Astria Fireplaces ParisLights43ZEN Installation instructions

PFS

Installation and Operation Instructions

Unvented (Vent-Free) Gas Fireplace

Models

P/N 126875-01 Rev. G 12/2016

REPORT NO. F11-054

ParisLights43ZEP

ParisLights43ZEN

INSTALLER: Leave this manual with the appliance.

CONSUMER: Retain this manual for future reference.

This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where

not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate.

This appliance is not convertible for use with other gases.

This is an unvented gas-ﬁred heater. It uses air (oxygen) from the room in which it is installed. Provisions

for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation

section on page 5 of this manual.

WARNING: If the information in these instructions is not followed exactly, a ﬁre or explosion may result

causing property damage, personal injury or death.

—Do not store or use gasoline or other ﬂammable vapors and liquids in the vicinity of this or any other

appliance.

—WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Leave the building immediately

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

—Installation and service must be performed by a qualiﬁed installer, service agency or the gas supplier.

P126875-01

Astria.US.com 126875-01_G

Thank you for your purchase. We appreciate your

business!

Please carefully read and follow all instructions in this manual. Pay

special attention to all warnings and safety information.

Following these safety, care, and operation instructions will help

ensure many years of dependable and enjoyable service from your

ﬁreplace.

Please read and understand these instructions before installing

or operating.

TABLE OF CONTENTS

SAFETY

WARNING: Improper installation, adjustment,

alteration, service or maintenance can cause injury

or property damage. Refer to this manual for correct

installation and operational procedures. For assis-

tance or additional information consult a qualiﬁed

installer, service agency or the gas supplier.

WARNING: This is an unvented gas-ﬁred heater.

It uses air (oxygen) from the room in which it is

installed. Provisions for adequate combustion and

ventilation air must be provided. Refer to Air for

Combustion and Ventilation section on page 5 of

this manual.

This appliance may be installed in an aftermarket,*

permanently located, manufactured (mobile) home,

where not prohibited by local codes.

This appliance is only for use with the type of gas

indicated on the rating plate. This appliance is not

convertible for use with other gases.

* Aftermarket: Completion of sale, not for purpose of resale,

from the manufacturer

WARNING: This product contains and/or generates

chemicals known to the State of California to cause

cancer or birth defects or other reproductive harm.

IMPORTANT: Read this owner’s manual carefully and

completely before trying to assemble, operate or

service this heater. Improper use of this heater can

cause serious injury or death from burns, ﬁre, explo-

sion,electricalshockandcarbonmonoxidepoisoning.

DANGER: Carbon monoxide poisoning may lead

to death!

Carbon Monoxide Poisoning: Early signs of carbon monoxide poison-

ing resemble the ﬂu, with headaches, dizziness or nausea. If you have

these signs, the heater may not be working properly. Get fresh air at

once! Have heater serviced. Some people are more affected by carbon

monoxide than others. These include pregnant women, people with

heart or lung disease or anemia, those under the inﬂuence of alcohol

and those at high altitudes.

Natural and Propane/LP Gas: Natural and propane/LP gases are

odorless. An odor-making agent is added to the gas. The odor helps

you detect a gas leak. However, the odor added to the gas can fade.

Gas may be present even though no odor exists.

Make certain you read and understand all warnings. Keep this manual

for reference. It is your guide to safe and proper operation of this

heater.

WARNING: Any change to this heater or its controls

can be dangerous.

WARNING: Do not allow fans to blow directly into the

ﬁreplace. Avoid any drafts that alter burner ﬂame pat-

terns.Ceilingfanscancreatedraftsthatalterburnerﬂame

patterns. Altered burner patterns can cause sooting.

