AUTOFLAME UNIC05 User manual

燃烧控制管理系统

AUTOFLAME

SERVOMOTORS GUIDE

伺服电机指南

2022.03.18

Autoflame Engineering Ltd.

Autoflame 技术工程有限公司

Unit 1-2 Concorde Business Centre

Airport Industrial Estate

Wireless Road, Biggin Hill

Kent TN16 3YN

United Kingdom

燃烧控制管理系统

+44 (0)1959 578 820

Tel:

technicalsupport@autoflame.com

Email:

www.autoflame.com

Web:

AUTOFLAME SERVOMOTORS

GUIDE

Autoflame 伺服电机指南

2022.03.18

This manual and all the information contained herein is copyright of Autoflame Engineering Ltd. It may not be

copied in the whole or part without the consent of the Managing Director.

Autoflame 工程有限公司拥有本手册的所有版权。在未经 Autoflame 公司常务董事同意的情况下，本手册内容

不得被整体或部分引用。

Autoflame Engineering Ltd’s policy is one of continuous improvement in both design and manufacture. We

therefore reserve the right to amend specifications and/or data without prior notice. All details contained in this

manual are correct at the time of going to print.

Autoflame 工程有限公司致力于不断提升 Autoflame 产品的设计和制造，我们保留修订本手册规范/数据的权利，

恕不另行通知。本手册内容于付印时准确无误。

Important Notes 重要提示

A knowledge of combustion related procedures and commissioning is essential before embarking work on any

of the MM / EGA systems. This is for safety reasons and effective use of the MM / EGA system. Hands on

training is required. For details on schedules and fees relating to group training courses and individual

instruction, please contact the Autoflame Engineering Ltd. offices at the address listed on the front.

为了安全有效地使用控制模块/EGA 系统，控制模块/EGA 系统的操作人员必须具有与燃烧相关的流程和调试知

识。我们要求使用者参加实践培训，请使用首页上 Autoflame 办公室通讯方式来详细了解团体培训和个别教学

事宜。

Short Form - General Terms and Conditions 一般条款

A full statement of our business terms and conditions are printed on the reverse of all invoices. A copy of these

can be issued upon application, if requested in writing.

在所有发票背面都印有我们的商业条款全文。客户可书面申请获得我公司商业条款文件。

The System equipment and control concepts referred to in this Manual MUST be installed, commissioned and

applied by personnel skilled in the various technical disciplines that are inherent to the Autoflame product

range, i.e. combustion, electrical and control.

只有专员人员才能安装，调试和使用本手册所提及的系统设备和控制概念。他们必须精通 Autoflame 产品所涉

及的各个技术学科，即:- 燃烧，电气和控制。

The sale of Autoflame’s systems and equipment referred to in this Manual assume that the dealer, purchaser

and installer have the necessary skills at their disposal. i.e., a high degree of combustion engineering

experience, and a thorough understanding of the local electrical codes of practice concerning boilers, burners

and their ancillary systems and equipment.

经销，购买或者安装本手册提及的 Autoflame 系统和设备的人员都要具有必要的专业知识，即:-与锅炉，燃烧

器和辅助系统/设备相关的丰富燃烧工程从业经验和全面电气行业规范知识。

Autoflame’s warranty from point of sale 保修条款

•Two years on all electronic and electro-mechanical equipment, assemblies and components.

对所有电子系统和部件实行两年售后保修；

•One year on all EGA systems and UV & IR scanners, including parts, components, cells and sensors.

对所有机械系统和部件和传感器实行一年售后保修。

The warranty assumes that all equipment supplied will be used for the purpose that it was intended and in

strict compliance with our technical recommendations.

Autoflame’s warranty and guarantee is limited strictly to product build quality, and design. Excluded absolutely

are any claims arising from misapplication, incorrect installation and/or incorrect commissioning.

