse the

motion restarts in the obstacle freeing direction.

• SEPARATE SAFETY DEVICES POWER SUPPLY Connect the safety devices that must be tested to this

clamp.

Digital programming of all functions.

• Working time adjustable independently in opening and closing for each single motor.

• Deceleration time adjustable independently in opening and closing for each single motor in the final motion

phase.

• Gate phase shift time adjustable independently in opening and closing.

• Adjustable pedestrian working time.

• Pause time adjustable and differentiated for complete or pedestrian opening.

• Thrust force adjustable on 10 levels for each motor.

• Decelerations selectable and adjustable independently on 10 levels for each motor.

• Absorption (anti-crushing) control adjustable on 100 levels for each single motor both in thrust phase and in

deceleration phase.

• Deceleration enable modes: with single or double limit switch.

• 4 possible working functions (step-by-step, step-by-step with stop, condominium or automatic, dead-man).

• Possibility of choosing the system configuration from swing gate (single or double), overhead/barrier and

sliding gate (single or double).

BA24 27

• COSTA choice with N.C. contact or 8K2 resistive.

• Anti-crushing enabling (motion inversion for 2 seconds and stop) or amperometric detection for limit switch.

• Specific menu for the exclusion of the accessories not used (picture 1, picture 2 and safety devices).

• Possibility to program: automatic closing, fast closing, pre-flashing, hammer stroke, final closing and opening

stroke, courtesy light, ending movement additional time, flashing light (both flashing and fixed), external clock

management with three different modes, number of cycles for scheduled maintenance, installer code and

number of performed cycles.

• Time self-learning.

INSTALLATION

INSTALLATION WARNINGS

• Before proceeding with the installation, fit a magnetothermal or differential switch with a maximum capacity of

10A upstream of the system. The switch must guarantee omnipolar separation of the contacts with an opening

distance of at least 3 mm.

• To prevent possible interference, differentiate and always keep the power cables (minimum cross-section

2,5 mm²) separate from the signal cables (minimum cross-section 0.5 mm²).

• Make the connections referring to the following tables and to the attached screen-print. Be extremely careful to

connect in series all the devices that are connected to the same N.C. (normally closed) input, and in parallel all

the devices that share the same N.O. (normally open) input. Incorrect installation or improper use of the

product may compromise system safety.

• Keep all the materials contained in the packaging away from children, since they pose a potential risk.

• The manufacturer declines all responsibility for improper functioning of the automated device if the original

components and accessories suitable for the specific application are not used.

• After installation, always check carefully proper functioning of the system and the devices used.

• This instruction manual addresses people qualified for installation of “live equipment”. Therefore, good technical

knowledge and professional practice in compliance with the regulations in force are required.

• Maintenance must be carried out by qualified personnel.

• Before carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.

• This control unit may only be used for the purpose for which it was designed. Check the aim of the final use

and make sure that all safety measures are taken.

• If the control equipment is installed on doors or leaves with wicket door, make sure that in case the wicket door

is open, the equipment is not allowed to work.

• Use of the product for purposes different from the intended use has not been tested by the manufacturer,

therefore any work is carried out on full responsibility of the installer.

• Mark the automated device with visible warning plates.

• Warn the user that children or animals may not play or stand around near the gate.

• Appropriately protect the danger points (for example, using a sensitive frame).

• The only control equipment does not guarantee anti-crushing safety. Please make sure that the security

devices connected to the control equipment are suitable for this purpose.

Use glands adequate to ensure proper mechanical connection of cable and maintain the box protection degree IP55.

(2)

Description

JP1

Terminal

Battery charger equipment connection

Position Signal

Battery charger equipment connection

2AC

Battery charger equipment connection

3+SK

JP4

Electric lock negative (common)

11 COM EL

Electric lock 1 +24 Vdc positive - motor 112 EL1

Electric lock 2 +24 Vdc positive - motor 2

13 EL2

External accessory power supply negative (common)

14 GND

Warning light output 24Vdc 3W MAX

15 SPIA

+24Vcc external accessory power supply (photocells, radio, etc.)

16 + ACC

+24Vcc external safety device power supply.

17 SEC

BA24

COLLEGAMENTI ELETTRICI: MORSETTIERE

ELECTRICAL CONNECTIONS: FASTONS

CF1 CF2

1Secondary connection of 24Vac transformer

WARNINGS FOR THE USER

In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service.