Safety.............................................................................................2

Local Codes ...................................................................................3

Requirements for the Commonwealth of Massachusetts............... 4

Product Identiﬁcation.....................................................................4

Product Features............................................................................5

Air for Combustion and Ventilation ................................................5

Installation .....................................................................................7

Gas Control Module System ........................................................15

Remote Control Operation ...........................................................16

Operating Fireplace ......................................................................19

Cleaning and Maintenance ..........................................................20

Inspecting Burners ......................................................................21

Speciﬁcations...............................................................................21

Wiring Diagram............................................................................22

Troubleshooting ...........................................................................23

Parts ............................................................................................26

Replacement Parts.......................................................................30

Service Hints................................................................................30

Technical Service .........................................................................30

Accessories..................................................................................30

Warranty ......................................................................................31

Astria.US.com

126875-01_G 3

SAFETY Continued

WARNING: Do not use a blower insert, heat ex-

changer insert or other accessory not approved for

use with this heater.

Due to high temperatures, the appliance should be

located out of trafﬁc and away from furniture and

draperies.

Do not place clothing or other ﬂammable material

on or near the appliance. Never place any objects

on the heater.

Fireplace become very hot when running ﬁreplace.

Keep children and adults away from hot surfaces to

avoid burns or clothing ignition. Fireplace will remain

hot for a time after shutdown. Allow surfaces to cool

before touching.

Carefully supervise young children when they are

in the room with ﬁreplace. When using the remote

control, keep selector switch in the OFF position to

prevent children from turning on burners with remote.

Keep the appliance area clear and free from combus-

tible materials, gasoline and other ﬂammable vapors

and liquids.

1. This appliance is only for use with type of gas indicated on rating

plate. This appliance is not convertible for use with other gases.

2. Do not place propane/LP supply tank(s) inside any structure.

Locate propane/LP supply tank(s) outdoors (propane/LP only).

3. If you smell gas

•shut off gas supply

•do not try to light any appliance

•do not touch any electrical switch; do not use any phone in your

building

•leave the building immediately

•immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions

•if you cannot reach your gas supplier, call the ﬁre department

4. This ﬁreplace shall not be installed in a bedroom or bathroom.

5. Do not use this ﬁreplace as a wood-burning ﬁreplace. Use only

the logs provided with the ﬁreplace.

6. Do not add extra logs or ornaments such as pine cones, vermicu-

lite, or rock wool. Using these added items can cause sooting.

Do not add lava rock around base. Rock and debris could fall into

the control area of ﬁreplace.

7. This ﬁreplace is designed to be smokeless. If logs ever appear to

smoke, turn off ﬁreplace and call a qualiﬁed service person.

Note: During initial operation, slight smoking could occur due to

log curing and ﬁreplace burning manufacturing residues.

8. To prevent the creation of soot, follow the instructions in Cleaning

and Maintenance, page 20.

9. Before using furniture polish, wax, carpet cleaner, or similar

products, turn heater off. If heated, the vapors from these prod-

ucts may create a white powder residue within burner box or on

adjacent walls or furniture.

10.This ﬁreplace needs fresh air ventilation to run properly. This

ﬁreplace has an Oxygen Depletion Sensing (ODS) safety shutoff

system. The ODS shuts down the ﬁreplace if not enough fresh

air is available. See Air for Combustion and Ventilation, page 5.

If ﬁreplace keeps shutting off, see Troubleshooting, page 23.

11.Do not run ﬁreplace

•where ﬂammable liquids or vapors are used or stored.

•under dusty conditions.

12.Do not use this ﬁreplace to cook food or burn paper or other

objects.

13.Do not use ﬁreplace if any part has been under water. Immediately

call a qualiﬁed service technician to inspect the room ﬁreplace

and to replace any part of the control system and any gas control

which has been under water.

14.Turn off and unplug ﬁreplace and let cool before servicing. Only

a qualiﬁed service person should service and repair ﬁreplace.

15.Operating ﬁreplace above elevations of 4,500 feet could cause

pilot outage.

16.To prevent performance problems, do not use propane/LP fuel

tank of less than 100 lbs. capacity (propane/LP only).

17.Provide adequate clearances around air openings.

18.The screen or any other part removed for servicing must be

replaced prior to operating this heater.

LOCAL CODES

Install and use ﬁreplace with care. Follow all local codes. In the

absence of local codes, use the latest edition of The National Fuel

Gas Code ANSI Z223.1/NFPA 54*.

*Available from:

American National Standards Institute, Inc.

