Alphasonik PB110LE User manual
Owner's Manual
BASS ENCLOSURES
PB110LE / PB210LE
PB112LE / PB212LE
ALPHASONIK
R
ALPHASONIK WAS FOUNDED IN 1976 WITH ONE MISSION, TO
BRING STATE OF THE ART PERFORMANCE TO THE CAR AUDIO
ENTHUSIAST.
In those early years we pioneered such ground-breaking technologies
as amplier fan cooling and high voltage signal transfer which remain a
benchmark in high-end audio.
Today, the new Alphasonik is committed to pushing the envelope with
regard to technology, quality and value. Our electronics feature audio-
phile parts and circuit topology designed to let the full musical experience
come through, loud and clear. Our loudspeakers employ the latest high
technology materials and processes such as carbon reinforced woven
glass and titanium vapor deposition to deliver your music with tremen-
dous impact, dynamics and resolution.
We stand behind our quality with one of the best warranties in consumer
electronics. Compare Alphasonik car audio products against anything
competition has to offer. We’re condent you will come to one conclu-
sion...
3
Thank you for purchasing this Alphasonik product. Alpha-
sonik products are specically engineered and designed for the mobile
audio environment. This manual contains important information about
installation, set-up procedures and integrating your new Alphasonik
product into your vehicle. With proper care and installation, your new
product will provide you with many years of high performance listening
enjoyment. We recommend having an Authorized Alphasonik Dealer
install your new product for optimal performance and to take advantage
of our warranty program. Before installing your new product, please
read through the manual to fully understand the application.
Before making any electrical connections, make sure that
you disconnect the battery’s ground cable to prevent the possibility of
short circuits or damage to your electronic equipment. If your vehicle’s
stereo (head unit) comes with an Anti-theft code, DO NOT disconnect
the battery. If you have the access code for the stereo (head unit),
please refer to the vehicle’s owner’s manual.
I
N
T
R
O
D
U
C
T
I
O
N
For those looking for a quick and convenient heart-pounding upgrade, Alpha-
sonik’s Bass Series Enclosures offer the solution. Ready to install in minutes,
these boxes are built to the exact specications of the woofer, getting the most
from the amplier and maximizing the overall efciency. Alphasonik enclo-
sures are crafted with your convenience in mind.
PB110LE
10” SINGLE PRE-LOADED ENCLOSURE
Single 10” Woofer with Mineral-Filled Composite Cone
Power Handling: 300 Watts
Sensitivity: 95dB
Frequency Response: 28Hz - 1kHz
Single Terminal w/ 4-ohm Impedance
Dimensions: 16.3” x 9.8” x 12.8” (414 x 249 x 325mm)
PB112LE
12” SINGLE PRE-LOADED ENCLOSURE
Single 12” Woofer with Mineral-Filled Composite Cone
Power Handling: 400 Watts
Sensitivity: 96dB
Frequency Response: 23Hz - 1kHz
Single Terminal w/ 4-ohm Impedance
Dimensions: 17.9” x 10.2” x 15.6” (455 x 259 x 396mm)
PB210LE
10” DUAL PRE-LOADED ENCLOSURE
Dual 10” Woofers with Mineral-Filled Composite Cone
Power Handling: 600 Watts
Sensitivity: 98dB
Frequency Response: 25Hz - 1kHz
Dual Terminal w/ 4-ohm Impedance at each terminal
Dimensions: 31.1” x 9.8” x 12.8” (790 x 249 x 325mm)
PB212LE
12” DUAL PRE-LOADED ENCLOSURE
Dual 12” Woofer with Mineral-Filled Composite Cone
Power Handling: 800 Watts
Sensitivity: 99dB
Frequency Response: 20Hz - 1kHz
Dual Terminal w/ 4-ohm Impedance at each terminal
Dimensions: 34.6” x 11” x 15.6” (879 x 279 x 396mm)
F
E
A
T
U
R
E
S
A
N
D
S
P
E
C
I
F
I
C
A
T
I
O
N
S
3
4
Investigate the layout of your vehicle thoroughly before
drilling or cutting. Take care when you work near the gas tank,
gas lines, hydraulic lines, electrical components and electrical
wiring. Do not use the equipment unmounted. Attach this sys-
tem securely to prevent damage, particularly in the event of an
accident or aggressive driving. Do not mount the system so that
wire connections are unprotected or are subjected to pinching
or damage from nearby objects. Before connecting or discon-
necting power connections at the system power terminals, dis-
connect the +12V DC wire at the battery end. Conrm that your
source unit and other equipment are turned off while connecting
the input terminals. If you need to replace the power fuse, re-
place it only with a fuse identical to the provided fuse. Using a
fuse of different type or rating may result in damage to the sys-
tem, which is not covered by the manufacturer’s warranty. Do
not install any product where it may be subjected to excessive
heat, moisture and dust or where it may be repeatedly kicked,
brushed or bumped. Make absolutely sure that the terminals
for the products are connected to the proper inputs and outputs
from the music source. Never run the wiring on the outside of
the vehicle or under it where it can be damaged by road hazards
or any moving parts of the vehicle. Use existing wire channels,
sills, panels and molding strips inside the vehicle to hide the wir-
ing for safety and a neat appearance.
