Audi RS 7 Assembly instructions

A7 S7 RS 7

Quick Questions & Answers

Getting to know your

The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.

By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this

information to augment that material.

auditechnology.com

To learn more about your features,

call your Audi Technologist.

1.855.750.TECH (8324)

Audi Brand Specialist

(Business Card Placeholder)

MMI® Controls

BLUETOOTH® Pairing

Audi connect®

Navigation

Climate Control

Cruise Control

Start-Stop System

Tire Pressure Monitor System

Clock Settings

Power Rear Hatch

Hands Free Trunk

Brakes

Table of Contents

LEARN MORE AT

auditechnology.com

Audi Explore

Welcome

Your new A7 is equipped with many features designed to accentuate

your driving experience and create an environment that is reﬁned,

elegant and supremely functional. This guide will assist you in better

understanding some of the features of your A7 and provide you with

the knowledge needed to enjoy your new Audi to its fullest.

When you see this symbol, you can

discover more with your smart phone

by texting the letter keys to the code

provided. A video tutorial will be sent

to further explain the topic.

Standard messaging and data rates charged by your phone

service provider will apply.

MMI®Controls

Audio & Navigation

TEXT A7AUDIO to 38981

Do not text and drive. Message and data rates may apply.

Pressing one of the six function buttons such as

or displays that features options in each corner of

the MMI® screen.

The four control buttons surrounding the control knob

correspond to the four corners of the MMI® display.

Selecting the desired button will access sub menus.

To make a selection or conﬁrm a request, simply

turn the control knob and press to select the option.

While operating the menus and functions, you can return

to a previous screen by pressing the button.

RADIO

NAV

BACK

The MMI® system consists of the MMI® display

screen and the MMI® control panel. This panel is

composed of a control knob, control buttons and

function buttons.

The MMI® Touch can be used to write letters and

numbers or access Preset Radio stations. To enter

a space, drag your ﬁnger from left to right on the

pad. To delete a character, drag your ﬁnger from

right to left. While in Navigation mode, after

pressing the control knob, the touch pad can be

used to move along the map in the desired

direction.

MMI® Controls

Volume

Pressing the volume dial will mute audio when in Radio mode

and pause when playing media. Holding it down will turn the

system o.

Track Advance Buttons

The arrow buttons allow you to move through the audio tracks

and radio stations.

Media Function Button

• Access available media from connected sources

• BLUETOOTH® Audio, SD card, DVD, Jukebox,

and Audi Media Interface (AMI).

• The AMI connection can be found in your glove box.

MMI®Controls

cont.

MMI® Controls

Steering Wheel Controls

In addition to the MMI® control

panel you can use the multifunction

steering wheel controls to display

speciﬁc MMI® features in the Driver

Information System.

Simply press the buttons

to display the MMI® modes.

The thumbwheel can be used

to scroll through the options.

Press it to make a selection.

Press the button to display

submenu options for that mode.

The button is used to

activate Voice Recognition.

The volume thumbwheel is

used to adjust the volume,

pressing it will mute audio.

Pressing the button will

repeat the last Navigation

announcement when

navigation is active.

The is used to access

a programmable stored

function.

NAV

4. Or press and hold the center

control knob until the

Presets screen shows

the Preset list.

2. Tune to the desired

station using the control

knob and pressing

to select.

3. Press and hold the desired

number on the touchpad

until you hear the tone that

the station has been stored.

Setting Station Presets

You can set any mix of up to 50 Presets from FM, AM or Sirius options.

TEXT A7SOUND to 38981

Do not text and drive. Message and data rates may apply.

MMI®Controls

cont.

1. Press the function

button multiple times to

toggle between FM, AM

or SIRIUS.

RADIO

NOTE: Occasionally, tall buildings and tunnels may interrupt the satellite signal. For more information, please refer to the SiriusXM® brochure in your glove box.

5. Scroll to the numbered list position

where you want to save your selection.

6. Press the center control knob again;

the station is saved to this position.

MMI® Controls

To access your Presets:

• Press the function button

then the Presets control button.

• Use the MMI® control knob to scroll

through your Presets.

