Ascaso Baby T User manual
Enter to Programming
Software Baby T
Press the XL key and inmediately and without releasing this one
press also the Lkey to turn off the coffee group.
Press the XL key for 10 seconds to enter in the menú.
Then the display on the left group will show the differents
programming options.
With the Sand Lkeys we increase/decrease the value of it, and with the XL key we
confirm the modification, returning to the programming menú.
To exit the programming menú, we must search for the “ESC” option and select it using
the XL key.
The keypads and displays will be off. To actívate again press the Lkey.
10’’
tc
Esc
UP
DOWN
CONFIRM
ANEXO SOFTWARE BABY T.indd 1ANEXO SOFTWARE BABY T.indd 1 09/09/2020 15:27:4809/09/2020 15:27:48
Parameters
Tc – COFFEE GROUP TEMPERATURE
To change the temperature of the coffee group.
Ts – BOILER TEMPERATURE
To change the temperature of the steam boiler.
Tec – PID PARAMETERS
P/I/D/B are parameters to configurate the PID control. We advise not to change.
TEE – STEAM BOILER TEMPERATURE IN STAND-BY MODE
Energy saving temperature of the boiler. It’s the temperature at which the boiler will be
maintained when it has reached the idle time set in the following TiE parameter.
TiE - Time for the boiler to go into “saving” mode and remain at the temperature set in
the previous parameter.
Ud – UNITS OF MEASURE
Degrees Celsius (C) or Farenheit (F).
Example of sequences:
Next parameter:
or
Modify parameter:
to enter to confirmto adjust
ANEXO SOFTWARE BABY T.indd 2ANEXO SOFTWARE BABY T.indd 2 09/09/2020 15:27:4809/09/2020 15:27:48
P1/P2/P3/P4 – COFFEE PREINFUSION
We can program the “on” time of the preinfusion. The pump “off” time is always three
seconds. Maximum seconds are 5 seconds.
Example:
P1: Preinfusion Skey 1 press (short coffee single)
P2: Preinfusion Skey 2 keystrokes (short coffee double)
P3: Preinfusion Lkey 1 press (long coffee single)
P4: Preinfusion Lkey 2 keystrokes (long coffee double)
Cr – CHRONOMETER FUNCTION
We can activate or deactivate the display of coffee delivery time.
U – OFFSET TEMPERATURE
This parameter is used to correct the temperature difference between the display group
data and the actual temperature value at the output group.
AC - To activate and deactivate the steam boiler
EP- It allows configuring the hydraulic connection as NETWORK or TANK.
SP – Indicates the number of total services of the machine since the last reset to 0.
ST – Indicates the number of total services of the machine.
ESC – To exit of the menú.
To activate the machine press Lkey
ANEXO SOFTWARE BABY T.indd 3ANEXO SOFTWARE BABY T.indd 3 09/09/2020 15:27:4909/09/2020 15:27:49
Washing process
With the machine turned off, press the XL key and inmediately and without releasing
this one press also the Skey. It makes 10 wash cycles
Factory reset
With the machine turned off, press S, L, XL buttons and On master switch
simultaneously.
When the display shows PRT, Turn Off and On master switch.
To activate the machine press Lkey
“Showroom” mode
With the machine turned off, press Sand Lsimultaneously.
ANEXO SOFTWARE BABY T.indd 4ANEXO SOFTWARE BABY T.indd 4 09/09/2020 15:27:4909/09/2020 15:27:49