DISCLAIMER
IMPORTANT: Never cut any metal that is an integral part
of the vehicle’s safety or structural support system. If you are
unsure, it is best to have the product professionally installed by
an Authorized Alphasonik Dealer. Never sacrice your safety for
sound.
W
A
R
N
I
N
G
A
N
D
D
I
S
C
L
A
I
M
E
R
Alphasonik, Inc. warrants this product against all defects in material and
workmanship for a period of one (1) year from the date of original purchase
provided it was purchased from an Authorized Alphasonik, Inc. Dealer.
The conditions of this warranty and the extent of the responsibility of Alpha-
sonik, Inc. under this warranty are as follows:
1. DATED PROOF OF PURCHASE IS REQUIRED FOR WAR-
RANTY SERVICE OF THIS PRODUCT. Information about Alphasonik, Inc.
authorized warranty service may also be obtained at www.alphasonikinc.com
or by contacting or writing Alphasonik, Inc. at the address listed on the back
of this booklet.
2. This warranty will become void if service is performed by any
one other than an approved Alphasonik, Inc. Warranty Service Center.
3. This warranty does not apply to any product which has been
subjected to misuse, neglect or accident, or which has had the warranty
seal broken, serial number altered, defaced or removed, or which has been
connected, installed adjusted or repaired other than in accordance with the
instructions furnished by Alphasonik, Inc.
4. This warranty does not cover car static, electrical interference,
adjustments or labor costs for the removal or reinstallation of the unit for
repair.
5. The sole responsibility of Alphasonik, Inc. under this warranty
shall be limited to the repair or replacement thereof, at the sole discretion of
Alphasonik, Inc.
6. If it becomes necessary to send the product or any defective
part to Alphasonik, Inc. or an authorized service station, the product must
be shipped in its original or equivalent carton, fully insured, with shipping
charges prepaid. Alphasonik, Inc. will not assume any responsibility for any
loss or damage incurred in shipping.
W
A
R
R
A
N
T
Y
5
6
7. This warranty is not transferable and protects the original pur-
chaser provided they reside and made their purchase in the United States.
International consumers may contact their local retailer or distributor for war-
ranty information.
8. ALL IMPLIED WARRANTIES, EXCEPT TO THE EXTENT PRO-
HIBITED BY APPLICABLE LAW, SHALL HAVE NO GREATER DURATION
THAN THE WARRANTY PERIOD SET FORTH ABOVE. UNDER NO
CIRCUMSTANCES SHALL ALPHASONIK INC. BE LIABLE FOR ANY LOSS
OR DAMAGE, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE
USE OR INABILITY TO USE THE PRODUCT. BECAUSE SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS OR EXCLUSIONS OR LIMITATIONS OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY
NOT APPLY TO YOU.
9. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.
10. Should you have any difculties with the performance of this
product during warranty or with any Alphasonik, Inc. authorized service
center, you may contact the Alphasonik, Inc. National Service Manager at
the address listed on the back of the booklet card or call 714.670.8950 for a
listing of Authorized Warranty Service Centers in your area.
INSTALLED WARRANTY
(When purchased from and installed by an Authorized Alphasonik, Inc.
Dealer)
Speaker and Accessories: 1-year over-the-counter defective exchange plus
1-year repair or replacement at the sole discretion of Alphasonik, Inc.
Electronics: 1-year over-the-counter defective exchange, plus 1-year repair
or replacements at the sole discretion of Alphasonik, Inc.
An Alphasonik Extended Warranty Registration Card must be submitted to
Alphasonik, Inc. within 30 days of purchase. To process any warranty claim,
Alphasonik, Inc. will require the dated proof of purchase, which must speci-
cally show the model and serial number and that installation was provided
for the product in question. All other terms per Alphasonik, Inc.’s standard
one-year warranty apply.
W
A
R
R
A
N
T
Y
C
O
N
T
I
N
U
E
D
ALPHASONIK INC.
7050 VILLAGE DRIVE BLDG. G
BUENA PARK, CALIFORNIA. 90621
TEL: (714)670-8950 · FAX: (714)670-8959
www.alphasonikinc.com
