Antari X FAZER User manual

High Efficiency Vaporizing System and Highly Durable Heaters Ensure 25% Increased Output.

Modular Design for Easy, Cost Effective Maintenance.

Standardized Interface Allows Interchangeable Control Modules on All Models.

Illuminated Fluid Tank for Easy Monitoring for the Level of Fog Fluid.

Electronic Low Fluid Monitoring Protects Pump from Running Dry

Heavy-Duty, Quiet Pump for Continuous, Silent Operation.

www.bluelight.at

Tableof Contents

Introduction

Important Safeguards

Unpacking &Inspection

Setup

Operation

Control ModuleOperation

ANTARIX-20 DMX Module Settings

Maintenance

Performance Notes

www.bluelight.at

Congratulations on thepurchase of your new

ANTARI X Fazer

Thank you for choosingan ANTARI X Fazer. You now own arugged and

powerful state-of-the-art machine. Priorto use, we suggestthat you

carefully read all ofthe instructions. By followingthe suggestions found

in this user manual,you can look forwardto the reliable andsatisfactory

performance of yourANTARIFog Machine for yearsto come.

Introduction

Please follow these operation, safety and maintenance

instructions to ensure a long and safe life for your fog machine.

Cautions

Risk of electric shock. Disconnect the appliance from the electric

supply before removing the cover. Note: there are no user

serviceable parts inside.

www.bluelight.at

Important Safeguards

Danger of Electric Shock

Danger of Burns

!Keep this device dry.

!For inside use only. Not designed for outside use.

!For the 110V models, use 3-prong grounded electrical

outlet only. Prior to use take care to determine that the

unit is installed at the rated voltage.

!Always unplug your ANTARI Fog Machine before filling

its tank.

!Keep fog machine upright.

!Unplug the machine when not in use.

!This machine is not water- or splash-proof. If

moisture, water, or fog liquid gets inside the housing,

immediately unplug the unit and contact aservice

technician or your ANTARI dealer before using it again.

!No user serviceable parts inside. Refer to your ANTARI

dealer or other qualified service personnel.

!For adult use only. Fog machine must be installed out

of the reach of children. Never leave the unit running

unattended.

!Never aim the output nozzle directly at people.

!Fog machine output area is very hot. Avoid coming

within 60 cm of the output nozzle during operation.

!Locate the fog machine in awell-ventilated area. Never

cover the unit's vents. In order to guarantee adequate

ventilation, allow afree air space of at least 20 cm

around the sides and top of the unit.

!Never aim the output nozzle at open flames.

www.bluelight.at

!If the supply cord is damaged, it must be replaced by

manufacturer or its service agent or similarly qualified

personnel in order to avoid ahazard.

!The output nozzle becomes very hot during operation

(300 C). Keep flammable materials at least 50 cm away

from the nozzle.

!Always allow your ANTARI X Fazer to cool down before

attempting to clean or service it.

!Never add flammable liquids of any kind (oil, gas,

perfume) to the fog liquid.

!Use only the high-quality, water-based ANTARI fog

liquid. Other fog liquids may cause clogging or

"spitting".

!Always make sure there is sufficient liquid in the fog

liquid tank. Operating this unit without liquid will

cause damage to the pump as well as over-heating of

the heater.

!If your ANTARI Fog Machine fails to work properly,

discontinue use immediately. Drain all fog liquid from

the tank, pack the unit securely (preferably in the

original packing material), and return it to your

ANTARI dealer for service.

!Always drain tank before mailing or transporting this

unit.

!Never drink fog liquid. If it is ingested, call adoctor

immediately. If fog liquid comes in contact with skin

or eyes, rinse thoroughly with water.

Danger of Explosion

Important:

Pay attention to allwarning labels and instructionsprinted on the

exterior of yourANTARIX Fazer.

Unpacking & Inspection

Setup

WARNING:

Use of any fluidother than ANTARI fog fluid ormodification or

attempted to unauthorized repairof the X Fazerwill immediately

invalidate the warranty.

Open the shipping carton and verify that all equipment necessary

to operate the system has arrived intact.

Before beginning initial setup of your ANTARI Fog Machine, make

sure that there is no evident damage caused by transportation.

In the event that the unit's housing or cable is damaged, do not

plug it in and do not attempt to use it until after contacting your

ANTARI dealer for assistance.

!Remove all packing materials from shipping box.

Check that all foam and plastic padding is removed,

especially in the nozzle area.

!Place fog machine on aflat surface and remove fog

liquid tank cap.

