Asus RT-AC85P User manual

Quick Start Guide

RT-AC85PRT-AC85P

Wireless-AC2400 Dual Band Gigabit RouterWireless-AC2400 Dual Band Gigabit Router

WEU15674a / First Edition / May 2020

Table of contentsTable of contents

Package contents ........................................................................3

A quick look at RT-AC85P .........................................................3

Position your wireless router...................................................4

Preparing your modem.............................................................5

Setting up your Router..............................................................6

A. Wired connection .............................................................................6

B. Wireless connection.........................................................................7

FAQ ...................................................................................................9

Networks Global Hotline Information .................................91

English

Dansk

Nederlands

Suomi

Français

Deutsch

Ελληνικά

Italiano

Norsk

Português

Español

Svenska

This QSG contains these languages:

English

A quick look at RT-AC85PA quick look at RT-AC85P

Package contentsPackage contents

RT-AC85P Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

LAN 1~4 LEDs WPS button

WAN LED Power (DC-IN) port

2.4GHz LED Power button

5GHz LED USB 3.0 port

Power LED WAN (Internet) port

Reset button LAN 1 ~ 4 ports

English

Position your wireless routerPosition your wireless router

For optimal wireless transmission between the wireless router and connected

wireless devices, ensure that you:

• Place the wireless router in a centralized area for a maximum wireless coverage

for the network devices.

• Keep the wireless router away from metal obstructions and away from direct

sunlight.

• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,

2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,

heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other

industrial equipment to prevent signal interference or loss.

• Always update to the latest rmware. Visit the ASUS website at

http://www.asus.com to get the latest rmware updates.

• To ensure the best wireless signal, orient the four detachable antennas as shown

in the drawing below.

NOTES:

• Use only the adapter that came with your package. Using other adapters

may damage the device.

• Specications:

DC Power adapter DC Output: +12V with 2.5A current

Operating Temperature 0~40oC Storage 0~70oC

Operating Humidity 50~90% Storage 20~90%

English

Preparing your modemPreparing your modem

1. Unplug the power cable/DSL modem. If it has a

battery backup, remove the battery.

NOTE: If you are using DSL for Internet, you

will need your username/password from your

Internet Service Provider (ISP) to properly

congure the router.

2. Connect your modem to the router with the

bundled network cable.

3. Power on your cable/DSL modem.

4. Check your cable/DSL modem LED lights to ensure

the connection is active.

Unplug

English

Setting up your RouterSetting up your Router

You can set up your Router via wired or wireless connection.

A. Wired connection

1. Plug your router into a power outlet and power it on. Connect the network

cable from your computer to a LAN port on your router.

2. The web GUI launches automatically when you open a web browser. If it does

not auto-launch, enter http://router.asus.com.

3. Set up a password for your router to prevent unauthorized access.

Internet

Modem

WAN

LAN

Laptop

English

B. Wireless connection

1. Plug your router into a power outlet and power it on.

2. Connect to the network with SSID shown on the product label on the back side

of the router. For better network security, change to a unique SSID and assign

a password.

ASUS router

2.4G Wi-Fi Name (SSID): ASUS_XX_2G

5G Wi-Fi Name (SSID): ASUS_XX_5G

* XX refers to the last two digits of 2.4GHz

MAC address. You can nd it on the label

on the back of your router.

Laptop

Tablet

Smart phone

Internet

Modem

WAN

English

3. You can choose either the web GUI or ASUS Router app to set up your router.

a. Web GUI Setup

•

Once connected, the web GUI launches automatically when you open a

web browser. If it does not auto-launch, enter http://router.asus.com.

•

Set up a password for your router to prevent unauthorized access.

b. App Setup

Download ASUS Router App to set up your router via your mobile devices.

•

Turn on Wi-Fi on your mobile devices and connect to your router’s

network.

•

Follow ASUS Router App setup instructions to complete the setup.

ASUS Router

ASUS

Router

English

FAQFAQ

1. Where can I nd more information about the wireless router?

• Online FAQ site: https://www.asus.com/support/faq

• Technical support site: https://www.asus.com/support

• Customer hotline: refer to the Support Hotline section in this Quick Start

Guide

• You can get the user manual online at https://www.asus.com/support

Remembering your wireless router settings

• Remember your wireless settings as you complete the router setup.

Router Name: Password:

2.4 GHz network SSID: Password:

5GHz network SSID: Password:

Dansk

Et hurtigt kik påEt hurtigt kik på

Pakkens indholdPakkens indhold

RT-AC85P AC adapter

Netværkskabel (RJ-45) Kvikstartguide

LAN 1~4 LED WPS knap

WAN LED Strøm (DC-IN) port

2.4GHz LED Afbryderknappen

5GHz LED USB 3.0 port

Strøm LED WAN (Internet) porte

Nulstillingsknap LAN 1~4 porte