25 West 43rd Street, 4th ﬂoor

New York, NY 10036

National Fire Protection Association, Inc.

1 Batterymarch Park

Quincy, MA 02169-7471

Astria.US.com 126875-01_G

PRODUCT IDENTIFICATION

Figure 1 - Vent Free ParisLights43 Fireplace

Pebble Pan

Nailing Flange

Access Door

Top Spacers

Left Side

Right Side

Front

State of Massachusetts: The installation must be made by a

licensed plumber or gas ﬁtter in the Commonwealth of Mas-

sachusetts.

Sellers of unvented propane or natural gas-ﬁred supplemental

room heaters shall provide to each purchaser a copy of 527 CMR

30 upon sale of the unit.

Vent-free gas products are prohibited for bedroom and bathroom

installation in the Commonwealth of Massachusetts.

LOCAL CODES Continued COMMONWEALTH OF MASSACHUSETTS REQUIRE-

MENTS

These appliances are approved for installation in the US state of Mas-

sachusetts if the following additional requirements are met:

• Un-vented Room Heaters shall be installed in accordance with

527 CMR 30.

• Installation and repair must be done by a plumber or gas ﬁtter

licensed in the Commonwealth of Massachusetts.

• The ﬂexible gas line connector used shall not exceed 36 inches

(92 centimeters) in length.

• The individual manual shut-off must be a T-handle type valve.

• Unvented appliances may NOT be installed in bedrooms or bath-

rooms.

• A working smoke detector must be installed in the area where

vent-free appliances are installed.

• Seller of unvented propane or natural gas-ﬁred supplemental

room heaters shall provide to each purchaser a copy of 527 CMR

30 upon sale of the unit.

Astria.US.com

126875-01_G 5

AIR FOR COMBUSTION AND VENTILATION

PRODUCT FEATURES

WARNING: This heater shall not be installed in a

room or space unless the required volume of indoor

combustion air is provided by the method described

in the National Fuel Gas Code, ANSI Z223.1/NFPA 54,

the International Fuel Gas Code, or applicable local

codes. Read thefollowing instructions to insure proper

fresh air for this and other fuel-burning appliances

in your home.

Today’s homes are built more energy efﬁcient than ever. New materials,

increased insulation and new construction methods help reduce heat

loss in homes. Home owners weather strip and caulk around windows

and doors to keep the cold air out and the warm air in. During heating

months, home owners want their homes as airtight as possible.

While it is good to make your home energy efﬁcient, your home

needs to breathe. Fresh air must enter your home. All fuel-burning

appliances need fresh air for proper combustion and ventilation.

Exhaust fans, ﬁreplaces, clothes dryers and fuel burning appliances

draw air from the house to operate. You must provide adequate fresh

air for these appliances. This will insure proper venting of vented

fuel-burning appliances.

PROVIDING ADEQUATE VENTILATION

The following are excerpts from National Fuel Gas Code, ANSI Z223.1/

NFPA 54, Air for Combustion and Ventilation.

All spaces in homes fall into one of the three following ventilation

classiﬁcations:

1. Unusually Tight Construction

2. Unconﬁned Space

3. Conﬁned Space

The information on pages 5 through 6 will help you classify your

space and provide adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and windows may provide enough

fresh air for combustion and ventilation. However, in buildings of

unusually tight construction, you must provide additional fresh air.

Unusually tight construction is deﬁned as construction where:

a.walls and ceilings exposed to the outside atmosphere have a

continuous water vapor retarder with a rating of one perm (6 x

10-11 kg per pa-sec-m2) or less with openings gasketed or sealed

and

b.weather stripping has been added on openable windows and

doors and

c. caulking or sealants are applied to areas such as joints around

window and door frames, between sole plates and ﬂoors, be-

tween wall-ceiling joints, between wall panels, at penetrations

for plumbing, electrical and gas lines and at other openings.

If your home meets all of the three criteria above, you must provide

additional fresh air. See Ventilation Air From Outdoors, page 6.

If your home does not meet all of the three criteria above, proceed to

Determining Fresh-Air Flow For Heater Location, page 6.

