Archos 70c Xenon User manual

English

Table of contents

For more information, please consult the FAQs on www.archos.com. Make sure to read them before considering any product return.

Your deal may be no big deal. As we are often updating and improving our products, your device’s software may have a slightly dierent

appearance or modied functionality than presented in this Quick Start Guide.

Package contents........................................................................................................................

Getting started..............................................................................................................................

Description of the device..........................................................................................................

Inserting SIM & Micro-SD cards...............................................................................................

3G & WiFi connection.................................................................................................................

The AndroidTM interface.............................................................................................................

ARCHOS Fusion Storage.........................................................................................................

Getting familiar with AndroidTM...........................................................................................

Troubleshooting........................................................................................................................

Consult the declaration of conformity on http://www.archos.com/products/declaration_conformity.html

114368_ARCHOS_70c_Xenon_QSG_book.indd 1 03/09/2015 11:19:10

Warranty

USB cable Charger

QSG booklet

Warranty,

legal & safety booklet

Package Contents

ARCHOS 70c Xenon

114368_ARCHOS_70c_Xenon_QSG_book.indd 2 03/09/2015 11:19:10

English

Getting Started

TIP:

To receive more complete service, please register your product.

From a computer, go to www.archos.com/register.

Charging 1. Charge your device by plugging your power cable into

the micro-USB port. The ARCHOS device will start charging.

2. Press the Power button to turn on the device.

-You can use your ARCHOS whilst it charges.

-Let your device charge completely the rst time you use it.

-Use only the supplied charger.

When your device is completely discharged, you need

to charge it for at least 10 minutes before the charging

battery icon can be displayed.

114368_ARCHOS_70c_Xenon_QSG_book.indd 3 03/09/2015 11:19:10

7 8

1 2 9

Description of the device

Webcam

Loudspeaker

Microphone

Volume buttons

ON/OFF button

Reset button

Headphone jack

Micro-USB port

9Notch

Camera

Loudspeaker

114368_ARCHOS_70c_Xenon_QSG_book.indd 4 03/09/2015 11:19:11

Remove the back cover Insert SIM card and memory card

SIM

TIF

Remove the back cover Insert SIM card and memory card

SIM

TIF

Remove the back cover Insert SIM card and memory card

SIM

TIF

English

Inserting SIM & Micro-SD cards

WARNING: Make sure to turn o your device before inserting the SIM & memory cards.

Opening

Use the notch to remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

Inserting a SIM card

For your SIM card, slide it facing downwards in the slot.

Inserting a Memory card

Slide it facing downwards in the slot TIF

Closing

Replace the back cover clicking it back into position.

114368_ARCHOS_70c_Xenon_QSG_book.indd 5 03/09/2015 11:19:11

3G & WiFi connection

Mobile data connection

If your mobile phone subscription includes a mobile data option, you should be

connected to the Internet without any further setup. The ARCHOS will only have signal

if you are in an area covered by your provider’s 4G or 3G network.

Activating/Deactivating the mobile data

1. Touch and pull down the status bar to display it.

2. Touch again the bar to reveal the quick settings.

3. Select the Settings icon.

4. In Wireless & networks, select Data usage, then the

SIM card tab.

5. Slide the Mobile data switch to turn on/o.

114368_ARCHOS_70c_Xenon_QSG_book.indd 6 03/09/2015 11:19:11

English

WiFi connection

WARNING: Make sure that you are in a WiFi zone. You can access the WiFi settings

quickly from the status bar.

1. Touch and pull down the status bar to display it.

2. Touch again the bar to reveal the quick settings.

3. Select the WiFi icon to activate the WiFi

connection .

4. Select“WiFi” below the WiFi icon.

5. Touch the name of network you want to connect to.

Private networks are shown with a lock icon and will

require you to enter your password.

114368_ARCHOS_70c_Xenon_QSG_book.indd 7 03/09/2015 11:19:11

34566 7

The AndroidTM Interface

114368_ARCHOS_70c_Xenon_QSG_book.indd 8 03/09/2015 11:19:11

English

GoogleTM Search

>Touch "Google" for text search or touch the microphone icon for voice search.

AndroidTM apps shortcuts

> Touch to start an application.

Back button

Home button

Recent apps buttons

Permanent AndroidTM apps shortcuts

> Touch to start an application

All Apps button

> Touch this icon to show all the applications and widgets installed on your

ARCHOS. All your downloaded applications are here.

The status bar

> Displays notications and quick settings

114368_ARCHOS_70c_Xenon_QSG_book.indd 9 03/09/2015 11:19:11

8 9

10 11

The AndroidTM Interface

The Quick settings

1Percentage of battery remaining

2To access all your settings.

3Current user*

4To adjust the screen brightness.

5To turn on/o your WiFi connection.

6To turn on/o your Bluetooth connection.

7To activate/deactivate all wireless

connections, especially when ying.

8To activate/deactivate automatic screen

orientation as you turn your ARCHOS.

9Location services

10 To mirror your Android device to the TV so

you can enjoy your great content exactly

as you see it on your mobile device.

11 To select a notication type

*New multi-user support for tablets lets

different users have their own separate,

customizable spaces on a single device.

Add users in Settings > Device.

114368_ARCHOS_70c_Xenon_QSG_book.indd 10 03/09/2015 11:19:12
