Avalue Technology LPC-15P5 User manual

Part No. E201715P5A0R

LPC-15P5

15" Fanless Multifunctional Touch Panel Computer

Quick Reference Guide

1st Ed –09 October 2013

LPC-15P5

2 LPC-15P5 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x LPC-15P5 Series Panel PC

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

—Chipset drivers and utilities

1 x Power Adapter

1 x Stand for Panel PC (optional)

Quick Reference Guide

LPC-15P5 Quick Reference Guide

1.3 System Specifications

Panel

LCD size

15", 4:3

Display Type

XGA TFT

Resolution

1024 x 768

Pixel pitch

0.297mm(H) x 0.297mm(V)

Luminance

400 cd/m²

Contrast ratio

700

Viewing angle

60(U), 80(D), 80(L), 80(R)

Response time

16 ms

Backlight

LED

Touch Type

5 Wires resistive

Touch Light

transmission

80%

Touch Interface

USB

System

Board

EMX-PNV

CPU

Onboard Intel® Atom™ D525 Dual Core 1.8GHz CPU

System Chipset

Intel ICH8-M

I/O Chip

Winbond W83627DHG

System Memory

One SODIMM socket supports up to 4GB DDR3 SDRAM

SSD

One CF socket supports Type I / II Compact Flash Card.

Hard Driver Bay

One 2.5" SATA HDD

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor

Monitoring system temperature, voltage, and cooling fan status. Auto

throttling control when CPU overheats

Expansion

1 x PCI slot, 1 x Mini PCIe slot

Rear I/O

Serial Port

2 x RS-232 D-sub 9 pin

Ethernet

2 x RJ-45

VGA

1 x VGA D-sub 15 pin

Audio port

1 x Line-out, 1 x Mic-in, 1 x Line-in

USB

4 x USB 2.0

Mouse & K/B

2 x PS/2 KB & MS

Expansion Slots

1 x PCI slot

Display

Chipset

Intel Pineview integrated graphics

LPC-15P5

4 LPC-15P5 Quick Reference Guide

Dual Display

VGA + LVDS

Audio AC97 Codec

Realtek ALC 888 supports 5.1CH Audio

Audio Interface

Connector: Line out, Line in, Mic-in

Ethernet LAN Chip

Intel® 82583V Gigabit LAN

Ethernet Interface

10/100/1000 Base-Tx Fast Ethernet compatible

Mechanical &

Environmental

Color

Front Silver & Rear panel Black

Mounting

Wall/Stand/VESA 75 x 75 & 100 x 100mm

System Power

Requirement

+12V DC Power Input

Power Adapter

Input: 100 ~ 250VAC/ 47 ~ 63Hz

Power Type

ATX

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-10°C ~ 60°C (14°F ~ 140°F)

Operating Humidity

5%~90% relative humidity, non-condensing

Dimensions

350mm x 274mm x 88.6mm

Weight

4.2 Kgs

Quick Reference Guide

LPC-15P5 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

1.4.2 Rear View

Connectors

Label

Function

Note

POWER

Power on button

VGA

VGA connector

COM1/2

Serial port

DB-9 male connector

Line-out

Line-out audio jack

Line-in

Line-in audio jack

USB

4 x USB 2.0 connector

Dock USB

2Gbe

RJ-45 Ethernet connector

PS/2 Keyboard

Keyboard connector

PS/2 Mouse

Mouse connector

Mic-in

Mic-in audio jack

12V DC-IN

DC Power-in connector

LPC-15P5

6 LPC-15P5 Quick Reference Guide

1.5 System Dimensions

Quick Reference Guide

LPC-15P5 Quick Reference Guide

2.Hardware

Configuration

Please refer to EMX-PNV Quick Installation Guide or User’s Manual for

advanced information.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

LPC-15P5

8 LPC-15P5 Quick Reference Guide

2.1 LPC-15P5 connector mapping

2.1.1 Serial Port 1/2 connector (COM1/2)

Signal

DCD

RxD

TxD

DTR

GND

DSR

RTS

CTS

2.1.2 VGA connector (VGA)

Signal

GND

DATA

GND

HSYNC

VCC

VSYNC

GND

CLK

Quick Reference Guide

LPC-15P5 Quick Reference Guide

2.2 Installing Hard Disk & Memory

Step 1. Unfasten 8 screws from the case to take off the top chassis.

LPC-15P5

10 LPC-15P5 Quick Reference Guide

Step 2-1. HDD Installation: Unfasten 4 screws of the HDD bracket and take it off.

Step 2-2. Insert the HDD into the bracket and fasten 4 screws.
