Amantii INSERT-26-3825 Original instructions

ELECTRIC FIREPLACES

SAFETY INFORMATION AND INSTALLATION MANUAL

INSERT-26-3825, INSERT-30-4026, INSERT-33-4230

Keep this manual for future reference.

Read these instructions completely before beginning installation. Failure to follow them could cause a heater

malfunction and result in serious injury and/or property damage.

WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it in areas where

gasoline, paint or flammable liquids are stored.

WARNING: This heater is tested and listed for use only with the optional accessories listed in these

instructions. Use of optional accessories not specifically tested for this heater could void the heater warranty

and/or result in a safety hazard.

SAFETY INFORMATION

When using electrical heaters, basic precautions, like the ones listed below, should always be followed in

order to reduce the risk of fire, electric shock and injury.

1. Read all instructions before using this heater.

2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3

feet from the front of the heater; keep them away from sides and rear as well.

3. Always unplug heater when it’s not in use.

4. Do not operate the fireplace if it has a damaged cord or plug, after it has malfunctioned, or if the unit

has been dropped or damaged in any way.

5. Do not use the heater outdoors.

6. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never

place the heater where it may fall into a bathtub or other water containers.

7. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners or anything else.

Arrange the cord away from traffic areas where it could not be tripped over.

8. To disconnect the heater, turn the controls to "OFF" before removing the plug from the outlet.

9. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause an

electric shock, fire or damage to the heater.

10. To prevent a possible fire, do not block air intakes in any manner.

11. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or

flammable liquids are used or stored.

12. Use this heater only as described in this manual. Any other use not recommended by the

Due to high temperatures, the fireplace should be located out of

traffic and away from furniture and draperies.

The fireplace can become very hot when running. Keep children and

adults away from hot surfaces to avoid burns or clothing ignition. The

fireplace will remain hot for a time after shutdown. Allow surfaces to

cool before touching.

Do not place clothing or other flammable material on or near the

fireplace. Never place any objects on the fireplace.

manufacturer may cause fire, electric shock or injury to persons.

13. Avoid the use of an extension cord because the extension cord may overheat and cause a fire. If you

have to use an extension cord, the cord should be No. 14 AWG minimum size and rated not less than

1875 WATTS.

14. Always use properly grounded fused and polarized outlets.

15. Always use ground fault protection where it is required by electrical codes.

16. Always disconnect the power before performing any cleaning, maintenance or relocation of the

heater.

17. To prevent a possible fire, do not burn wood or other materials in this heater.

18 To prevent electric shock or fire, always use a certified electrician, should new circuits or outlets

be required.

19. When transporting or storing the heater, keep it in a dry place, free from excessive vibration.

LISTING APPROVALS

This heater has been tested in accordance with the CSA Standards for fixed and location-dedicated

electric room heaters in the United States. All components are UL or CSA safety certified.

Voltage/Hz

120VAC,60Hz

Watts:

1500Watts

Amps:

15Amps

Grounded Circuit

Note: This heater must be electrically wired and grounded in accordance with local codes or, in the

absence of local codes, with National Electric Code.

PRODUCT DIMENSION

Figure 1 INSERT-26-3825 dimensions

Figure 2 INSERT-30-4026 dimensions

Figure 3 INSERT-33-4230 dimensions

Locating FIREPLACE

NOTICE: Minimum and maximum clearances must be maintained at all

times. Illustrations throughout these instructions reflect typical

installations and are for design purposes only. Actual installations may

vary slightly due to individual preferences.

WARNING: Never locate this heater where it may fall into a bathtub or

any water container.

Figure 4 Heater Locations

Figure 8 illustrates a variety of ways the heater may be located in a room. The heater may be installed

directly on the floor, carpet or raised on a hearth.

WARNING: RISK OF FIRE. MAINTAIN ALL SPECIFIED AIR SPACE

CLEARANCES TO COMBUSTIBLES. FAILURE TO COMPLY WITH THESE

INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO

OVERHEAT. ENSUREALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT

MANTEL, FRONT, ETC.) ARE CLEARLY MAINTAINED.

APPLIANCE VENTS LOCATED ON THE FRONTAND BACK OF THIS

ELECTRICAPPLIANCE CANNOT IN ANY WAY BE COVERED AS IT MAY

CREATE A FIRE HAZARD.

WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL,THE PAINT

OR LACQUER MUST BE HEAT RESISTANT TO PREVENT DISCOLOURATION.

Figure 5

The minimum distance from the top of the appliance that the mantel can be installed is 5cm,at any depth.

The sides and back are 1cm.

UNPACKING AND TESTING FIREPLACE

Carefully remove the unit from the box. Prior to permanently installing the unit, test it to make sure it

operates properly. To do this, plug the unit's power supply cord into a 120-volt grounded outlet.

INSTALLATION

Once the mantel has been prepared, the fireplace can be installed.

Select a suitable location that is not susceptible to moisture and is away from

drapes, furniture and high traffic areas.

Note: Follow all national and local electrical codes. This insert can be installed

into an existing mantle or as a new construction.

1. Unplug the unit and turn the power switch to the “ON”position.

2. Push the fireplace into the mantel.

3. Plug the fireplace into a 15amp/120V, grounded outlet.

Note: Unscrew and remove the screws on both

sides of the unit before you place the fireplace into the

mantel.

Figure 6 The location of screw

WARNING - RISK OF FIRE! The power cord must not be pinched or

placed against a sharp edge. Secure the cord to avoid tripping or

snagging thus reducing the risk of fire, electric shock or personal

injury. Do not run the cord under carpeting. Do not cover the cord

with throw rugs, runners or similar items. Arrange the cord away from

traffic areas where it could be tripped over.

WARNING - RISK OF FIRE! To prevent a possible fire, do not block

the air intake or exhaust in any manner.

CAUTION: The unit's power supply cord must be connected to a

properly grounded and protected 120-volt outlet. Always use ground

fault protection where required by the electrical code.

Unscrew and remove

the screws on both

sides of the unit before

you place the fireplace

into the mantel.

OPERATING INSTRUCTIONS

A: REMOTE CONTROL OPERATION

The power switch and control panel are located behind the front glass .

Figure 7 The location of power switch

1. For remote to function make sure the heater is plugged-in and mains power switch located on the up

left hand side behind the front glass is at position I.

Figure 8 Figure 9

Power switch is

located behind the

glass panel

Note.The heating and flame function can only be operated by the remote control.

The remote control needs 2 pcs AA batteries (not included).

Note:When the heater is turned on for the first time, it may release a slight, harmless odor. This

odor is a normal occurrence caused by the initial heating of the internal heating elements and

should not occur after the initial burn off. (This odor may occur again if dust or debris has been

trapped in the unit.)

2. When operating the remote make sure you point the remote to the centre of the heater unit and make

sure each time you press the button the LED indicator located on top right hand corner of the remote

blinks. If the LED fails to blink check the batteries. It takes some time for the receiver to respond to the

transmitter. Do not PRESS the buttons more than once within two seconds for correct operation.

3. Power on button: The power –on button at top left corner of the remote is the mains ON/ OFF

power button. This will turn off all the functions and the heater will be in standby mode.

4. Flame Power On button ”DISPLAY ON OFF”: This button controls both the ember and flame effect.

Once the flame effect is ON use the + and –buttons as explained below to adjust the flame brightness

as desired. Press this button again to turn OFF the flame effect.

a. The –or + buttons control the brightness of EMBER.

To increase the brightness of ember bed, press and release the + button. Each time you

press this button the brightness will increase by a small amount, until the maximum is reached.

To decrease the brightness of ember bed, press and release the –button. Each time you

press this button the brightness will decrease by small amount, until the minimum brightness is

reached.

b. The FLAME INTENSITY–or + buttons control the brightness of FLAME.

To increase the brightness / flame height, press and release the + button. Each time

you press this button the brightness will increase by a small amount, until the maximum is reached.

To decrease the brightness / flame height, press and release the –button . Each time

you press this button the brightness will decrease by small amount, unitl the minimum brightness is

reached. You can mix the ember and the flame to create a realistic flame effect.

5. Heater On/off button: This button is the heater ON / OFF button. Press this button to turn the heater

ON. The heater will always start at high heat setting 1500W. To turn OFF the heater press this button

again.

HIGH button: Press the high button to switch the heater to high heat setting 1500W.

LOW button: Press the low button to switch the heater to LOW heat setting 750W.

TEMP button: Press the TEMP. button to switch the heater to AUTO mode. Under this mode the

heater will operate in similar way as explained below for the manual o0peration.