• Press the center button of the control

knob to select a Preset.

• Using voice recognition, press the

button, after the beep, say, “Presets”.

RADIO

BLUETOOTH®Pairing: MMI®

Initial Setup

3. Select Audi MMI® when it

appears on the phone’s

screen.

To pair a phone:

1. Switch ignition to accessories mode.

2. Activate your phone’s BLUETOOTH® function

and set to Pairing or Search mode.

TEXT A7PAIR1 to 38981

Do not text and drive. Message and data rates may apply.

NOTE: See your phone’s owner manual for speciﬁc BLUETOOTH® activation instructions.

Vehicle should be stationary with the parking brake engaged while performing this operation.

BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will

automatically connect when you start your vehicle and your phone’s contacts automatically

synchronize, allowing you to retrieve contacts and make and receive calls through the

infotainment system. For more information regarding phone compatibility visit audiusa.com/bluetooth.

4. Use the MMI® control knob

to select Yes.

5. Conﬁrm the six-digit PIN

displayed matches the PIN

displayed on your phone,

and select Yes.

NOTE: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars, and it will be displayed whenever a paired phone is connected to the infotainment system.

6. Select Pair on your phone

to complete the pairing

process.

7. • Contacts synchronizing.

• BLUETOOTH® active and

network strength bars.

Important Safety Instructions and Warnings which you must read, are listed on the last panel under BLUETOOTH® Pairing.8

BLUETOOTH®

Pairing

Voice Recognition: MMI®

Call By Name

1. Press the button.

A beep will sound.

2. Say, “Call” <Name from directory>

(e.g., “Call John Smith”).

3. To conﬁrm the request, say “Yes”. The number

will be dialed.

NOTE: If multiple numbers are stored for a given contact, the system will ask

which number you wish to dial. When calling by name using voice recognition,

you must say the name as it is stored in your phone book.

TEXT A7VOICE1 to 38981

Do not text and drive. Message and data rates may apply.

Important Safety Instructions and Warnings which you must read, are listed on the last panel under Voice Recognition.

You may also speak natural language commands using the button.

Verbal destination commands can be given while in any screen.

Your Audi MMI® Navigation system has many Global Voice

Recognition commands available. This means that you can access

any function or while another function or mode is active.

Natural Language Commands

Commands such as:

• Enter Number • Redial

• Enter Destination • Online Destination

• Presets • FM, AM

• Media

You can begin your request from any screen.

Once your requested function is active, you can continue

with commands for that mode.

For example:

• Enter Number

• Dial

• Repeat

• Correction

To cancel Voice Recognition while active, say “Cancel” after

the beep or press the button until system responds

with cancelled.

Refer to your owner’s manual for further commands.

BLUETOOTH®

Pairing

1. Ensure SIM card (provided by dealer)

is present in the SIM slot.

2. Press the function button.

3. Press the Settings control button.

Audi connect®can provide you with Google Earth™, Google Voice™

Local Search, Wi-Fi Hotspot, Online Services (fuel prices, weather

information, travel information, news feeds) and myAudi

Destinations.

Vehicle should be stationary with the parking brake engaged while performing this operation.

Audi connect®

Conﬁguration:

Audi connect®

Initial Setup

TEXT A7CONNECT to 38981

Do not text and drive. Message and data rates may apply.

TEL

Audi connect®

Wi-Fi Conﬁguration

6. Select a password that is at least eight characters long.

The default password can be used. Or a new password can

be entered.

Audi connect®

cont.

4. Select Wi-Fi settings. 5. Then select Wi-Fi active

and choose Visible.

NOTE: Most devices use Encryption type WPA2 as the default.

9. Press the Back button,

scroll to Data connection

and select.

7. Select Apply settings to

save your password.

8. On your device, search for

Wi-Fi networks, select SSID

and enter your password to

establish a connection.

NOTE: You may connect up to eight wireless

devices at one time.

10. Select Without request.

Press the back button to

exit.

Data Conﬁguration

Important Safety Instructions and Warnings which you must read, are listed on the last panel under Audi connect®.

Audi connect®
