REV. 9/26/2016 INSTAX-LCD
Installation instructions for part AX-LCD
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
®
axxessinterfaces.com •metraonline.com © COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
Axxess Integrate
®
IMPORTANT
If you are having difficulties with the
installation of this product, please call our
Tech Support line at 1-800-253-TECH.
Before doing so, look over the instructions a
second time, and make sure the installation
was performed exactly as the instructions
are stated. Please have the vehicle apart
and ready to perform troubleshooting steps
before calling.
Using the LCD screen
Main menu options:
• Red adjusts the red backlighting of the LCD
(ranges from 1 to 32).
•
Blue adjusts the blue backlighting of the LCD
(ranges from 1 to 32).
• Green adjusts the green backlighting of the
LCD (ranges from 1 to 32).
• Contrast adjusts the contrast of the LCD
(ranges from 1 to 100).
• Reset puts the color back to the default settings.
Note: The vehicle menu will vary from car to car.
For more information, please see the owner’s
manual that came with the vehicle.
Arrow Up -
Toggles “up” through menu options
Arrow Down - Toggles “down” through
menu options
Return/ESC - Return to the previous menu
Enter - Enter current menu option
• Press and hold the “Return/ESC” button on the LCD screen
for 5 seconds until “Select Interface” comes up.
• Select “Connection Type”, and then press “Enter”.
• Scroll up or down to “Direct Connect”, and then press “Enter”.
• Once done, press the “Return/ESC” button two times to get back to the main menu.
