ATEN CS782DP User manual

CS782DP

2-Port USB DisplayPort

KVM Switch

User Manual

ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All

rights reserved. All other trademarks are the property of their respective owners.

Part No. PAPE-1375-AT5G Released: 04/2022

- 2 -

Compliance Statements

FEDERAL COMMUNICATIONS COMMISSION

INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

The device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

FCC Caution

Any changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate this equipment.

Warning

Operation of this equipment in a residential environment could

cause radio interference.

Achtung

Der Gebrauch dieses Geräts in Wohnumgebung kann

Funkstörungen verursachen.

KCC Statement

- 3 -

Industry Canada Statement

This Class A digital apparatus complies with Canadian ICES-

003.

RoHS

This product is RoHS compliant.

- 4 -

CS782DP User Manual

Online Registration

Telephone Support

Technical Support

For international online technical support – including

troubleshooting, documentation, and software updates:

http://eservice.aten.com

For North American technical support:

International http://eservice.aten.com

International 886-2-8692-6959

China 86-400-810-0-810

Japan 81-3-5615-5811

Korea 82-2-467-6789

North America 1-888-999-ATEN ext 4988

1-949-428-1111

Email Support support@aten-usa.com

Online

Technical

Support

Troubleshooting

Documentation

Software Updates

http://support.aten.com

Telephone Support 1-888-999-ATEN ext 4998

- 5 -

Package Contents

Check to make sure that all the components are in working order.

If you encounter any problem, please contact your dealer.

The CS782DP 2-Port USB DisplayPort KVM Switch package

contains the following items:

1 CS782DP 2-Port USB DisplayPort KVM Switch

2 DisplayPort cables

2 USB cables

2 audio cables

1 remote port selector

1 user instructions

Note:

Read this manual thoroughly and follow the installation and

operation procedures carefully to prevent any damage to the

unit or any connected devices.

The product may be updated, with features and functions

added, improved or removed since the release of this

manual. For an up-to-date user manual, visit http://

www.aten.com/global/en/

- 6 -

Overview

The CS782DP takes a giant step forward from prior digital-

interfaced KVM models by offering DisplayPort functionality,

USB 2.0 peripheral sharing (via a USB hub attached to the USB

mouse port), a rich bass experience for 2.1 surround systems and

a firmware upgrade function that allows you to keep up with

latest available versions.

Supporting the latest DisplayPort technology, for premium

image quality and vivid high-definition sound for music, movies

and games.

Another new feature of the CS782DP is the implementation of a

remote port selector. This means that you can now control port

switching from the desktop while the switch itself can be placed

in a convenient, out-of-the-way location. Also, in addition to

new hotkeys, the CS782DP offers the latest mouse port-

switching function – simply double-click on the scroll wheel of

a USB mouse to change ports.

Finally, the CS782DP's new Power on detection feature means

that if one of the computers is powered off, the CS782DP will

automatically switch to the other computer if powered-on.

Featuring an unbeatable combination of DisplayPort

functionality, USB 2.0 peripheral sharing convenience and

enhanced user-friendly operations, the CS782DP allows users to

keep ahead of the latest innovations in desktop multimedia and

productivity.

- 7 -

Features

One DisplayPort video console controls two USB computers

DisplayPort 1.2

compliant, HDCP compliant

Computer selection via remote port selector, hotkeys, and

USB mouse

Multiplatform support – Windows, Mac, Sun, Linux

Supports MST (Multi-Stream Transport)

, enabling multiple

monitors to be used via a single DisplayPort connector

Compatible with widescreen LCD monitors

Power on detection – if either of the computers is powered

off, the CS782DP will automatically switch to the other

computer

Audio-enabled – full bass response provides a rich

experience for 2.1 channel surround sound systems

Supports HD Audio

through DisplayPort playback

Independent switching of the KVM and Audio focus

allows

convenient multi-tasking

Supports multimedia keyboards

Supports wireless keyboards and mice

Console mouse port emulation / bypass feature supports

most mouse drivers and multifunction mice

Mac/Sun keyboard support and emulation

USB 2.0 mouse port can be used for USB hub and USB

peripheral sharing

Bus-Powered

Firmware upgradable

- 8 -

Note: 1. For DisplayPort compliant display device, make sure to

configure the device setting to be compatible with

DisplayPort 1.2 to avoid compatibility issue.

2. Mouse port switching is only supported under mouse

emulation mode and by USB 3-key wheel mice.

3. MST (Multi-Stream Transport) requires either

monitors capable of DisplayPort 1.2 daisy-chaining, or

use of a powered DisplayPort MST Hub. A

DisplayPort v1.1a display can be the last display in a

DisplayPort v1.2 chain. The PC source must be

DisplayPort 1.2 compliant.

4. HD audio through DisplayPort cannot be switched

independently.

5. 1. PC keyboard combinations emulate Mac / Sun

keyboards. 2. Mac / Sun keyboards work only with

their own computers.

6. This feature may require an extra power adapter to be

connected to the USB hub and that the CS782DP’s

Mouse Emulation Mode be disabled.

- 9 -

System Requirements

Console

A DisplayPort monitor capable of the highest resolution that

you will be using on any computer in the installation

A USB Keyboard and a USB Mouse

Speakers (optional)

Computers

The following equipment must be installed on each computer

that is to be connected to the system:

A DisplayPort video port

USB Type-A port

Speaker port (optional)

Cables

Two DisplayPort cables, two USB 2.0 cables and two 3.5mm

audio jack cables included with the CS782DP package

Operating Systems

Supported operating systems are shown in the table, below:

OS Version

Windows 2000 / XP / Vista / 7 / 8 / 8.1 / 10

Linux RedHat 6.0 or later

SuSE 8.2 or later

Mandriva (Mandrake) 9.0 or later

UNIX AIX 4.3 or later

FreeBSD 3.51 or later

Sun Solaris 9 or later

Novell Netware 5.0 or later

Mac OS 9 or later

DOS 6.2 or later

- 10 -

Components

CS782DP

No. Component Description

1 console audio

port

Your console speakers plug in here.

2 console monitor

port

Your console DisplayPort monitor

plugs in here.

3 console keyboard

port

Your console USB keyboard plugs in

here.

4 console mouse

port

Your console USB mouse plugs in

here.

5 remote port

selector jack

The remote port selector plugs in here.

PC2 PC1

879

Computer Port 2

978

Computer Port 1

5 2 4

Console Port
