9
Regulation knob “1” (located closer to the front of the screen) enables setting of the upper extreme position of the
screen bottom bar:
“-“ - means increasing the lenght of the fabrics is rolled down when the screen is rolled in,
“+” - means decreasing the length of the fabrics is rolled down when the screen is rolled in.
3.6. +DELTA remote control system programing
Parallel operation of a few screens with built-in +DELTA installed in the same room is possible; in such case control
systems of each screen must be programmed with dedicated control code. The screen with +DELTA remote control
system is supplied with single remote transmitter, it is possible to purchase optional transmitters. The optional transmitters
must be programmed at the controller.
A) Setting of the new transmitter
Controller can memorize 10 individual control codes of remote transmitters.
Connect power supply to the screen.
Press 3 times P2 button of the remote transmitter within 12 seconds after the screen’s sound signal.
Transmitter is not set to the control system with individual code (random generated code).
B) Deleting of the transmitter
Connect power supply to the screen.
Press P2 button of the remote transmitter once.
Press the “Stop” button of the remote transmitter within the next 4 seconds.
Press P2 button within the next 4 seconds again.
The remote transmitter was deleted from the controller memory.
C) Appending additional remote transmitter
Appending new transmitter procedure has 2 steps. First step the remote transmitter supplied with the screen must be
set as the main remote transmiiter, in second step the optional new transmitter can be set up to operate with the
screen.It is possible to append multiple transmitters to the screen with the procedure described below.
Connect power supply to the screen.
Press P2 button of the original remote transmitter twice, the screen will generate sound.
Press “” button of the new remote transmitter once within the next 4 seconds.
Setting up of the main remote transmitter will be confirmed with the sound signal.
We recommend to mark the main remote transmitter to identify it easily in the future.
Press P2 button of the main remote transmitter twice, the screen will generate sound.
Press P2 button of the new remote transmitter once within the next 4 seconds.
Appending of the new remote transmitter will be confirmed with sound.
4. Screen operation
Projection screen AVERS can be operated manually or automatically with optional control systems Avers ALFA-Trigger,
ALFA-wireless trigger or Beta.
4.1 Manual operation
Manual screen operation is possible with the wall control switch or by radio frequency transmitter of the optional remote
control system.
- Push button „‚”, the screen will begin to roll down and stop automatically at the bottom position after rolling down.
- Push “Stop” button of the remote transmitter, screen rolling operation will be stopped.
- Push button „”, the screen will begin to roll up and stop automatically in the upper position after rolling up.
4.3. Screen maintenence
Pojection screen Avers do not require periodical service maintenance. Clean dust from the screen case and fabrics with
dry soft cloths. If needed use moisturized cloth with soft detergent to remove stains. After stain removal dry the cleaned
surface with cloth carefully.
!!! IMPORTANT !!!
Do not decrease (tuning knob 1+) the range of the rolled down surface. It can damage the screen.
Do not increase (regulation 2+) the range of the surface which was rolled down behind the STOP mark, placed in
the upper right corner of the screen. Rolling down the screen behind the mark can damage the screen.
!! CAUTION !! Roll out the screen a few minutes before projection will start.
The screen should be rolled in after projection is finished.
Projection surface would be damaged if the screen would be left open for a longer period of time.