保修前提: 所有设备必需被用于预期使用目的并且严格符合我们的技术建议。Autoflame 产品保修条款只适用于

产品制造质量问题和设计问题。根据保修条款，Autoflame 不接受由于错误操作，错误安装和/或调试导致的索

赔请求。



Contents 目录
IMPORTANT SAFETY NOTES / 重要安全提示..................................................................................... 6
AUTOFLAME SERVOMOTORS / Autoflame 伺服电机................................................................ 7
1. Servo Motor Sizes / 伺服电机尺寸..................................................................................................... 9
SMALL SERVOMOTORS / 小型伺服电机 ................................................................................... 10
1. Specifications / 规格 ........................................................................................................................ 11
2. External View / 外部视图 ................................................................................................................. 12
3. Dimensions / 尺寸............................................................................................................................ 13
LARGE SERVOMOTOR / 大型伺服电机 ..................................................................................... 14
1. Specifications / 规格 ........................................................................................................................ 15
2. External View –Metal Housing / 外部视图 –金属外壳.................................................................... 17
3. Dimensions –Metal Housing / 尺寸 –金属外壳 .............................................................................. 18
4. External View –Polycarbonate Housing / 外部视图 - 聚碳酸酯外壳 ............................................... 19
5. Dimensions –Polycarbonate Housing / 尺寸 –聚碳酸酯外壳......................................................... 20
INDUSTRIAL UNIC SERVOMOTORS / 工业 UNIC 伺服电机 ..................................................... 21
1. Specifications / 规格 ........................................................................................................................ 23
2. External Drawings / 外部图纸 .......................................................................................................... 25
3. UNIC05............................................................................................................................................ 26
4. UNIC10............................................................................................................................................ 27
5. UNIC20 & UNIC40........................................................................................................................... 28
6. Manual Operation / 手动操作........................................................................................................... 29
7. Industrial Servomotors 4-20mA / 工业伺服电机 4-20 毫安 .............................................................. 31
ATEX APPROVED SERVOMOTORS / ATEX 认证伺服电机 ...................................................... 32
1. ATEX Certification / ATEX 认证 ....................................................................................................... 32
2. ATEX Approved Small Servomotors / ATEX 认证小型伺服电机 ..................................................... 35
3. ATEX Approved Large Servomotors / ATEX 认证大型伺服电机 ..................................................... 37
4. ATEX Approved Industrial Servomotors / ATEX 认证工业伺服电机 ............................................... 39
SERVOMOTORS MOUNTING BRACKETS / 伺服电机安装支架 ............................................... 41
1. Small Servomotor Mounting Bracket and Coupling / 小型伺服电机安装支架和联轴器 ................... 43
2. Large Servomotor Mounting Bracket and Coupling / 大型伺服电机安装支架和联轴器................... 45
3. UNIC05 Mounting Bracket and Coupling / UNIC05 安装支架和联轴器 ........................................... 47
4. UNIC10 Mounting Bracket and Coupling / UNIC10 安装支架和联轴器 ........................................... 48
5. UNIC20 / UNIC40 Mounting Bracket and Coupling / UNIC20/UNIC40 安装支架和联轴器 ............. 49
INSTALLATION / 安装 ................................................................................................................. 50
1. Overview / 概况................................................................................................................................ 50
2. Wiring / 接线..................................................................................................................................... 51
3. Adjusting the Servomotor’s Position / 调节伺服电机的位置 ............................................................ 52
4. Servomotor Feedback Voltage / 伺服电机反馈电压 ........................................................................ 54
5. Servomotors with Autoflame Gas Valves / 带有 Autoflame 气阀的伺服电机................................... 55

7.6. Servomotor Flying Leads and Connectors / 伺服电机引线和连接器 ............................................... 56

8. MAINTENANCE AND TROUBLESHOOTING / 维护和故障排除 ................................................ 58

IMPORTANT SAFETY NOTES / 重要安全提示

Servomotors must be installed, wired, commissioned and adjusted by

an Autoflame trained and certified technician.

伺服电机必须由经过 Autoflame 培训和认证的技术人员安装、接线、调试和调整。

Any person installing, wiring, commissioning or adjusting the servomotors without

undergoing proper Autoflame training and without full understanding of the Micro

Modulation MM system might put themselves and others in a seriously dangerous

situation that can result in serious injury or even death, and may cause permanent

equipment damage and substantial property damage.

在没有接受适当的 Autoflame 培训和没有全面了解微调制控制模块系统，任何人安装、布线、调试或调整伺

服马达可能会使自己和他人处在严重危险的情况，可能会导致严重伤害甚至死亡，和可能引起永久的设备损害

和大量的财产损失。

Some of the wiring connections are live, make sure to totally and safely isolate the mains

power before undergoing any work related to the servomotors. Failure to do so can result

in fatal injury.

有些接线是带电的，在进行任何与伺服电机有关的工作之前，请确保完全安全地隔离电源。如果不这样做，可

能会导致致命的伤害。

Servomotors are supplied by the factory set at 0.0° position. Remember that this position

may not necessarily automatically position the valve or damper at 0.0° or a closed

position. This must be physically checked. Failure to check this can have seriously

dangerous consequences.

伺服电机由工厂提供，设定在 0.0 度位置。请记住，这个位置不一定会自动将阀门或风门定位在 0.0 度或关闭

位置。这必须进行物理检查。如果检查失败，可能会产生严重的危险后果。

This guide must be read in conjunction with the relevant MM system manual.

