Atlona AT-HDMI40SR User manual

AtlonA

HDMI Extender over 1 CAT5e Cable

AT-HDMI40SR

User Manual

Safety and Notice

The AT-HDMI40SR HDMI Extender over 1 CAT5e Cable has been tested

for conformity to safety regulations and requirements in the US, and has

been certied for international use. However, like all electronic equipment,

the AT-HDMI40SR should be used with care. Please read and follow the

safety instructions to protect yourself from possible injury and to minimize

the risk of damage to the unit.

• Follow all instructions and warnings marked on the unit.

• Do not attempt to service the unit yourself, except where explained in

this manual.

• Provide proper ventilation and air circulation. Do not use near water.

• Keep unit away from objects that might damage the device and assure

that the placement of this unit is on a stable surface.

• Use only the manufacturer’s power adapter and connection cables.

They are designed for this unit.

• Do not use liquid or aerosol cleaners to clean this unit. Always unplug

the power to the device before cleaning.

Introduction

Features

The AT-HDMI40SR boosts up your video/audio transmission distance up

to 60m/200ft in HDTV 1080i format. With only one cost effective CAT-5/5e

cable, users can readily extend HDTV sources from DVD players, PS3, PC,

or any other kind of HDCP compliant source, to any remote display includ-

ing HDMI/DVI enabled TV set LCD, or monitor. This cost effective solution

allows HDCP compliant sources and players to transmit high quality video

and audio at greater distances.

The AT-HDMI40SR includes two units: transmitting and receiving units.

The transmitting unit is used to capture the input HDMI/DVI signals and

carry the signals through one RJ-45 connector into one CAT-5/5e/6 cable.

The receiving unit is responsible for equalizing the sent TMDS multimedia

data. The transmission distance between the sending and receiving units

can be up to 60m/200ft at 1080i and 40m/130ft at 1080p. With the equaliza-

tion control switch on the receiving unit, users can adjust the equalization

strength to the received TMDS signals, and therefore optimize the trans-

mission distance between source and destination.

• HDMI 1.2a compliant

• Extend the signal distance of an HDMI source up to 60m/200ft at 1080i or 720p

• Extend the signal distance of an HDMI source up to 40m/130ft at 1080p

• HDCP compliant

• Minimize the cable skew by adjustable 8-level equalization knob

1 2

Package Contents

Technical Specifications

• 1x HDMI transmitting unit (AT-HDMI40S)

• 1x HDMI receiving unit (AT-HDMI40R)

• 2x 5V 2A power adapter

• 1x User Manual

• Video Bandwidth: 1.65Gbps (HDMI 1.2a)

• Input TMDS signal: 1.2 volts (peak-to-peak)

• Input DDC signal: 5 volts (peak-to-peak)

• HDMI Connector: 19 pin type female connector

• Power Supply: 5V 2A

• Power Consumption: 10 Watts (max)

• RJ-45 Connector: 2 indication LEDs

• Dimensions: 70mm x 60mm x 25mm / 2.8”x2.4”x1” (L x W x H)

• Weight: 180g / 6.3oz

3 4

Panel Descriptions

HDMI IN: Connect a HDMI source with a HDMI M-M cable here

Rotary switch:

0: HDMI mode with 8 audio channels

1: HDMI mode with S/PDIF 2 audio channels

2: DVI mode

3-5: Reserved

6: Use default EDID

7: Learn EDID from the receiver

TMDS: Plug in a CAT5/5e/6 cable that needs to be linked to the TMDS connector

of the receiving unit: AT-HDMI40R.

Front View - Transmitting Unit AT-HDMI40S

Rear View - Transmitting Unit AT-HDMI40S

Mode

HDMI IN

5V DC TMDS

HDMI IN: Connect a HDMI display with a HDMI M-M cable here.

Rotary switch: Adjust the equalization strength to the received TMDS

signals. 0-7= strongest – weakest.

