Atlona AT-MDP21 User manual

www.atlona.com | toll free: 1-877-536-3976

For International: 1-408-962-0515

Atlona 2x1 Mini DisplayPort KVM Switch

SPECIFICATIONS:

FEATURES:

REAR VIEW

INPUTS/OUTPUTS:

PACKAGE CONTENTS:

WARRANTY

Weight 0.65 lbs

SKU# AT-MDP21

• Inputs: 2 x Mini DisplayPorts, 4xUSB

• Outputs: 1 x Mini DisplayPorts, 2xUSB

• 1 x AT-MDP21 2x1 Mini DisplayPort KVM Switch

• 1 x Instruction Manual

• 2 x 5ft Mini DisplayPort cables

• 4 x 5ft USB cables

3 year manufacturer warranty (parts and labor)

• 2 x Mini DisplayPort inputs and 1mini DisplayPort output KVM Switch.

• 4 USB inputs and 2 USB outputs.

• 2 input select buttons on front panel to select the input sources.

• Passive mechanical Switch, doesn’t require power

• Supports digital video resolutions up to 1920x1200

• Supports high-speed uncompressed digital video.

• Type of Switcher: 2 inputs to 1 output, (Mechanical) Mini DisplayPort KVM Switch

• Video Resolutions: up to 1920x1200

• Controls: Select buttons on the front panel

• Signal Support: High-speed Uncompressed digital video and audio

• Safety Approvals: RoHS (2002/95/EC)

• Dimensions (LxWxH): 6.25”x 5” x 1.23”(160mm x 134.8mm x 32mm)

• Shipping Weight: 0.3 Kgs / 0.65 lbs

www.atlona.com | toll free: 1-877-536-3976

For International: 1-408-962-0515 2

CONNECTION DIAGRAM

AT-MDP21

Apple LED Cinema display

Apple laptop with mini

Displayport output

Apple laptop with mini

Displayport output

Keyboard

Mouse