Periodically check functioning of the safety devices. Any repairs must be carried out by specialised personnel

using original and certified materials.

The appliance is not to be used by children or people with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given supervision or instruction

WARNING: IMPORTANT SAFETY INSTRUCTIONS

It is very important to follow the present instructions for your own safety.

Please keep this manual.

-SK

LAMP

Battery charger equipment connection

Motor 1

Motor 2

Flashing light output 24V 10W max.

Working:

Fast flashing in opening, off during pause,

fast flashing in closing

START input (N.O.)

18 START

PEDESTRIAN input (N.O.)

After an emergency intervention (SAFETY or AMPEROMETRIC) with motion inversion

of the second leaf, the pedestrian command will activate both leafs to prevent them

from overlapping.

19 PED

JP3

BA24 29

JP3

STOP input (N.C.).

If not used, jumper with terminal n° 29.

20 STOP

FCAM1

FCCM1

FCAM2

FCCM2

PHOTO 2

Opening limit switch input - motor 1 (N.C.).

If not used, disable during programming.

Closing limit switch input - motor 1 (N.C.).

If not used, disable during programming.

Opening limit switch input - motor 2 (N.C.).

If not used, disable during programming.

Closing limit switch input - motor 2 (N.C.).

If not used, disable during programming.

PHOTOCELL 2 input (N.C.).

If not used, disable during programming.

Operation:

Input active during both opening and closing.

If intercepted, it immediately stops the motion and holds it stopped until the photocell

is freed. Upon release, motion always restarts in opening.

If intercepted when the gate is closed, following a Start command, it does not allow

opening the gate and it will be signalled with 5 fast flashes, then the warning light

turns on to indicate that the gate is not in stand-by. Upon release, the gate will start

opening without further commands.

If intercepted during pause, it reloads the pause time.

PHOTOCELL 1 input (N.C.).

If not used, disable during programming.

Operation:

Input active only during closing.

It stops and inverts the motion, opening the gate completely.

If the gate is closed, it does not affect its functioning.

If intercepted during pause, it reloads the pause time.

PHOTO 1

RESERVE

28 EDGE

Multifunctional input. External clock:

SEE PROGRAMMING C16-C17-C18

SAFETY DEVICES input (see menu C9)

If not used, disable durino programming.

Operation:

IInput active during both opening and closing.

It stops and inverts the motion for 2 sec. The gate will remain locked until the next

Start pulse, which will restart it in the obstacle freeing direction.

When active in stand-by, after the start/pedestrian command the door does not move

and 3 long flashes (2 sec.) will signal the anomaly.

If active in pause, the door does not close automatically (if expected) and

3 long flashes (2 sec.) will signal the anomaly.

THE EDGE ACTIVATION IS SIGNALLED BY THE WRITING “SAF” ON THE LCD.

29 COM Common inputs-outputs

ANTENNA BRAID input

30 GND

ANTENNA SIGNAL input

31 ANT

JP5

BA24

PROTECTION FUSES

DescriptionValue Type

Accessories and motor protection, power supply from battery charger circuit.

10 A /

Position

Equipment, motor and safety devices protection.

10 A /

Accessories protection.

500 mA FAST

PROGRAMMING PROCEDURE AND SYSTEM CONFIGURATION

The system adjustments can be accessed via the display. There are 5 different menus marked with the

letters A, C, F, H and E.

To enter the programming procedure:

- start from the display as is shown in the picture

- Press simultaneously the keys ESC and OK for 3 seconds

(The writing Gbd will turn off)

ESC OK

Gbd

The writing P A S S appears on the display.

Press the OK button to go to step 3.

Press the ESC button to exit and return to step 1.

ESC OK

PASS

4 figures appear on the display ( 0 0 0 0 ), the first one is flashing.

With the + or – keys, the user selects the first digit of the installer

code.

When the required digit is selected, press the OK key to confirm

and go to step 4.

ESC OK

0 0 0 0

The second figure is flashing.

With the + or – keys, the user selects the second digit of the

installer code.

When the required digit is selected, press the OK key to confirm

and go to step 5.

ESC OK

4 0 0 0

BA24 31

The third figure is flashing.

With the + or – keys, the user selects the third digit of the installer

code.

When the required digit is selected, press the OK key to confirm

and go to step 6.

