Arjo MAXI MOVE User manual
Apply and release brake
Loop sling attachment Clip sling attachment
Apply break Release brake
Latch
closed
DPS recline
Legs closed
Spreader bar down
Spreader bar up
DPS sit up
Legs open
For storage and on incline only. Do not apply
brakes when lifting a patient in any other way.
Attach and secure the clip at the lug before
patient is lifted.
Control panel and Control handset buttons
001-25215-EN Rev 0 • 05/2020 • Page 1/2
Maxi Move
QUICK REFERENCE GUIDE - FUNCTIONS
Raise lever Remove locking pin.
Press locking clip thumb pads. Lift attachment up (A) and away (B) from the T-bar.
Fit attachment around
T-bar, thumb pads forward.
Locking clip is fully
engaged.
Use lever as a crank. Turn
it one clockwise rotation.
1
2
12
Remove attachment
Install attachment
Electrical power fail – lower the jib
AB
Markings on the attachment
are aligned.
123
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com 001-25215-EN Rev 0 • 05/2020 • Page 2/2
