The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.
By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this
information to augment that material.
LEARN MORE AT
auditechnology.com
Audi Explore
Welcome
Your new A5 is equipped with many features designed to accentuate
your driving experience and create an environment that is refined,
elegant and supremely functional. This guide will assist you in better
understanding some of the features of your A5 and provide you with
the knowledge needed to enjoy your new Audi to its fullest.
When you see this symbol, you can
discover more with your smart phone
by texting the letter keys to the code
provided. A video tutorial will be sent
to further explain the topic.
Standard messaging and data rates charged by your phone
service provider will apply.
MMI® Controls
Audio & Navigation
The MMI® system consists of the MMI® display screen
and the MMI® control panel. This panel is composed of a
control knob with joystick, control buttons and function
buttons.
Pressing one of the six “function buttons” such as
“RADIO” or “NAV” (Navigation) displays that feature’s
options in each corner of the MMI® screen. For instance,
after pressing the “RADIO” function button, the four
corners of the MMI® screen read “Presets”, “Band”,
“Functions” and “Settings”.
To select one of these options, use one of the four corresponding
buttons, known as the “control buttons,” surrounding the “control
knob.” While operating the function options, you can return to a
previous screen by pressing the “BACK” button.
You can access sub-menus and lists by turning the control knob,
which scrolls through the listings on the MMI® screen. To make a
selection, simply press the center button of the control knob.
To move to a specific location within the Navigation Map or to control
the main menu of a DVD, a joystick located directly on top of the
control knob provides additional convenience.
Do not text and drive. Message and data rates may apply.
TEXT A5NAV1 to 38981
MMI® Controls
Media Function Button
7YY[iiWlW_bWXb[c[Z_W\hecYedd[Yj[ZiekhY[i
8BK;JEEJ>7kZ_e"I:YWhZ":L:"@ka[Xen"
and Audi Media Interface (AMI)*.
J^[_FeZ7C?YWXb[Yec[iijWdZWhZm_j^
MMI® Navigation plus.
Volume/Track Advance Button
The knob to the upper right of the control knob is the volume dial.
Tipping the knob right or left allows you to move through audio
tracks and radio stations. Pressing once will mute the audio.
>ebZ_d]_jZemdm_bbjkhdj^[ioij[ceú$
*iPod AMI cable is standard on Audi Vehicles with concert radio and convenience package.
MMI® Controls
cont.
Steering Wheel Controls
In addition to the MMI® control panel, you can use the
multifunction steering wheel controls to display specific
MMI® features in the Driver Information System. Simply
press the “MODE” button until you reach your desired
function, including Radio functions.
The thumbwheel can be used to scroll through the options.
Press it to make a selection. Steering wheel controls allow
you to select Phone functions.
MMI® Controls
You can set any mix of up to 50 Presets from FM, AM or Sirius options.
Setting Station Presets
Do not text and drive. Message and data rates may apply.
TEXT A5NAV2 to 38981
1. Press the “RADIO” function button
multiple times to toggle between FM,
7CehI?H?KI$
2. Tune to the desired station using the
control knob and pressing to select.
3. Press and hold the center control knob
until the Presets screen shows the
Preset list.
MMI® Controls
cont.
MMI® Controls
To access your Presets:
Fh[iij^[“RADIO” function button
then the Presets control button.
Ki[j^[CC?YedjhebadeXjeiYhebb
through your Presets.
Fh[iij^[Y[dj[hXkjjede\j^[Yedjheb
knob to select a Preset.
EYYWi_edWbbo"jWbbXk_bZ_d]iWdZjkdd[bicWo_dj[hhkfjj^[iWj[bb_j[i_]dWb$<ehceh[_d\ehcWj_ed"fb[Wi[h[\[hjej^[I_h_kiNCXheY^kh[_doekh]bel[Xen$
4. Scroll to the numbered list position
where you want to save your selection.
5. Press the center control knob again;
the station is saved to this position.
BLUETOOTH® Pairing MMI®
Initial Setup
3. Select Audi MMI® when it
appears on the phone’s
screen.
To pair a phone:
1. Switch ignition to accessories mode.
2. Activate your phone’s BLUETOOTH® function
and set to Pairing or Search mode.
Do not text and drive. Message and data rates may apply.
See your phone’s owner manual for specific pairing instructions. Vehicle should be stationary with the parking brake engaged while performing this operation.
