Page 1 of 13
READ AND SAVE THESE INSTRUCTIONS
To reduce the risk of electric shock, ensure electricity
has been turned off at the circuit breaker or fuse box
before beginning.
All wiring must be in accordance with the National
Electrical Code and local electrical codes. Electrical
installation should be performed by a qualified licensed
electrician.
CAUTION: Read all instructions and safety information
before installing your new fan. Review accompanying
assembly diagrams.
WARNING: To reduce the risk of electrical shock and
fire, do not use this fan with any solid-state fan speed
control device.
WARNING: To reduce the risk of fire, electric shock, or
personal injury, mount to UL Listed outlet box marked
“acceptable for fan support of 15.9 kg (35 lbs.) or less”
and use mounting screws provided with the outlet box.
Most outlet boxes commonly used for the support of
light fixtures are not acceptable for fan support and
may need to be replaced. Due to the complexity of the
installation of this fan, a qualified licensed electrician is
strongly recommended.
AVERTISSEMENT: Pour réduire les risques d'incendie,
de choc électrique ou de blessure, posez le ventilateur
seulement sur une boîte de sortie électrique ou tout
autre support portant une mention selon laquelle elle
peut supporter un ventilateur de 35 lb (15,9 kg) ou
moins, utilisez les vis de montage accompagnant la
boîte de sortie électrique. La plupart des boîtes de
sortie électriques généralement utilisées pour la pose
d'un appareil d'éclairage ne conviennent pas à la
suspension d'un ventilateur et peuvent nécessiter un
remplacement. En cas de doute, adressez-vous à un
électricien qualifié.
The outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum
of 50 pounds.
The fan must be mounted with a minimum of 7 feet
clearance from the trailing edge of the blades to the
floor. The tip of the fan blade to the nearest
wall/obstruction: 30 inches
Avoid placing objects in the path of the blades.
To avoid personal injury or damage to the fan and other
items, be cautious when working around or cleaning
the fan.
Do not use water or detergents when cleaning the fan
or fan blades. A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into
outlet box. The wires should be spread apart with the
grounded conductor and the equipment- grounding
conductor on one side of the outlet box.
Electrical diagrams are for reference only. Light kits that
are not packed with the fan must be UL and cUL Listed
and marked suitable for use with the model fan you are
installing. Switches must be UL and cUL General Use
Switches. Refer to the Instructions packaged with the
light kits and switches for proper assembly.
SAFETY RULES
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
12.
11.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, THIS FAN MUST BE INSTALLED WITH AN
ISOLATING WALL CONTROL/SWITCH.
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, DO NOT BEND THE BLADE ARMS (ALSO
REFERRED TO AS FLANGES), WHEN INSTALLING
THE BRACKETS, BALANCING THE BLADES OR
CLEANING THE FAN.
