1
USER
INSTRUCTION
MANUAL
ATLI Cam App Dashboard Control
Model No. T-100, T-100 Lite
This instruction manual covers the in-app dashboard control for firmware version
4.1.0 or higher.
Please refer to INSTALLATION AND SETUP PROCEDURE for more
information on how to install and connect the camera.
2
Content Index
Dashboard ......................................................................................................... 3
Magnifier ........................................................................................................... 4
EV ..................................................................................................................... 4
Auto/Manual/Preset ........................................................................................... 5
Preset ............................................................................................................. 5
Add Presets ....................................................................................................... 6
System Settings ................................................................................................ 7
WLAN ............................................................................................................. 7
Memory Card .................................................................................................. 9
Advanced ..................................................................................................... 10
Remote Support ........................................................................................ 10
Time Zone ................................................................................................. 10
Built-in FTP Server .................................................................................... 11
FTP Auto Sync .......................................................................................... 12
About ......................................................................................................... 12
Time Lapse Mode ........................................................................................... 13
Output .......................................................................................................... 13
Orientation .................................................................................................... 14
Power Saving ............................................................................................... 14
Grid ............................................................................................................... 15
Time Stamp .................................................................................................. 15
Schedule ...................................................................................................... 16
Occurrence: Once ..................................................................................... 16
Occurrence: Daily ...................................................................................... 17
Occurrence: Weekly .................................................................................. 18
Realtime Playback (Live Preview) ................................................................ 19
Change settings on the fly ............................................................................ 20
Time Slice ..................................................................................................... 21
Photo Mode ..................................................................................................... 22
Video Mode ..................................................................................................... 23
Album .............................................................................................................. 24
3
Dashboard
Once the camera is connected to the app, access the dashboard to manage and operate the
camera.
Icon
Description
More feature
HDR
Auto/Manual/Preset
Home
Battery Status
Charging
Memory Card Status
available storage | available frame
Rotate
Record/Take photo
System Settings
Album
4
Magnifier
EV
EV
-4~ 4
Long-press on the screen to activate
magnifier.
Drag the magnifier and move around.
EV is disabled when both ISO and Shutter
Speed are set to manual.
Tap on the lock button to lock the focus in
place.
5
Auto/Manual/Preset
Preset
The presets come with a default interval that is recommended.
*T-100 Lite does not support Infrared mode.
Preset
Interval (s)
Cloud
3
City Night
3
Flower
10
Star
10
Sun
2
Preset
Mode
Infrared
Common/Fantasy1/Fantasy2/Fantasy3/Custom
Shutter
Speed
1/20K,1/10K,1/5K,1/2.5K,
1/1000,1/500,1/250,1/125,1/60,
1/30,1/25,1/15,1/8,1/4,1/2,1,1.4
ISO
100~ 4000
White
Balance
2500~ 10000
Sharpness
-10~10
Saturation
-30~ 30
Contrast
-5~ 5
Hue
-20~ 20
• Auto [ ]: The camera will choose the
optimized settings.
• Manual [ ]: Customize the following
settings.
• Drag the magnifier and move around.
*Manual settings are unavailable
in the preset scenes.
6
Add Presets
Add custom presets with personalized settings.
• To create a custom scene with
personalized settings, click on
Add Scene [ ] to proceed.
• Enter a name and choose an icon
for the new scene.
• Custom scene can be located
under preset menu.
• Tap on the icon to edit or delete
the custom scene.
7
System Settings
Manage the following settings of the camera.
WLAN
To enable internet access for the camera, connect it to a local Wi-Fi network via WLAN.
Setup
System Settings > WLAN > Select a Wi-Fi SSID > Enter Wi-Fi Password > Wi-Fi name turns blue
8
• The default IP Setting mode is DHCP.
• This enables the camera to obtain an
IP and the corresponding network
settings from the Wi-Fi router.
• However, the camera IP and other
network settings can be assigned
manually by changing the IP Setting
mode to Static as shown in the Wi-Fi
configuration.
9
Memory Card
Memory Card shows the status of the microSD card.
Formatting memory card
Back up all important data before formatting
a microSD card.
* Formatting a micorSD card can help to
solve corrupted files issues, but it cannot fix
a damaged SD card.
If formatting does not resolve the SD card
related problems, please retry with another
SD card.
Once the memory card reaches its capacity,
the camera will stop recording and save the
files automatically.
10
Advanced
The Advanced section provides additional features or supports to the camera.
Remote Support
Enabling Remote Support will authorize the ATLI technical team to remotely access the
camera and conduct a thorough inspection of the camera status, settings, and operation.
Setup
1. Turn on Remote Support in Advanced.
2. Connect the camera to a local Wi-Fi network which has internet connection.
3. Connect the camera to a power source to make sure the camera stays online.
In order to ensure a good connection, the camera should be placed near the Wi-Fi router.
*Remote Support will be disabled automatically by restarting/rebooting the camera.
Time Zone
The time zone setting sets the camera internal clock to align with your local time zone.
It is important to set this correctly as the camera clock is used for all camera activities that
involves time, such as timestamp, schedule, file storage time, etc.
The default Time Zone is set to “Auto” which assigns the time zone automatically based on the
current location.