Conﬁned and Unconﬁned Space

The National Fuel Gas Code, ANSI Z223.1/NFPA 54 deﬁnes a con-

ﬁned space as a space whose volume is less than 50 cubic feet per

1,000 Btu per hour (4.8 m3per kw) of the aggregate input rating of

all appliances installed in that space and an unconﬁned space as a

space whose volume is not less than 50 cubic feet per 1,000 Btu per

hour (4.8 m3per kw) of the aggregate input rating of all appliances

installed in that space. Rooms communicating directly with the space

in which the appliances are installed*, through openings not furnished

with doors, are considered a part of the unconﬁned space.

* Adjoining rooms are communicating only if there are doorless

passageways or ventilation grills between them.

OPERATION

This vent-free ﬁreplace is clean burning. It requires no outside

venting. There is no heat loss out a vent or up a chimney. Heat is

generated by both realistic ﬂames. This heater is designed for vent-

free operation. It has been tested and approved to ANSI Z21.11.2

standard for unvented heaters. State and local codes in some areas

prohibit the use of vent-free heaters.

SAFETY DEVICE

This ﬁreplace has a pilot with an Oxygen Depletion Sensing (ODS)

safety shutoff system. The ODS/pilot is a required feature for vent-free

room heaters. The ODS/pilot system shuts off the ﬁreplace if there is

not enough fresh air.

Astria.US.com 126875-01_G

DETERMINING FRESH-AIR FLOW FOR FIREPLACE LOCATION

Determining if You Have a Conﬁned or Unconﬁned Space

Use this work sheet to determine if you have a conﬁned or uncon-

ﬁned space.

Space: Includes the room in which you will install ﬁreplace plus any

adjoining rooms with doorless passageways or ventilation grills

between the rooms.

1. Determine the volume of the space (length x width x height).

Length x Width x Height =__________cu. ft. (volume of space)

Example: Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling

height) = 2,560 cu. ft. (volume of space)

If additional ventilation to adjoining room is supplied with grills

or openings, add the volume of these rooms to the total volume

of the space.

2. Multiply the space volume by 20 to determine the maximum Btu/

Hr the space can support.

_______ (volume of space) x 20 = (Maximum Btu/Hr the space

can support)

Example: 2,560 cu. ft. (volume of space) x 20 = 51,200 (maximum

Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

Vent-free ﬁreplace ________Btu/Hr

Gas water heater* ________Btu/Hr

Gas furnace ________Btu/Hr

Vented gas heater ________Btu/Hr

Gas ﬁreplace logs ________Btu/Hr

Other gas appliances*+ ____Btu/Hr

Total =_______Btu/Hr

* Do not include direct-vent gas appliances. Direct-vent draws

combustion air from the outdoors and vents to the outdoors.

Example:

Gas water heater 40,000 Btu/Hr

Vent-free ﬁreplace + 33,000 Btu/Hr

Total = 73,000 Btu/Hr

4. Compare the maximum Btu/Hr the space can support with the actual

amount of Btu/Hr used.

______ Btu/Hr (maximum the space can support)

______ Btu/Hr (actual amount of Btu/Hr used)

Example: 51,200 Btu/Hr (maximum the space can support)

73,000 Btu/Hr (actual amount of Btu/Hr used)

The space in the example is a conﬁned space because the actual Btu/

Hr used is more than the maximum Btu/Hr the space can support.

You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoining room. If the

extra space provides an unconﬁned space, remove door to adjoining

room or add ventilation grills between rooms. See Ventilation Air

From Inside Building.

B. Vent room directly to the outdoors. See Ventilation Air From

Outdoors.

C. Install a lower Btu/Hr ﬁreplace, if lower Btu/Hr size makes room

unconﬁned.

If the actual Btu/Hr used is less than the maximum Btu/Hr the

space can support, the space is an unconﬁned space. You will need

no additional fresh air ventilation.

WARNING: If the area in which the heater may be

operated does not meet the required volume for indoor

combustion air, combustion and ventilation air shall

be provided by one of the methods described in the

National Fuel Gas Code, ANSI Z223.1/NFPA 54, the

InternationalFuel Gas Code, or applicable local codes.