!Fill with only ANTARI Fog Fluid. ANTARI XFazer only

works with uncontaminated ANTARI Fog Fluid. Other

fluids may cause spitting and serious clogging problem

and could result in the production of an unhealthful

fog. The use of other fluids voids the warranty of the

ANTARI XFazer. When filled, place cap back on liquid

tank.

!Firmly attach the control module cable to the

connector inside the rear chamber of the machine.

Operation

Important:

Always monitor tank fluidlevel as you arefogging. Running a fog

machine with no fluidcan permanently damage theunit.

!Plug power cord into agrounded electrical outlet.

Turn power switch on rear of unit to " ON" position.

Warm-up is complete when the display on control

module shows " Readyto Faze."

!To emit fog, press the appropriate button on the

control module for the desired length of time.

!Loosen the screws onthe two sides ofthe vent to adjust

output angle as desired.

!The control unit's display will cycle " Warming up" and

" Ready to Faze" as the machine re-heats to the proper

operating temperature.

!When the fluid isrunning low, the LEDinside the tank

chamber starts blinking fortwo minutes and thenstop

operation to protect thepump from running dry..

!Always monitor liquid levelto prevent interrupted

operation.

!For further information on operating your ANTARI X

Fazer, see the section titled, "Control Module

Operation" on page 6.

If your model includes amounting bracket designed for overhead

installation, it may be installed at floor level or suspended

overhead. If the unit is to be mounted using the bracket, it is

important that the fog does not shoot directly at any one's face.

Whatever installation method you choose, do not allow the unit

to have more than a15 degree angle of inclination.

If you experience low output, pump noise or no output at all,

unplug immediately. Check fluid level, the external fuse, control

module connection, and power from the wall. If all of the above

appears to be O.K., plug the unit in again. If fog does not come

out after holding the control module button down for 30 seconds,

check the hose attached to the tank to make sure there is fluid

going through the hose. If you are unable to determine the cause

of the problem, do not simply continue pushing the control

module button, as this may damage the unit. Return the

machine to your ANTARI dealer immediately.

!X-10: 10 meter wired multi-function remote control

module with 5-pin XLR connector for ANTARI XSeries

models X-310, X-510, X-515, X-530. Its interface

allows the operator to customize fog machine functions

by adjusting fogging duration, interval and volume. Its

LCD displays current operating parameters, which are

automatically stored in non-volatile memory, allowing

the machine to be powered down without losing

function settings. Instructions below:

Control Module Operation

FUNCITON

VOLUME

ESC ENTER ON / OFF

TIMER MANUAL

1.Via the Function key, you can adjust the desired

settings. Pressing the Function keywill cycle through

different options including Volume, Timer, Heat &

Fan. The Enter (Volume) Keyis used to selectthe

desired option. To adjustfog output volume setting,

simply go into Volume option. Adjust the volume

percentage (within the rangeof 1% to nonstopburst) by

means of Up /Down keys. To adjusttimer setting, go

into Timer option. Cycle through Interval(within the

range of 1 to900 seconds), Duration (withinthe range

of 1 to 200seconds), and Volume (withinthe range of

1% to nonstop burst)by means of Up/ Down keys. Use

Enter (Volume) Key toselect each option andmake

changes as desired. Toturn off the heaterand fan, go

into Heat &Fan option. Use Enter (Volume)Key to

confirm the selection. UseOn/Off (Manual) Key toturn

it on.

2.Always press Enter(Volume) keyto confirm setting.

3.Press ESC(Timer) key toexit current menu leveland

move to an upper(previous)level.

4.Press the Timer key to activate the timer function.

The display shows the adjusted interval and the device

counts the seconds down to "0". After that, the fog

emission is triggered at the volume adjusted under "

Timer "Option. The duration depends on the settings

adjusted under "Duration". If you wish to deactivate the

timer function, press the Timer key once more.

5.Press the Volume keyfor immediate triggering of the

fog emission at the volume adjusted under "Volume "

Option. Press the Volume switch once more in order to

stop the fog emission.

6.Press the Manual keyfor immediate triggering of the

fog emission at 100 %volume. Let the Manual key loose

in order to stop the fog emission.

7.When in standby mode,press On/Off key toreactive

the machine.

!X-20: DMX Interface module. Please refer to the section

on Page 8titled X-20 DMX Module Settings.

!X-30: All the X-10 features plus wireless capability.

Wireless operation is possible up to adistance of 50

meters. The address can be set from 0to 8, which means

total 9different units can be controlled separately or in

any combination desired. Press functionto cycle to RF

mode to select desired address number. Make sure the

address setting on the X-30 matches theaddress

setting on the transmitter. There are two buttons on the

transmitter. Blue one is toemit fog and Redone is to

stop the operation.
