1. ASUS Control Panel

The ASUS Control Panel is a program that allows you to adjust certain

features on your computer environment like the desktop color, screen

resolution and refresh rates.

1.1 NVIDIA

graphics card series

After installing the display drivers, locate the ASUS Control Panel icon on

the Windows taskbar. TheASUS Control Panel contains a menu of

shortcuts for commonly used tasks and utilities.

To launch theASUS Control Panel, click the ASUS Control Panel icon on

the Windows taskbar.

ASUS Control Panel icon

Windows

Taskbar

ASUS Control Panel icon

1.1.1 Setting screen resolution

The ASUS Control panel menu includes a list of shortcuts for easy screen

resolution setting.

To change the screen resolution:

1. From the ASUS Control Panel menu, click one of the available screen

resolutions.

2. When prompted, click OK to

apply settings or Cancel to

abort.

ASUS Control Panel icon

Screen resolution

setting shortcut

The setting does not take

effect if the progress bar

elapses.

Your computer screen may flicker while adjusting to the new setting.

1.1.2 Refresh Rate

This item changes the refresh rate of the current screen resolution. A

refresh rate is the number of times a display image is repainted or redrawn

per second. The refresh rate is expressed in Hertz (Hz), for example, a

refresh rate of 75Hz means the image is refreshed 75 times per second.

Make sure your monitor supports the refresh rate you choose.

Selecting a refresh rate beyond your monitor’s specification may

damage it. Press ESC to restore your original settings.

To change the refresh rate:

1. From theASUS control panel menu, click Refresh Rate and select a

setting from the list.

2. When prompted, click OK to

apply settings or Cancel to

abort.

The setting does not take

effect if the progress bar

elapses.

1.1.3 Windows Display Properties

This item runs the Windows Display Properties dialog box that allows you

to:

• change the Windows theme

• enhance the Windows desktop

• select a screen saver

• adjust the monitor power settings

• change the Windows appearance

• adjust screen resolution

To launch the Windows Display Properties dialog box, click the Windows

Display Properties menu item from the ASUS Control Panel.

ASUS Control Panel icon

This manual suits for next models

Table of contents

Asus A7000 Mounting instructions

Popular Video Card manuals by other brands