ESC OK

4 6 0 0

The last figure is flashing.

With the + or – keys, the user selects the last digit of the installer

code.

When the required digit is selected, press the OK key to confirm and

go to step 7.

ESC OK

4 6 8 0

Now the installer code is complete: go to step 8.

If the installer code is not correct, go back to step 2.

ESC OK

4 6 8 3

The 5 main menus appear on the display (letters A C F H E); the A

is flashing.

With the + or – keys you can select the other menus (the relative

letter will blink).

Press the OK key to enter the selected menu (in the example A).

ESC OK

A C F H E

Use the + and + keys to enter the submenus (A1, A2, A3, A4,…)

Use the OK key to confirm the selected menu; a “Y” will appear next

to the menu name to indicate that it is enabled.

ESC OK

A 5

MENÙ A

BA24

Use the + and – keys to see the other submenus of the A menu;

follow the procedure as before.

Press the ESC key to return to the higher level (menu A, C, F, H E).

ESC OK

A 6

When the 5 main menus are shown on the display (letters A C F H

E) and the C is blinking;

Press the OK key to enter the selected menu (in the example C).

ESC OK

A C F H E

Use the + and – keys to select the submenus (C1, C2, C3, C4)

Press the OK button in sequence to:

enable the input (the Y will appear next to C1)

disable the input (the N will appear next to C1)

ESC OK

C 1

MENÙ C

Enter the H1 submenu to see the setting of the numeric value.

Use the + and – keys to select the menu H; it will blink.

Use the OK key to enter the menu.

ESC OK

A C F H E

Use the + and – keys to select the various submenus (H1, H2, H3,

H4)

Use the OK key to enter the selected submenu.

ESC OK

H 1

MENÙ H

This manual suits for next models

Table of contents

Other Bandini Industrie Control Unit manuals

Bandini Industrie

Bandini Industrie GiBiDi BA100 Guide

Bandini Industrie

Bandini Industrie GI.BI.DI. DSC70 Guide

Bandini Industrie

Bandini Industrie GiBiDi BA230 Guide

Bandini Industrie

Bandini Industrie GI.BI.DI. DSC80 Guide

Bandini Industrie

Bandini Industrie GI.BI.DI. TL100 Guide

Bandini Industrie

Bandini Industrie GiBiDi CB24 Guide

Bandini Industrie

Bandini Industrie GBD F4 PLUS Guide

Bandini Industrie

Bandini Industrie GBD BA230 Guide

Bandini Industrie

Bandini Industrie GBD SR100 Guide

Bandini Industrie

Bandini Industrie GI.BI.DI. SR100 Guide

Bandini Industrie

Bandini Industrie GiBiDi GROUND 610 Guide

Bandini Industrie

Bandini Industrie GiBiDi CL200 Guide

Bandini Industrie

Bandini Industrie GI.BI.DI. CL100 Guide

Bandini Industrie

Bandini Industrie GiBiDi CB24 Guide

Bandini Industrie

Bandini Industrie GBD F12E-AS04340 Guide

Bandini Industrie

Bandini Industrie Gi.Bi.Di. BA24 Guide

Bandini Industrie

Bandini Industrie GiBiDi BSC24 Guide

Popular Control Unit manuals by other brands

Festo

Festo Compact Performance CP-FB6-E Brief description

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Quick installation guide

JS Automation

JS Automation MPC3034A user manual

JAUDT

JAUDT SW GII 6406 Series Translation of the original operating instructions

Spektrum

Spektrum Air Module System manual

BOC Edwards

BOC Edwards Q Series instruction manual

KHADAS

KHADAS BT Magic quick start

Etherma

Etherma eNEXHO-IL Assembly and operating instructions

PMFoundations

PMFoundations Attenuverter Assembly guide

GEA

GEA VARIVENT Operating instruction

Walther Systemtechnik

Walther Systemtechnik VMS-05 Assembly instructions

Altronix

Altronix LINQ8PD Installation and programming manual

Eaton

Eaton Powerware Series user guide

WAGO

WAGO 750-407/040-000 manual

Sony

Sony CCU-590 Operation manual

Graco

Graco 25D614 instructions

Task Force Tips

Task Force Tips YE-RF-900 Instructions for installation, safe operation and maintenance

Shini

Shini SPV-U Series manual