本指南必须与相关的控制模块系统手册一起阅读。

1 Autoflame Servomotors / Autoflame 伺服电机

Autoflame Servomotors Guide / Autoflame 伺服电机指南 Page | 7

1. AUTOFLAME SERVOMOTORS / Autoflame 伺服电机

Autoflame servomotor is a rotary type electric actuator, used with Autoflame’s Mk8 MM and Mini Mk8 MM

Micro Modulation systems to achieve ultimate positioning accuracy for boiler and burner applications which in

turn guarantees unmatchable control precision, accuracy, efficiency, repeatability and reliability.

Autoflame 伺服电机是一种旋转型电动装置，与 Autoflame 的Mk8 控制模块和 Mk8 微型控制模块微调制系统

一起使用，以实现锅炉和燃烧器应用的最终定位精度，从而确保无与伦比的控制精密度、准确度、效率、可重

复性和可靠性。

Autoflame offers three standard types of servomotors; small, large and industrial, which can be used for all

control channels. Autoflame fuel and FGR valves require small or large servomotors only. All servomotors can

be configured to drive clockwise or counter clockwise to open/close a valve or damper. The servomotors can

be installed in any orientation.

Autoflame提供三种标准类型的伺服电机; 小、大、工业，可用于所有控制通道。Autoflame燃料和 FGR（烟气

再循环）阀门只需要小型或大型伺服电机。所有伺服电机可配置为顺时针或逆时针驱动阀门/风门的开启/关闭。

伺服电机可以安装在任何方向。

The servomotors applications include:

伺服电机应用包括：

•Main, primary or secondary air damper

主, 一次或二次风门

•Forced draught damper

强制通风门

•Induced draught damper

引导式通风门

•Gas and/or oil fuel control valves

燃气和/或燃油燃料控制阀

•Fuel atomisation

燃料雾化

•FGR valve/damper

FGR（烟气再循环）阀门/风门

•Feedwater valve

给水阀

•Draught control damper

背压控制风门

•TDS control valve

TDS 控制阀

•Bottom Blowdown Valve

底部排污阀

•NOx reduction systems

氮氧化物减少系统

Autoflame servomotors offer the following feature:

Autoflame 伺服电机提供以下功能:

•Ultra-high accuracy level

超高精度水平

•Lightweight

轻盈

•Compact design suitable for narrow spaces

紧凑的设计，适合狭窄的空间

•Simple structure maximises reliability

结构简单，可靠性最大化

•Can be mounted straight into Autoflame gas or oil valves/dampers

可以直接安装入 Autoflame 燃气或燃油阀门/风门

1 Autoflame Servomotors / Autoflame 伺服电机

Autoflame Servomotors Guide / Autoflame 伺服电机指南 Page | 8

•Mounting bracket available for use with third party valves/dampers

可用安装支架与第三方阀门/风门一起使用

•Easy access to wiring terminals for installation, maintenance and testing

易于连接端子进行安装、维护和测试

•Simple wiring connection using a terminal block integrated into the servomotor

简单的布线连接使用一个集成到伺服电机的终端块

•Optional flying lead connector for quick, trouble free installation and replacement

可选引线连接器，快速、简易的安装和更换

•2 years limited warranty

两年有限保修

1 Autoflame Servomotors / Autoflame 伺服电机

Autoflame Servomotors Guide / Autoflame 伺服电机指南 Page | 9

1.1. Servo Motor Sizes / 伺服电机尺寸

The following servomotors are available

以下伺服电机可使用

Servo Type

伺服类型

Max. Torque Nm

最大扭力 Nm

Max. Torque ft.lb

最大扭力 ft.Ib

Small 小型

Large 大型

UNIC05

UNIC10

UNIC20

196

145

UNIC40

392

289

The load that the servomotor is used to drive should not exceed the maximum torque rating of the servomotor.

With Autoflame supplied valves, the correct servomotor size is already specified by Autoflame.

用于伺服电机驱动的负载不应超过伺服电机的最大扭力额定值。对于 Autoflame 提供的阀门，正确的伺服电机

尺寸已经由 Autoflame 指定。

To correctly size an Autoflame servomotors for use with a third party valves or dampers, the torque required

to drive that valve or damper should be checked, this in order to select a servomotor with sufficient torque to

drive the damper reliably. Please check the manufacturer’s specifications for that valve or damper to check

the torque requirements.

为了正确确定与第三方阀门或风门一起使用的 Autoflame伺服电机的尺寸，应该检查驱动该阀门/风门所需的扭

力，以便选择具有足够扭力的伺服电机来可靠地驱动伺服电机。请检查该阀门或风门的制造商的规格，以检查

扭力要求。

If this is unknown or the data is not available, then it is necessary to check the torque required to drive the

valve/damper using a torque meter. The torque should be measured when the valve/damper is fully loaded.

