AmazonBasics B07P897S54 User manual

B07P897S54, B07P89796B, B07PCLV36K, B07PCM39CK,

B07P74YSYM, B07P8973C1

Standard Towel Bar - 18 & 24-Inch

Barre à Serviettes Standard - 45,7cm et 61,0cm

Standard-Handtuchhalter – 45,7cm und 61,0cm

Portasciugamani Standard - 45,7 e 61,0cm

Toallero de Barra Estándar - 45,7 y 61,0cm

スタンダードタオルバー– 45.7 & 61.0 cm

Standardowy drążek na ręcznik - 45,7cm i 61,0cm

Standard handdukstång - 45,7cm och 61,0cm

English ..................................... 3

Français ................................... 9

Deutsch.................................. 15

Italiano................................... 21

Español.................................. 27

日本語 ..................................... 33

Polski..................................... 39

Svenska ................................. 45

Welcome Guide •English

Contents:

Before getting started, ensure the package contains the following components:

Part

• One (1) Bathroom Towel Bar

• Four (4) Plastic Anchors

• Four (4) Drywall Screws

• Two (2) Mounting Brackets

• Paper Mounting Template

Recommended Tools:

• Power Drill

• 1/4” (6.35mm) Drill Bit

• Level

• Cross-head Screwdriver

• Hammer

• 1/8” (3.3mm) Slotted Screwdriver

• Pencil

• Tape Measure

• Safety Glasses

• Tape

WARNING Maximum load: 22 lbs (10 kg).

Installation

Step 1: Determine Mounting Location

•

Determine where you would like to mount your bathroom hardware ﬁxture by placing it on the wall.

• Mark the location with tape or a pencil.

• Tape your mounting template to the wall, covering the desired location.

NOTICE Ensure that the template is straight by aligning a level with the center line of the

template.

Step 2: Mounting Brackets to Wall

• Using a drill and 1/4” (6.35mm) drill bit, drill two vertical holes for each mounting bracket in the

location speciﬁed on the template paper.

Installation

Step 3: Mounting Brackets to Wall

• Remove the mounting template from the wall and insert plastic drywall anchors into all 4drilled

holes. Lightly tap with hammer until anchors are ﬂush with wall.

Step 4: Attaching Brackets to Wall

• Position mounting bracket against anchor holes and thread screws until secure.

NOTICE When securing the mounting bracket to the wall, make sure the ﬂat side of the

bracket is against the wall.

Installation

Step 5: Attaching Fixture to Mounting Bracket

• Using a 1/8” (3.3mm) slotted screwdriver, loosen the metal set screw located at the base of

each ﬁxture.

• Loosen screw until ﬁxture is able to rest ﬂush over mounting bracket.

Screw clockwise

• Place one ﬁxture over top the mounting bracket with set screws facing down. With the ﬁxture

resting on the wall, use a 1/8” (3.3mm) slotted screwdriver again to tighten the ﬁxture onto the

mounting bracket.

• Make sure the ﬁxture is secured to the wall by gently moving the post from side to side.

Installation

Step 6: Insert Towel Bar Into Fixtures

• Insert one end of the towel bar into the ﬁxture you have already installed onto the wall.

• Insert the other end of the towel bar into the ﬁxture that has not been mounted to the wall.

• Place the ﬁxture over top the mounting bracket with set screws facing down.

• With the ﬁxture resting on the wall, use a 1/8” (3.3mm) slotted screwdriver again to tighten the

ﬁxture onto the mounting bracket.

• Make sure the ﬁxture is secured to the wall by gently moving the post from side to side.

Warranty Information

To obtain a copy of the warranty for this product:

For US - Visit amazon.com/AmazonBasics/Warranty

For UK - Visit amazon.co.uk/basics-warranty

— or —

Contact Customer Service at 1-866-216-1072

Feedback

Love it? Hate it?

Let us know with a customer review.

AmazonBasics is committed to delivering customer-driven products that live up to your high

standards. We encourage you to write a review sharing your experiences with the product.

Please visit: amazon.com/review/review-your-purchases#

For further services:

Visit amazon.com/gp/help/customer/contact-us

— or —

Contact Customer Service at 1-866-216-1072

Guide de Démarrage •Français

Contenu:

Avant de commencer, veuillez vous assurer que l’emballage contient les composants suivants:

Composant

• Une (1) barre à serviettes de salle de bain

• Quatre (4) chevilles plastique

• Quatre (4) vis à cloison sèche

• Deux (2) supports de ﬁxation

• Gabarit de montage en papier

Outils recommandés:

• Perceuse électrique

• Foret de 6,35mm (1/4”)

• Niveau

• Tournevis cruciforme

• Marteau

• Tournevis plat de 3,3mm (1/8”)

• Crayon

• Mètre-ruban

• Lunettes de protection

• Ruban adhésif

AVERTISSEMENT

Charge maximale: 10kg.

Installation

Étape1: Sélection de l’Emplacement du Montage

•

Déterminez l’endroit où vous souhaitez monter votre ﬁxation pour salle de bain en la plaçant

sur le mur.

• Marquez l'emplacement à l’aide de ruban adhésif ou d’un crayon.

• Collez votre gabarit de montage au mur de telle sorte qu’il couvre l’emplacement choisi.

REMARQUE Assurez-vous que le gabarit est à niveau en alignant un niveau sur le segment

central du gabarit.

Étape2: Montage Des Supports Sur le Mur

• À l'aide d'une perceuse et d'une mèche de 6,35mm (1/4”), percez deux trous verticaux pour

chaque support de ﬁxation à l'endroit désigné par le gabarit.