TMDS: Plug in a CAT5/5e/6 cable that needs to be linked to the TMDS

connector of the transmitting Unit : AT-HDMI40S.

5V DC: Connect to 5V DC power supply.

Front View - Receiving Unit AT-HDMI40R

Rear View –Receiving Unit AT-HDMI40R

Mode

HDMI OUT

5V DC TMDS

5 6

Hardware Installation

1. Connect your HDMI/DVI source (such as a DVD player) to the transmit-

ting unit AT-HDMI40S.

2. Connect your HDMI/DVI display (such as a plasma TV) to the receiving

unit AT-HDMI40R.

3. Connect your CAT-5/5e/6 cable between the transmitting and receiving

units.

4. Make sure your CAT-5/5e/6 cable is tightly connected and not loose.

5. Plug in 5V DC power cord to the power jack of the receiving unit.

6. Plug in 5V DC power cord to the power jack of the transmitting unit.

7. If a ickering or a blinking image is seen, try to adjust the rotational switch

to improve the cable skew. 0 stands for the strongest EQ while 7 stands for

the weakest. Try adjusting the EQ from 7 to 0.

Notice

1. If your HDMI/DVI device requires an EDID present, you can use an EDID

Reader/Writer to provide DVI / HDMI EDID information.

2. All the transmission distances are measured using Belden CAT-5e

125MHz.

3. To reduce the interference among the unshielded twisted pairs of wires in

CAT-5/5e/6 cable, you can use shielded CAT-5/5e/6 cables to improve EMI

problems, which worsens in long transmissions.

4. Because the quality of the CAT-5/5e/6 cables has major effects in how

long transmission distance will be, and the quality that is received by the

display, the actual transmission length is subject to your CAT-5/5e/6 cables.

For resolution greater than 1080i or 1280x1024, a CAT-6 is recommend-

ed.

Note for EDID (Extended Display Identication Data) learning

1. Please connect the display which you want to read EDID with a HDMI

cable to the transmitter’s HDMI-IN and turn Mode to 7so the Transmitter

can learn the EDID information from the connected HDTV. The LED on the

RJ45-OUT of Transmitter will dim and light again in a few seconds, which

indicates the EDID learning process is completed.

2. Turn Mode clockwise from Mode 7 to Mode 0 or Mode 1 for desirable

audio setting and enjoy the experience. DO NOT let the rotary arrow pass

by Mode 6 which will erase the EDID just learned and restore the default

EDID.

After the EDID is learned, please turn MODE to 1, then begin to adjust EQ

on Receiver from 7 to 0.

7 8

SAFETY INFORMATION

Safeguards

To reduce the risk of electric shock, do not

expose this product to rain or moisture.

If the wall plug does not t into your local

power socket, hire an electrician to replace

your obsolete socket.

Do not modify the wall plug.

Doing so will void the warranty and safety

features.

This equipment should be installed near

the socket outlet and the device should

be easily accessible in case it requires

disconnection.

Precautions

FCC Regulations state that any

unauthorized changes or modications to

this equipment not expressly approved by

the manufacturer could void the

user’s authority to operate this

equipment.

Operate this product using only the

included external power supply. Use of

other power supplies could impair

performance, damage the product or cause

res.

In the event of an electrostatic discharge,

this device may automatically turn off. If this

occurs, unplug the device, and plug it back

in.

Protect and route power cords so they will

not be stepped on or pinched by anything

placed on or against them. Be especially

careful of plug-ins, or cord exit points from

this product.

Avoid excessive humidity, sudden

temperature changes or temperature

extremes.

Keep this product away from wet locations

such as bathtubs, sinks, laundries, wet

basements and swimming pools.

Use only accessories recommended by

ATLONA to avoid re, shock or other

hazards.

Unplug the product before cleaning. Use

a damp cloth for cleaning. Do not use

cleaning uid or aerosols, which could

enter the unit and cause damage, re or

electrical shock. Some substances may

also mar the nish of the product.

