AT&T E2520 User manual
Quick Start Guide
2.4 GHz Cordless
Speakerphone E2520
with Caller ID & Call Waiting
E2520 QSG.qxd 07/19/2004 3:21 PM Page 1
Installation and setup
Connect the base and install batteries as shown below. After installation, place the
handset in the base and allow the batteries to charge for 8 hours before use. You can
keep the batteries charged by returning the handset to the base after each use.
Press coin into slot on
base of handset to
release latch, then
remove battery cover.
Insert supplied
batteries.
Place handset in base to charge
for 8 hours before first use.
Rotate antenna to fully upright
position.
Insert top
tab first.
To replace battery cover
Press down to
click in place.
Caution: Use only the supplied NiCd battery or
AT&T model 2AA NiMH replacement battery
(SKU 26820). Do not use alkaline batteries.
Plug power cord
transformer into
electrical outlet.
Plug long tele-
phone line cord
into telephone jack.
Route cords through
slot in base.
E2520 QSG.qxd 07/19/2004 3:21 PM Page 2
HANDSET 1
REDIAL MEMMENU
Off/Clear
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous
menu, or exit the menu display.
Quick reference guide
Speaker
Press to activate handset speaker-
phone. Press again to switch call back
to earpiece.
Softkeys
Press a softkey to select a menu item
displayed just above the key.
Phone/Flash
Press to begin a call, then dial a number.
During a call, press to receive an incoming
call, if Call Waiting is activated .
Sound Select
Press to customize the sound at the ear-
piece for clear conversations.
Handset
Xfer/Intercom
Press to transfer a call or initiate an
intercom conversation .
Redial Log Phonebook
Screen menus
Item 1 Item 2 Item 3
Menus
Main Menu
Calls Log
Handset Settings
Set Time
Clock Mode
Register
Base settings from handset
Handset Settings
Ringer Volume
Ringer Melody
Low Batt Tone
Range Tone
Keypad Tone
Contrast
Language
Base Settings from
handset
Tone/Pulse
Ringer Melody
E2520 QSG.qxd 07/19/2004 3:21 PM Page 3
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 06/04.
96-005768-010-000
Quick reference guide
Telephone function keys
INTERCOM ............
Press to transfer a call or initiate an intercom conversation.
FLASH ....................During a call, press to receive an incoming call, if
Call Waiting is activated.
VOLUME ................Press to adjust speakerphone listening volume.
MUTE ......................Press to silence microphone; press again to resume.
SPEAKERPHONE....
Press to turn speakerphone on or off (answer or end a call).
REDIAL ..................Press to redial the last number.
HOLD ......................
Press to hold a call, press again to release hold.
Base/Speakerphone
Telephone
function keys
Swivel antenna fully
upright for best results.
E2520 QSG.qxd 07/19/2004 3:21 PM Page 4
