Aritech 1200C User manual

1200C-2000C Fire Alarm

Control Panel and

Repeater User Manual

P/N 10-3311-505-1003-01 • ISS 18DEC14

Trademarks and

patents

The 1200C-2000C name and logo are trademarks of

UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacture

UTC CCS Manufacturing Polska Sp. Z o.o.

Ul. Kolejowa 24. 39-100 Ropczyce, Poland

Authorized EU manufacturing representative:

UTC Fire & Security B.V. Kelvinstraat 7, 6003 DH Weert,

Netherlands

Certification

2012/19/EU (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that

cannot be disposed of as unsorted municipal waste in the European

Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your supplier or to a

designated collection point. For more information see:

www.recyclethis.info.

Contact information

For contact information, see www. utcfssecurityproducts.eu.

1200C-2000C Fire Alarm Control Panel and Repeater User Manual i

Content

Important information ii

Introduction ii

Product compatibility ii

Support ii

Limitation of liability ii

Controls and indicators 1

The control panel interface 1

User interface controls 2

General indicators 4

Controls buttons and indicators 6

Sounder buttons and indicators 7

Fire brigade buttons and indicators 8

Repeater buttons and indicators 9

Zone indicators 10

Operation 11

Panel operation in standby 11

Panel operation in fire alarm12

Panel operation in pre-warning 13

Panel operation in fault 14

Maintenance 15

Fire alarm system maintenance 15

Battery maintenance 16

Product Compliance 17

ii 1200C-2000C Fire Alarm Control Panel and Repeater User Manual

Important information

Introduction

This is the installation manual for UTC Fire & Security 1200C-2000C addressable

fire alarm control panels and repeaters. Read these instructions and all related

documentation entirely before operating this product.

Product compatibility

All models are compatible with UTC Fire & Security Aritech fire detectors and

manual call points. Compatibility with third-party products cannot be guaranteed.

Consult your local supplier for further information.

Support

For assistance operating and maintaining this product, contact your installation or

maintenance contractor.

Limitation of liability

Installation in accordance with this manual, applicable codes, and the instructions

of the authority having jurisdiction is mandatory. UTC Fire & Security shall not

under any circumstances be liable for any incidental or consequential damages

arising from loss of property or other damages or losses owing to the failure of

UTC Fire & Security products beyond the cost of repair or replacement of any

defective products. UTC Fire & Security reserves the right to make product

improvements and change product specifications at any time.

While every precaution has been taken during the preparation of this manual to

ensure the accuracy of its contents, UTC Fire & Security assumes no

responsibility for errors or omissions.

1200C-2000C Fire Alarm Control Panel and Repeater User Manual 1

Controls and indicators

This chapter describes the control panel interface, indicators, and controls.

The control panel interface

Figure 1: The control panel interface

1. LCD screen

2. Alphanumeric keypad

3. Fire brigade buttons and indicators

4. Key switch

5. Sounder buttons and indicators

6. Repeater buttons and indicators

7. Controls buttons and indicators

8. Zone indicators

9. General indicators

2 1200C-2000C Fire Alarm Control Panel and Repeater User Manual

User interface controls

Key switch operation

The key switch is used to restrict the operation of the fire panel controls.

Table 1: Key switch enable/disable

Position Status Description

Disabled Panel operation is restricted.

Enabled Panel operation is not restricted.

The Silence Buzzer and Test buttons operate with the key switch in any position.

User interface controls

The user interface has 20 buttons, 10 of which are alphanumeric. The remaining

10 are described below.

Table 2: Description of the control panel user interface controls

Button Description

Alpha selection (when using the alphanumeric buttons)

Display the most recent alarm

Print the current screen

Scroll between Alarm, Fault and Conditions. View additional information when

the "MORE" prompt appears on the LCD screen.

Exit a menu

Enter or confirm a value or selection

Move to the next field on the LCD screen

Move to the previous field on the LCD screen

1200C-2000C Fire Alarm Control Panel and Repeater User Manual 3

Button Description

Increase a value

Decrease a value

4 1200C-2000C Fire Alarm Control Panel and Repeater User Manual

General indicators

Figure 2: General indicators

1. Fire Alarm LEDs

2. Fault LED

3. Disable LED

4. Supply fault LED

5. System fault LED

6. Processor running LED

7. Supply On LED

Table 3: Description of general indicators

LED indicator Description

Fire Alarm Two red LEDs indicate a fire alarm.

Fault A yellow LED indicates one or more of the following general faults:

• Device fault·

• Supply fault

• Processor fault

• Bell fault

• Communications fault

• Fire brigade fault·

• Any test mode·

• Any disablement

1200C-2000C Fire Alarm Control Panel and Repeater User Manual 5

LED indicator Description

Disable A yellow LED indicates that one or more of the following is disabled:

• Devices on the loop

• Area

• Zone

• Sounders

• Fire brigade·

• Any delays ON

Supply fault A yellow LED indicates one or more of the following supply faults:

• A mains failure

• A battery problem (battery disconnected or not charging)

• An earth fault

System fault A yellow LED indicates one or more of the following:

• Internal memory failure

• Clock failure

• Watchdog time out

• Tamper switch

• Service switch

• Logic error

• Memory lock

• No checksums calculated

• Hardware test fault

• Fireman’s' panel down

• Repeater down

• Panel down

• Global repeater down

• Input fault

• Output fault

• Configuration fault

• Checksum fault

• Protected memory overwritten

• Time date wrong

• Access fault

• FEP fault

• Watchdog time-out

Processor running A flashing green LED indicates normal operation

Supply on A steady green LED indicates that the control panel is powered up

6 1200C-2000C Fire Alarm Control Panel and Repeater User Manual

Controls buttons and indicators

Figure 3: Control buttons and indicators

1. Silence Buzzer

2. Reset

3. Disable

4. Test

5. Test Third Source (2000C control panels only)

Note: Some features can only be accessed if the key switch is enabled (see “Key

switch operation” on page 2).

Table 4: Description of controls LED indicators

LED indicator Key switch position Description

Silence Buzzer Enabled or disabled The control panel internal buzzer activates for any

new condition.

The buzzer sound is:

• Constant for a fire alarm

• Fast intermittent for a fault warning

• Slow intermittent for a condition warning

Press the Silence Buzzer button to silence the

buzzer. A steady yellow LED indicates that the

buzzer has been silenced.

Reset Enabled Press this button to reset the fire panel.

Disable Enabled Press this button to display the Disable menu on

the LCD screen. The yellow LED indicates a

disablement.

Test Enabled Press this button to display the Test menu on the

LCD screen. The yellow LED indicates that a

feature or device is being tested.

Test Third Source Enabled or disabled Press this button to test the third source battery.

The yellow LED is steady and the internal buzzer

sounds intermittently.