TEXT A5NAV1 to 38981
BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will
automatically connect when you start your vehicle and your phone’s contacts automatically
synchronize, allowing you to retrieve contacts and make and receive calls through the infotainment
system. For more information regarding phone compatibility visit audiusa.com/bluetooth.
4. The Audi MMI® system
will indicate a PIN number
is required and ask, Would
you like to connect? Use
the MMI® control knob to
select Yes.
5. Confirm the six-digit PIN
displayed matches the PIN
displayed on your phone,
and select Yes using the
control knob.
Note: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars, and it will be displayed whenever a paired phone is connected to the infotainment system.
6. Select Pair on your phone
to complete the pairing
process.
-$9edjWYjiiodY^hed_p_d]$
8BK;JEEJ>WYj_l[WdZ
network strength bars.
BLUETOOTH®
Pairing
TEXT A5NAV6 to 38981
Voice Recognition: MMI®
Do not text and drive. Message and data rates may apply.
Call By Name
1. Press the “TALK” button.
A beep will sound.
2. Say, “Call” <Name from directory>
(e.g., “Call John Smith”).
3. To confirm the request, say “Yes”.
The number will be dialed.
Note: If multiple numbers are stored for a given contact, the
system will ask which number you wish to dial. When calling by
name using voice recognition, you must say the name as it is
stored in your phone book.
BLUETOOTH®
Pairing
Voice Recognition: MMI®
cont.
Name Tags
You may attach your own specific verbal Name Tags to stored Contacts, such as nicknames or other words that are not in the directory listing.
You may use any short verbal command.
TEXT A5NAV6 to 38981
Do not text and drive. Message and data rates may apply.
3. Select contact’s name and press MMI®
control knob to open contact’s information.
2. From the telephone menu,
select Directory.
1. Press the “TEL” function button.
4. Press the “TALK” button. After the beep, say “Store Name”.
5. When prompted, say <name>. When prompted,
repeat <name>.
6. The system will confirm, “The name <name> has been stored.”
7. To call this contact, refer to call by name using voice
recognition instructions.
Important Warnings and Safety Information, which you must read, are listed on the last panel under Navigation - Voice Recognition.
BLUETOOTH®
Pairing
Initial Setup
BLUETOOTH® pairing is a one-time procedure. Once paired via
BLUETOOTH®, your phone will automatically connect when you start your
vehicle and your phone’s contacts automatically synchronize, allowing
you to retrieve contacts, and make and receive calls through the
infotainment system.
BLUETOOTH® Pairing:
Audi concert radio
To pair a phone:
1. Switch ignition to accessories mode and turn on the Audi concert radio.
2. Activate your phone’s BLUETOOTH® function and set to Pairing or Search mode. BLUETOOTH® functions are accessed through the
phone’s settings.
Do not text and drive. Message and data rates may apply.
TEXT A5BT1 to 38981
For more information regarding phone compatibility visit audiusa.com/bluetooth.
3. Select Audi UHV when it
appears on the phone’s
screen.
4. Enter default PIN 1-2-3-4
and press Pair.
5. The phone is now paired
and your contacts will be
synchronized.
Note: Pairing methods may differ. See your phone’s owner manual for specific pairing instructions.
BLUETOOTH®
Pairing
Name Tag Creation
A name tag is required to operate the voice recognition system.
Voice Recognition:
concert radio
1. Press the “TALK” button.
2. After the beep, say “Store Name”.
TEXT A5BT1 to 38981
Do not text and drive. Message and data rates may apply.
To create a name tag:
4. The system will ask for the
phone number. Speak the
<numbers>, (e.g., 8-0-0,
5-5-5-, 1-2-3-4.)
5. If incorrect, say “Back” to
remove the last set of
numbers.
6. If correct, say “Store
Number”, and the system
will confirm that <name>
is saved.
Note: To confirm or play back the saved voice tags, press the “TALK” button. After the beep, say “Play Phone Book”.
3. When prompted say the
<name>. A second
prompt will ask you to
repeat the <name>.
Call by name
2. Say “Select Name”. 3. When prompted,
say the <name>.
4. After name confirmation,
say “Dial”, and the number
will be dialed.
1. Press the “TALK” button.
Important Warnings and Safety Information, which you must read, are listed on the last panel under BLUETOOTH® Pairing.
BLUETOOTH®
Pairing