VENTILATION AIR

Ventilation Air From Inside Building

This fresh air would come from an adjoining unconﬁned space. When

ventilating to an adjoining unconﬁned space, you must provide two per-

manent openings: one within 12" of the ceiling and one within 12" of the

ﬂoor on the wall connecting the two spaces (see options 1 and 2, Figure

2). You can also remove door into adjoining room (see option 3, Figure

2). Follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Air for

Combustion and Ventilation for required size of ventilation grills or ducts.

AIR FOR COMBUSTION AND VENTILATION Continued

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation grills or ducts. You must

provide two permanent openings: one within 12" of the ceiling and one

within 12" of the ﬂoor. Connect these items directly to the outdoors or

spaces open to the outdoors. These spaces include attics and crawl

spaces. Follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Air for

Combustion and Ventilation for required size of ventilation grills or ducts.

IMPORTANT: Do not provide openings for inlet or outlet air into attic

if attic has a thermostat-controlled power vent. Heated air entering

the attic will activate the power vent.

Figure 3 - Ventilation Air from Outdoors

Figure 2 - Ventilation Air from Inside Building

Outlet

Air Ventilated

Attic

Outlet

Inlet

Air

Inlet Air Ventilated

Crawl Space

Crawl

Space

To Attic

Remove

Door into

Adjoining

Room,

Option

Ventilation Grills

Into Adjoining Room,

Option 2

Ventilation

Grills

Into Adjoining

Room,

Option 1

12"

Astria.US.com

126875-01_G 7

INSTALLATION

NOTICE: This heater is intended for use as supple-

mental heat. Use this heater along with your primary

heating system. Do not install this heater as your

primary heat source. If you have a central heating

system, you may run system’s circulating blower

while using heater. This will help circulate the heat

throughout the house.

WARNING: A qualiﬁed service person must install

ﬁreplace. Follow all local codes.

WARNING: Never install the ﬁreplace

• in a bedroom or bathroom

• in a recreational vehicle

• where curtains, furniture, clothing or other ﬂam-

mable objects are less than 36" from the front and

42" top of ﬁreplace. For side clearances see Figure

7, page 8

• in high trafﬁc areas

• in windy or drafty areas

CAUTION: This ﬁreplace creates warm air cur-

rents. These currents move heat to wall surfaces next

to ﬁreplace. Installing ﬁreplace next to vinyl or cloth

wall coverings or operating heater where impurities

(such as, but not limited to, tobacco smoke, aromatic

candles, cleaning ﬂuids, oil or kerosene lamps, etc.)

in the air exist, may discolor walls or cause odors.

Note: Standoff spacers are attached to the sides and top of your

ﬁreplace, these spacers can be placed directly against wall or fram-

ing materials.

Use the dimensions shown for rough openings to create the easiest

installation as shown in Figure 4.

IMPORTANT: Vent-free heaters add moisture to the air. Although this

is beneﬁcial, installing ﬁreplace in rooms without enough ventilation

air may cause mildew to form from too much moisture. See Air for

Combustion and Ventilation, page 5.

CHECK GAS TYPE

Use the correct gas type (natural or propane/LP) for your ﬁre-

place. If your gas supply is not correct, do not install ﬁreplace.

Call dealer where you bought ﬁreplace for proper type ﬁreplace.

WARNING: This appliance is equipped for either

natural gas or propane/LP gas but not both. Gas type

is indicated on the rating plate. Field conversion is

not permitted.

INSTALLATION CLEARANCES

WARNING: Maintain the minimum clearances. If

you can, provide greater clearances from ﬂoor, ceiling

and adjoining wall.

Carefully follow the instructions below. This will ensure safe instal-

lation.

CLEARANCES

Minimum clearances to combustibles for the ﬁreplace are as follows:

*Back and sides 1"

Perpendicular walls 8"

Floor (From bottom of Fireplace) 0"

Ceiling (From top of opening) 42"

Top of Standoffs 0"

* For back and sides of ﬁreplace, do not pack with insulation or

other materials.

