Audiovox AS-9055 User manual

128-6831

1 of 2

3 Channel Remote

Car Starter

Model AS-9055

Owner’sManual

FEATURES :

w2 Programmable RF Transmitters

wThree Channel Receiver (capable of accepting 4 transmitters)

wOn-Board Start Relay

wOn-Board Accessory Relay

wOn-Board Ignition 1 Relay

wOn-Board Ignition 2 Relay

wIgnition 2 Relay Selectable On or Off During Cranking

wOn-Board Parking Light Relay

wIgnition 3 / Shock By-Pass / GM VAT Output (relay required)

wTach Signal Learning Circuit

wTwo ( + ) and Two ( - ) Safety Shutdown Circuits

wAlarm By-Pass Output

wAccessoryOutputs

(PulseBefore&AfterStart,DuringCrank&AfterShutDown)

wSelectable Steady or Flashing Parking Lights for Run Indication

wSelectable 5, 10, 15, 20 Minute Run Time

128-6831

2 of 2

© 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-6831

REMOTE STARTING THE VEHICLE

This will not start the vehicle if any one of the following situations exists;

The vehicle's hood lid is opened.

The gear shift selector is not in Park.

The brake pedal is depressed.

The safety control switch is in the Off position.

1. To start the vehicle, press and release the transmitter button two times

within 2 seconds. The vehicle will start and remain running for the pre-

programmed 5,10,15,20 minute run cycle. As a visual indication, the

parking lights will flash or remain on depending on the setting by your

installation center.

2. When you arrive at the vehicle, turn the ignition key to the ON position

(not the spring loaded start position), then step on the brake pedal to disen-

gage the remote starter. The vehicle will continue to run, but now on it's own

power.

NOTE: The engine will stop running before the pre-programmed run cycle

has expired if you perform any one of the following functions;

-Press and the button on the keychain transmitter two times within 2 seconds.

-Depress the brake pedal.

-Open the vehicle's hood

-Move the safety control switch to the Off position.

SAFETY CONTROL SWITCH

The red handle control switch allows you to temporarily disable the remote starting function

of the system and moving this switch to the Off position is recommended whenever the

vehicle is being serviced. When the system is disabled, the remote door locks and optional

accessories will remain operational.

FUNCTION SETTING CHART

To be completed by installer

Run Time 5 Min o10 Min o15 Min o20 Min o

Door Lock Timer 1 Sec/1 Sec o3.5 o1 Sec/Dbl 1 Sec o

Lights Pulse oSteady o