Never open or remove unit panels or make

any adjustments not described in this

manual. Attempting to do so could expose

you to dangerous electrical shock or other

hazards. It may also cause damage to your

AT-HDMI-40SRS. Opening the product will

void the warranty.

Do not attempt to service the unit. Instead

disconnect it and contact your Authorized

ATLONA reseller or contact ATLONA

directly.

WARRANTY

1. LIMITED WARRANTY

Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the

accompanying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be

free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event

applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of

receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation

may not apply to Customer.

2. CUSTOMER REMEDIES

Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-

gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet

this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited

Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-

uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.

3. NO OTHER WARRANTIES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLI-

ERS DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED

TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH

REGARD TO THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES

CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JU-

RISDICTION.

4. NO LIABILITY FOR DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLO-

GIES OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITA-

TION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS

OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER

PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA

TECHNOLOGIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA

TECHNOLOGIES’ AND ITS SUPPLIERS’ ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT

SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JU-

RISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

ATLONA

2151 O’toole Ave, Ste D

San Jose CA 95131

Toll Free: 1-877-536-3976

International: 408-954-8782

FAX: 408-954-8792

Website: www.atlona.com

E-MAIL: [email protected]

Table of contents

Other Atlona Extender manuals

Atlona

Atlona AT-COMP300SR User manual

Atlona

Atlona AT-PRO2HDREC-DA User manual

Atlona

Atlona AT-PRO3HDREC User manual

Atlona

Atlona AT-IR300SRS User manual

Atlona

Atlona AT-VBNC400SR User manual

Atlona

Atlona AT-HD-IR40SR User manual

Atlona

Atlona AT-COMP150SR User manual

Atlona

Atlona AT-USB50-SR User manual

Atlona

Atlona AT-2VGA300SL User manual

Atlona

Atlona AT-AV-SR User manual

Atlona

Atlona AT-PRO2HDREC User manual

Atlona

Atlona AT-HDVS-150-TX-WP User manual

Atlona

Atlona AT-DVI15SRS User manual

Atlona

Atlona AT-DVI40SRS User manual

Atlona

Atlona AT-DVI50S User manual

Atlona

Atlona AT-HDF30SR User manual

Atlona

Atlona ATAEX702PSK User manual

Atlona

Atlona AT-HDMI40SRS User manual

Atlona

Atlona AT-UHD-EX-100CE-RX-PSE User manual

Atlona

Atlona AT-RGB45SR User manual

Atlona

Atlona AT-VGA-RS300SRS User manual

Atlona

Atlona AT-HD-IR40SR User manual

Atlona

Atlona AT-DVI60SRS User manual

Atlona

Atlona AT-IR300SRS User manual

Popular Extender manuals by other brands

SY HDBT-60T installation guide

Appsys ProAudio

Appsys ProAudio ADX-16 user manual

IDK

IDK OPF-TH1000-A user guide

Enable-IT

Enable-IT 824WP quick start guide

Worx

Worx Landroid RadioLink WA0864 Get started

TP-Link

TP-Link TL-WA730RE user guide

Camplex

Camplex CMX-HDMI-SFPL user manual

SC&T

SC&T HE03-4K user manual

Marmitek

Marmitek MegaView70 user manual

Samsung

Samsung SCS-26UC4 user guide

Foxun

Foxun SX-GES24 operating instructions

MuxLab

MuxLab 500771 Operation manual

foxunhd

foxunhd SX-AEX01 operating instructions

TERK Technologies

TERK Technologies LFIRX2 owner's manual

Devolo

Devolo Audio Extender supplementary guide

Edimax

Edimax EW-7438RPn V2 instructions

Shinybow USA

Shinybow USA SB-6335T5 instruction manual

SECO-LARM

SECO-LARM ENFORCER EVT-PB1-V1TGQ installation manual