For example, for an air damper, that will be when the fan motor / VSD is driven at maximum speed. It is

recommended that a nominal 20% is added to the measured torque value to determine the type of servomotor

required for the application. This nominal 20% takes into account any factors such as dust, rust, and lack of

lubrication experienced between service intervals which can make the valve/damper require more torque.

如果这是未知的或数据不可用，则有必要使用扭力表检查驱动阀门/风门所需的扭力。扭力应该在阀门/风门满

载时测量。例如，对于空气风门，当风机马达/ VSD（变频器）以最高速度运作。建议在测量的扭力值上增加

额定 20%，以确定应用所需的伺服电机类型。这 20%的额定值考虑到各种因素，如灰尘、锈蚀和在使用间隔

期间缺乏润滑，这些因素会使阀门/风门需要更多的扭力。

𝑆𝑒𝑟𝑣𝑜𝑚𝑜𝑡𝑜𝑟 𝑇𝑜𝑟𝑞𝑢𝑒 = 𝑀𝑒𝑎𝑠𝑢𝑟𝑒𝑑 𝑡𝑜𝑟𝑞𝑢𝑒 𝑎𝑡 𝑚𝑎𝑥. 𝑙𝑜𝑎𝑑 𝑥 1.2

伺服电机扭力 = 测量的最大扭力负载 x 1.2

For example if the measured torque to drive an air damper at full load is 19Nm;

例如，如果测量的扭力驱动满载为 19Nm 的空气风门;

𝑆𝑒𝑟𝑣𝑜𝑚𝑜𝑡𝑜𝑟 𝑇𝑜𝑟𝑞𝑢𝑒 = 19 𝑥 1.2 = 22.8𝑁𝑚

伺服电机扭力 = 19 x 1.2=22.8Nm

Therefore a large servomotor may be selected for this damper.

因此，可以为风门选择大型伺服电机。

2 Small Servomotors / 小型伺服电机

Autoflame Servomotors Guide / Autoflame 伺服电机指南 Page | 10

2. SMALL SERVOMOTORS / 小型伺服电机

Small servomotors provide a maximum torque of up to 4Nm, they are compact, lightweight, extremely durable

and can be used for variety of applications including controlling air dampers, gas and oil fuel valves. The

housing is made from high impact Acrylonitrile Butadiene Styrene (ABS) for lighter weight and easier

installation.

小型伺服电机提供最大扭力达 4Nm，它们紧凑，轻便，非常耐用，可用于各种应用，包括控制空气风门，燃

气和燃油燃料阀。外壳由高冲击丙烯腈丁二烯苯乙烯(ABS)制成，重量更轻，安装更容易。

ATEX approved version with metal housing is also available for use in hazardous environments where

explosion proof equipment is necessary.

ATEX 认可的金属外壳的版本也可用于需要防爆设备的危险环境。

The following small servomotors are available:

以下小型伺服电机可使用：

Voltage –V AC

电源 –V AC

Frequency

频率

Supplied Wiring Glands

提供接线格兰头

Part #

产品号

230

50Hz

2x PG11 Metal Glands

2x PG11 金属格兰头

MM10005

110

60Hz

2x M20 - 1/2" NPSM Adaptors

2x M20 - 1/2" NPSM 转接头

MM10005/A

50Hz

1x M20 - 1/2" NPSM and Blanking Plug

1x M20 - 1/2" NPSM 和堵头

MM10005/C

60Hz

1x M20 - 1/2" NPSM and Blanking Plug

1x M20 - 1/2" NPSM 和堵头

MM10005/D

110

50Hz

2x M20 - 1/2" NPSM Adaptors

2x M20 - 1/2" NPSM 转接头

MM10005/E

This manual suits for next models

Table of contents

Languages:

Popular Servo Drive manuals by other brands

Mitsubishi Electric

Mitsubishi Electric MELSERVO-J5 MR-J5-G Series user manual

Robotis

Robotis XH430-W350-T manual

NTI AG

NTI AG LinMot C1250 Series installation guide

Welcon

Welcon WE2A D048 Series Hardware manual

Parallax

Parallax 900-00005 manual

Festo

Festo TP 1410 manual

Axor

Axor MAGNUM 400 Service manual

Siemens

Siemens SINAMICS S120 Getting started

Danfoss

Danfoss 176F6494 installation instructions

THORLABS

THORLABS TDC001 user guide

TECO

TECO JSDAP Series manual

Rockwell Automation

Rockwell Automation Allen-Bradley Kinetix 6000 user manual

GSK

GSK DA98D user manual

Lenze

Lenze m850 Mounting and switch-on instructions

Baumuller

Baumuller b maXX 3000 Instruction handbook

Baumuller

Baumuller b maXX 5000 Instruction handbook

Baumuller

Baumuller b maXX 5500 Instruction handbook

Danfoss

Danfoss VLT HVAC Drive FC 102 operating instructions
