AUDIOLINE Switch 20x User manual
Schnurloses DECT-/GAP-Telefon
Cordless DECT/GAP telephone
Operating
Instructions
Switch 20x GB
Table of contents
1 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2 Preparing the Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Operating Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Preliminary Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 Telephoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6 Other features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7 Call list / Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
8 Phone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9 Setting the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
10 Registering/de-registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . .25
11 PBX / Supplementary Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1
GB
Safety Information
2
1 Safety Information
Please read this operating instruction manual thoroughly.
Intended use
The telephone is suitable for telephoning within a public telephone network
system. Any other use is considered unintended use. Unauthorised modifica-
tion or reconstruction is not permitted. Under no circumstances open the
device or complete any repair work yourself.
Installation location
Prevent excessive exposure to smoke, dust, vibration, chemicals, moisture,
heat and direct sunlight.
Do not use the handset in potentially explosive areas.
Power adapter plug
aAttention: Only use the power adapter plug supplied because other
power supplies could damage the telephone.
Ensure access to the power adapter plug is not obstructed by furniture or
such.
Rechargeable batteries
aAttention: Never throw batteries into a fire. Only use batteries of the
same type. Pay attention to the correct polarity. Incorrect polarity of the
batteries represents a risk of explosion during charging.
Power failure
The telephone cannot be used to make calls in the event of a power failure.
Always keep a cord connected telephone which operates without an external
power supply available in case of emergency situations.
GB
3
Safety Information
Medical equipment
aAttention: Never use the telephone in the vicinity of medical equipment.
Effects on such equipment cannot be fully ruled out.
DECT1telephones can cause an unpleasant humming sound in hearing aids.
Disposal
In order to dispose of your device, take it to a collection point pro-
vided by your local public waste authorities (e.g. recycling cen-
tre). According to laws on the disposal of electronic and electri-
cal devices, owners are obliged to dispose of old electronic and
electrical devices in a separate waste container.
The adjacent symbol indicates that the device must not be dis-
posed of in normal domestic waste!
Batteries represent a hazard to both health and the environ-
ment! Never open, damage or swallow batteries, nor allow them
to get into the environment.
They may contain toxic and ecologically hazardous heavy
metals. You are legally obliged to dispose of batteries at the point
of sale or at appropriate collection points provided by your local
public waste authorities. Disposal is free of charge. The adjacent
symbols indicate that batteries must not be disposed of in normal
domestic waste and but at authorised collection points.
Packaging materials must be disposed of according to local reg-
ulations.
1DECT: Digital Enhanced Cordless Telecommunication = Standard for
cordless telephones.
Preparing the Telephone
4
2 Preparing the Telephone
Safety information
aAttention: It is essential to read the Safety Information in Chapter 1
before starting up.
Checking the package contents
The package contains:
Content Switch 20x model
2001202120312041
Base station with power adapter
plug 1 1 1 1
Charging station with power
adapter plug - 1 2 3
Handset 1 2 3 4
Telephone connection cable 1 1 1 1
Rechargeable batteries 2 4 6 8
Operating instructions 1 1 1 1
1Visit www.audioline.de
to find out whether this telephone is available.
The power adapter plugs supplied fulfils the ecodesign directive
of the European Council (Directive 2005/32/EC).
This means that power consumption is considerably lower than
power adapter plugs of an earlier design both in operating and
idling modes.
Preparing the Telephone
GB
5
Connecting the base station
aAttention: Position the base station at least 1 m away from other
electronic devices, otherwise there is a risk of mutual disturbance.
Connect the base station as illustrated in the diagram. For reasons of
safety, only use the power adapter plug and telephone connection line
supplied.
Mains power outlet
Telephone line socket
aAttention: Use only the power adapter plug supplied with the base
station!
Connecting the charging station2
Connect the charging station to the mains. Ensure access to the power
adapter plug is not obstructed by furniture or such.
2Only applies to telephone sets with at least two handsets, see “Checking the
package content“.
Preparing the Telephone
6
Inserting the batteries
Open the battery compartment cover. Put in the
batteries. Close the battery compartment cover.
aAttention: Use only type AAA NiMH 400 mAh
rechargeable batteries. Never use normal
batteries / primary cell batteries.
Observe the correct polarity!
Charging the batteries
☞Before the handset is used for the first time, insert it in the base station /
charging station for at least 16 hours.
The handset warms up during the charging process. This is normal and
does not represent a risk. Use only the adapter plug unit provided for the
charging station. The battery status is shown on the display. When the battery
capacity is nearly exhausted, the battery symbol (L) will flash in the display
and you will hear the battery warning sound (if the option is switched on) /
menu item “HS SETTINGS/TONE SETUP/BATTERY TONE“). You still have
up to ten minutes of talk time.
Setting the time and date on the handset
At initial operation the handset does not have the correct time (e.g. for entries
in the call list/answering machine). Date and time are set through the menu
item “HS SETTINGS/ DATE & TIME“.
Setting the display language
The display language is available 3 languages. The default setting is “German
(Deutsch)“. Set the language using the menu item “MT-EINSTEL. /
SPRACHE“.
Auto Answer
If this function is activated, an incoming call is taken when the handset is
removed from the base station. The automatic answering function is activated
and deactivated using the menu item “HS SETTINGS/ AUTO ANSWER“.
GB
7
Operating Elements
3 Operating Elements
Display
Call list
Softkey
(Menu / OK)
Off Hook button
Digit keys
Handsfree
Phone book
Earpiece
Arrow keys
(Up/down)
Softkey (Internal
call / Delete / Mute)
On Hook button
Redial
R-key
Microphone
Operating Elements
8
Charge contacts
Locate handset
(Paging)
