Arbor Technology PBN-9007 User manual
- 1 -
Quick Installation Guide
Version 1.2
PBN-9007
COM Express Mini Type 10 Carrier Board
Form Factor
COM Express
Carrier Board
I/O
SATA, USB, COM, SIM,
Mini-card, CFast
Video
Single Channel LVDS,
Display Port
Ethernet
RJ-45 LAN Connector
Audio
ALC662 CODEC,
Line-out, Mic-in,
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor.com.tw
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
♦ Technical Support
Copyright® All Rights Reserved. 4040900700120P
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
- 2 -
COM Express Module Type Summary Features
COM Express supports seven pin-out Type apply to Basic and Extended form factors:
Module Type 1 and 10 supports single connector with two rows of pins (220 pins)
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins)
Connector placement and most mounting holes have transparency between Form
Factors.
The differences amount the Module Types are summarized in table below:
Module Type 1 10 2 345 6
Connectors 1 1 2 2 2 2 2
Connector Rows A, B A, B A, B,
C, D
A, B,
C, D
A, B,
C, D
A, B,
C, D
A, B,
C, D
PCIe Lanes (max) 6 4 22 22 32 32 24
PCI Bus No No Yes Ye s No No No
PATA - IDE No No Yes No Ye s No No
LAN (Max) 1113131
Serial Ports No 0 / 2 No No No No 0 / 2
Muxed SDVO No No 0 / 2 0 / 2 0 / 2 0 / 2 No
Digital Display I/F No No No No No No 0 / 3
USB 3.0 Ports No No No No No No 0 / 4
DDIs No No No No No No 0 / 3
LVDS Channel A 0 / 1 0 / 1 0 / 1 0 / 1 0 / 1 0 / 1 0 / 1
LVDS Channel B 0 / 1 No 0 / 1 0 / 1 0 / 1 0 / 1 0 / 1
- 3 -
Packing List
Before you begin installing your single board, please make sure that the following
materials have been shipped:
1 x PBN-9007 COM Express Mini Type 10 Carrier board
1 x Quick Installation Guide
Ordering Information
PBN-9007 COM Express Mini Type 10 Carrier Board
Cable Kit CBK-05-9007-00
Specications
Form Factor COM Express Mini Type 10 Carrier Board
I/O Chips Fintek F71869
Audio ALC662 CODEC, Line-out, Mic-in with Phone Jack
Storage 1 x Serial ATA connector, 1 x CFast socket
Serial Port
COM1: RS-232
COM2: RS-232/422/485 selectable
TX/RX COM Port (depending on CPU Module)
USB 2.0 4 x USB 2.0 ports
USB 3.0 2 x USB 2.0/3.0 ports
LCD Single Channel LVDS connector
Display Port DisplayPort connector
DIO 8-bit Digital Input/Output
Expansion Interface 1 x Mini-card full size socket
Operation Temp. -40ºC~85ºC (-40ºF~185ºF)
Power Connector +12V DC main functioning, Power Jack
Dimension (L x W) 95 x 125 mm (3.7” x 4.9”)
- 4 -
Board dimensions
23.9
53
85
12
27 11
54
81.66 18.86
Unit:mm
Ø 3.1* Ø6.4
16.8
10.28
8
1.6
125
- 5 -
4
66
121
4
53.28
91
4.15
95
125
Unit:mm
- 6 -
Jumpers/ Connectors Quick Reference
Jumpers
Label Description
JRS1 COM 2 RS-232/422/485 Serial Port Selection
JP1 AT / ATX, BIOS From CPU Module / Carrier Board Selection
JBAT1 Clear CMOS Setting
JLCD2 LCD Mode S election
JINV1 Inverter Voltage Setting
JBL1 LVDS Brightness Control Mode Selection
JLCD1 LCD Voltage Setting
JTOP1 CPU Board Power Source Selection
- 7 -
Connectors
Label Function
COM2 RS-232/422/485 Serial Port Connector
DIO1 Digital I/O Connector
JFRT1 Front-panel switches and LED Indicators Connector
USB2 USB Connector
USB3 USB Connector
SATA1 Serial ATA Connector
PWR1 SATA Power Connector
LAN1, LAN2 Ethernet Connectors
USB1 Double Stack USB 2.0/3.0 Connector
MIC1 Microphone
LINE_OUT1 Line-out
PW1 Power Button
5W_T1 Touch Screen Connector
LVDS1 LVDS Connector
INV1 LCD Inverter Connector
PADP1 DC Power Connector
CON1 CPU Board COM Port
DP1 DisplayPort Connector
COM1 RS-232 Serial Port
CPUF1 Fan Power Connector
KBMS1 KB/MS Connector
MC1 Mini-Card Socket
CF1 CFast Socket
SIM1 SIM Card Socket
- 8 -
Jumpers
JSR1
1
JBL1
JLCD1 7
JTOP1 8
6
JLCD2
JINV1
5
4
JP1
JBAT1
3
2
- 9 -
Connectors
USB2
PWR1
USB3
910
11 12
15
13
SATA1
14
COM2 DIO1
JFRI1
LAN2
LAN1
USB1
MIC1
Line_OUT1
PW1
16
17
18
19
20
21
23
LVDS1
INV1
24 22 5W_T1
25
27
28
29
30
PADP1
26
CON1
COM1
DP1
CPUF1
KBMS1
CF1
32
SIM1
33
MC1
31
- 10 -
Jumpers
JRS1: COM2 RS-232/422/485
Serial Port Selection(1)
Connector type: 2.00mm pitch 2x3-pin
headers.
Mode RS-232
(Default) RS-422 RS-485
1-2 Short Open Open
3-4 Open Short Open
5-6 Open Open Short
6
5
21
6
5
21
6
5
21
JP1: AT/ATX Mode Selection (2)
Connector type: 2.00mm pitch 1x2-pin header.
Pin Description
1-2 ON AT Mode
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
1-2 OFF ATX Mode
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
JP1: BIOS from CPU Board / Carrier
Board Selection (2)
Connector type: 2.00mm pitch 1x2-pin header.
Pin Description
3-4 ON CPU
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
3-4 OFF Carrier
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
JBAT1: Clear CMOS Setting (3)
Connector type: 2.00mm pitch 1×3-pin header.
Pin Mode
1-2 keep CMOS (default)
23 1
2-3 clear CMOS
23 1
JLCD2: LVDS Panel Mode
Selection (4)
Connector type: 2.00mm pitch 2×2-pin
headers.
Pin LCD Mode
1-3 Scan
Direction 0V:ON, High:Off
3
1
4
2
2-4 Frame Rate 0V:ON, High:Off
3
1
4
2
JINV1: LCD Inverter Voltage
Selection (5)
The voltage of inverter could be selected by
JINV1 in +5V or +12V.
Connector type: 2.00mm pitch 1×3-pin header.
Pin Voltage
1-2 +5V
23 1
2-3 +12V (default)
23 1
JBL1: LVDS1 Brightness Control
Level and Mode Selection (6)
Connector type: 2.00mm pitch 2×3-pin
headers.
Pin Brightness Control Source
1-3 5V PWM mode control
(default)
65
2
1
65
2
1
65
2
1
65
2
1
3-5 3.3V PWM mode control
65
2
1
65
2
1
65
2
1
65
2
1
2-4 5V DC level control
65
2
1
65
2
1
65
2
1
65
2
1
4-6 0V DC level control
65
2
1
65
2
1
65
2
1
65
2
1