FRAMING AND FINISHING

Choose framing application accordingly. Figure 4, page 8 shows

typical one sided framing. Figure 5, page 8 shows framing for

see-thru installation.Note: Kits F1029 and F1030 are required

for see-thru application (See upgrading ParisLights43 to see-thru

application, page 13).

All minimum clearances must be met. Steel framing may be neces-

sary or wood studs may be notched. Concrete board is provided for

facing around the ﬁreplace as shown in Figure 6, page 8.

If you are using a separate combustible mantel piece, refer to Figure

7, page 8 for proper installation height. You can install noncom-

bustible mantels at any height above the ﬁreplace.

NOTE: To avoid heat-related ﬁnish damage, we recommend

the use of high temperature paint (rated 175° F or higher) on

the underside of the mantel.

Astria.US.com 126875-01_G

INSTALLATION Continued

Figure 5 - Framing Clearances for See-Thru Application

53 1/4"

38"

*53 1/4"

38"

STUDS MOUNTED (FLAT)

INSIDE OF NAILING FLANGE

15 1/4"

MOUNTED INSIDE OF

NAILING FLANGE (FLAT)

FOR ONE SIDED

APPLICATION, STUDS

ARE NOT MOUNTED

TO THE REAR

OF NAILING FLANGES

17 1/2"

Figure 7 - Clearances for Combustible Mantels

Ref.

Mantel

Depth Ref.

Mantel

from Top

of Opening

1 12" A 24"

2 9" B 21"

3 6" C 18"

4 4" D 16"

5 2" E 14"

ABCDE

Wall

Supplied firebox

hood must be

used at all times.

Note: All vertical

measurements are

from top of fireplace

hood opening to

bottom of mantel

shelf.

Noncombustible

material ma

y project

off this sur

face above

the fireb

ox hood

Figure 6 - Installing Concrete Board

Concrete

Board

Combustible

Material May

Be Used

TOP VIEW

SAFE

ZONE

Perpendicular

Wall

33°

4" to Face Opening

Figure 4 - Framing Clearances for One Sided Application

*Please refer to overall ﬁreplace width (Figure 8, page 9) before

rough framing construction.

Astria.US.com

126875-01_G 9

1/2"

29 5/8"

16 3/8"

7 1/8"

1 7/8"

8 1/4"

44 1/8"1"

55 1/8"

52"

47"

16 1/2"11 3/4"

8 1/4"

5/8"

INSTALLATION Continued

Figure 8 - ParisLights43 Series Dimensions

Gas Line

Access

Gas Line

Access

Electrical

Outlet

Astria.US.com 126875-01_G

INSTALLATION Continued

Mantel Clearances for Built-In Installation

If placing mantel above built-in ﬁreplace, you must meet minimum

clearance between mantel shelf and top of ﬁreplace opening.

NOTICE: If yourinstallation doesnot meet theminimum

clearances shown, you must do one of the following:

• raise the mantel to an acceptable height

• remove the mantel

NOTICE: Surface temperatures of adjacent walls and

mantels become hot during operation. Walls and

mantels above the ﬁrebox may become hot to the

touch. If installed properly, these temperatures meet

the requirement of the national product standard. Fol-

low all minimum clearances shown in this manual.

ELECTRICAL WIRING INSTRUCTIONS

1. Remove electrical cover plate with bushing from left side of

ﬁreplace front by removing 2 sheet metal screws as shown in

Figure 9.

2. Slide power source wiring through electrical bushing opening

and electrical cover plate and make all necessary connections.

3. Slide all wiring connections in electrical housing as shown in

Figure 9.

4. Secure electrical cover plate with screws previously removed.

Note: Electrical housing and cover plate have sharp edges. Wear

protective gloves.

CHECK GAS TYPE

Use proper gas type for the ﬁreplace unit you are installing. If you

have conﬂicting gas types, do not install ﬁreplace. See retailer where

you purchased the ﬁreplace for proper ﬁreplace according to your

gas type.

INSTALLING GAS PIPING TO FIREPLACE LOCATION

WARNING: A qualiﬁed service person must con-

nect ﬁreplace to gas supply. Follow all local codes.

CAUTION: Never connect propane/LP ﬁreplace di-

rectly to the propane/LP supply. This ﬁreplace requires

an external regulator (not supplied). Install the external

regulator between the ﬁreplace and propane/LP supply.

WARNING: Never connect natural gas ﬁreplace

to private (non-utility) gas wells. This gas is com-

monly known as wellhead gas.

Installation Items Needed

Before installing ﬁreplace, make sure you have the items listed below.

• external regulator for propane/LP unit only (supplied by installer)

• piping (check local codes)

• sealant (resistant to propane/LP gas)

• equipment shutoff valve *

• test gauge connection *

• sediment trap (optional)

• tee joint

• pipe wrench

• approved ﬂexible gas line with gas connector (if allowed by local

codes) (not provided)

* An equipment shutoff valve with 1/8" NPT tap is an acceptable

alternative to test gauge connection. Purchase the optional equipment

shutoff valve from your dealer.

For propane/LP units, the installer must supply an external regulator.

The external regulator will reduce incoming gas pressure. You must

reduce incoming gas pressure to between 11" and 14" of water. If

you do not reduce incoming gas pressure, heater regulator damage

could occur. Install external regulator with the vent pointing down

as shown in Figure 10, page 11. Pointing the vent down protects it

from freezing rain or sleet.

CAUTION: Use only new, black iron or steel pipe.

Internally-tinned copper tubing may be used in cer-

tain areas. Check your local codes. Use pipe of 1/2"

diameter or greater to allow proper gas volume to

ﬁreplace. If pipe is too small, undue loss of volume

will occur.

Figure 9 - Connecting Electricity

Electrical

Bushing

Electrical

Cover Plate

Electrical

Housing

Wire Nut (3x)

(Not Supplied)

Outer Wrapper of

Fireplace

Electrical Cover Plate

and Electrical Bushing

To Power

Source

Receptacle

(Supplied)

Power Source Wiring (Not

Supplied)

Ground

(16GA Green)

Sheet Metal

Screws

14GA

Black &

White

This manual suits for next models

Table of contents

Other Astria Fireplaces Indoor Fireplace manuals

Astria Fireplaces

Astria Fireplaces Villa Vista User manual

Astria Fireplaces

Astria Fireplaces VEGA 32 User manual

Astria Fireplaces

Astria Fireplaces LIBRA 40CL Series User manual

Astria Fireplaces

Astria Fireplaces Scorpio Series User manual

Astria Fireplaces

Astria Fireplaces Gemini33TMN-B User manual

Astria Fireplaces

Astria Fireplaces Blaze&Glow18EP User manual

Astria Fireplaces

Astria Fireplaces LibraST40DMN Installation instructions

Astria Fireplaces

Astria Fireplaces Arcadia18MN User manual

Astria Fireplaces

Astria Fireplaces Altair C Series Owner's manual

Astria Fireplaces

Astria Fireplaces MAGNIFLAMEOD30NE User manual

Astria Fireplaces

Astria Fireplaces Odyssey42ZNM User manual

Astria Fireplaces

Astria Fireplaces MONTECITO User manual

Astria Fireplaces

Astria Fireplaces MAGNIFLAMEOD24NE User manual

Astria Fireplaces

Astria Fireplaces Altair40DMN Owner's manual

Astria Fireplaces

Astria Fireplaces Craftsman 36P2 Owner's manual

Astria Fireplaces

Astria Fireplaces MONTECITO ESTATE CAT User manual

Astria Fireplaces

Astria Fireplaces Tuscan42P2 Owner's manual

Astria Fireplaces

Astria Fireplaces Aries C Series User manual

Astria Fireplaces

Astria Fireplaces Altair Series User manual

Astria Fireplaces

Astria Fireplaces Windsor STP2 User manual

Astria Fireplaces

Astria Fireplaces Blackstone Series User manual

Astria Fireplaces

Astria Fireplaces Polaris42ZEN User manual

Astria Fireplaces

Astria Fireplaces BlueRidge18MN User manual

Astria Fireplaces

Astria Fireplaces Astria Devonshire36TEN Owner's manual

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
