ALIENWARE® M11x
COMPREHENSIVE SPECIFICATIONS
The contents herein are subject to change without notice.
© 2010 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the prior written permission of Dell Inc. is
strictly prohibited.
Trademarks used in this manual: Alienware is a trademark or registered trademarks of Alienware Corporation.;
Dell is a trademark of Dell Inc.; Intel and Pentium are the registered trademarks and Core is a trademark of Intel
Corporation in the U.S. and other countries.; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc.
Other trademarks and trade names may be used in this manual to refer to either the entities claiming the marks
and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other
than its own.
Model: P06T Type: P06T001/P06T002 Rev. A00 February 2010
COMPREHENSIVE SPECIFICATIONS
COMPREHENSIVE SPECIFICATIONS
COMPREHENSIVE SPECIFICATIONS
4
Computer Model
Alienware M11x
Dimensions
Height (Front and Back) 32.7 mm (1.29 inches)
Width 285.7 mm (11.25 inches)
Depth 233.3 mm (9.19 inches)
Weight with 8-cell battery
(starting at)
1.99 kg (4.39 lb)
NOTE: e weight of your laptop will vary depending
on the conguration ordered and the manufacturing
variability.
COMPREHENSIVE SPECIFICATIONS
5
Processor and System Chipset
Processor Intel Pentium™ Dual Core
Intel®Core™2 Duo
L2 cache
Intel Pentium Dual Core
Intel Core2 Duo
2 MB
3 MB
Bus clock 200 MHz
System chipset Intel GS45
SDRAM bus width one or two 64-bit channels of DDR3 memory up to
800 MHz
Processor address bus width 32 bits
Processor data width 64 bits
BIOS EPROM 16 Mbit
Graphics bus PCIe x16 bus
PCI bus 32 bits
COMPREHENSIVE SPECIFICATIONS
6
Memory
Connectors two internally-accessible DDR3 SODIMM sockets
Capacities 1 GB, 2 GB, and 4 GB
Memory type 800 MHz (dual-channel congurations)
Memory congurations
possible
2 GB, 4 GB, and 8 GB
IEEE 1394 A
IEEE 1394A controller JMicron JMB380
IEEE 1394 interface compliant with standard IEE1394a-2000 specication
Ports and Connectors
Network adapter one RJ45 connector
USB three 4-pin USB 2.0-compliant connectors, including
one USB PowerShare connector
VGA one 15-hole connector
HDMI one 19-pin connector
COMPREHENSIVE SPECIFICATIONS
7
Ports and Connectors
DisplayPort one 20-pin connector
Audio two audio output/headphone connectors and one audio
input/microphone connector
3-in-1 Media Card Reader one combo connector
SIM card one SIM card slot
IEEE 1394 one 4-pin serial connector
Communications
Network adapter 10/100 Mbps Ethernet LAN on system board
Wireless WLAN Mini-Card (half Mini-Card slot)•
WWAN Mini-Card (full Mini-Card slot) (optional)•
integrated Bluetooth• ®module (optional)
COMPREHENSIVE SPECIFICATIONS
8
Video
Video controller integrated on
the system board
Discrete video controller
Intel GS45
Nvidia NV11P-GS1
Video memory
Intel GS45
Nvidia NV11P-GS1
dynamic based on system memory capacity
1 GB
External display support VGA, HDMI, and DisplayPort
Audio
Controller Realtek ALC665
Speaker single 8-ohms speakers in both the left and right speaker
assembly
Internal speaker amplier up to 1 W per channel; up to 2 W total power
Internal microphone support single digital microphone in camera assembly
Volume controls program menus and media keyboard function keys
COMPREHENSIVE SPECIFICATIONS
9
Hard-Drive Storage
Interface SATA
Number of hard drives one
Hard drive 2.5 inch SATA hard drive
Type standard portable and solid-state hard-drives
Cards Supported
Media cards Secure Digital (SD) memory card•
MultiMedia Card (MMC)•
Memory Stick PRO•
Video cards Intel Graphics Media Accelerator 4500MHD•
(Integrated on system board)
Nvidia GeForce GT 335M (Discrete)•
COMPREHENSIVE SPECIFICATIONS
10
Display
Type (WLED) 11.6 inch HD+ TrueLife
Maximum resolution 1366 x 768
Dimensions
Height 144 mm (5.67 inches)
Width 256.12 mm (10.08 inches)
Diagonal 293.83 mm (11.57 inches)
Refresh rate 60 Hz
Operating angle 0° (closed) to 140°
Pixel pitch 0.2550 mm
Controls brightness can be controlled through keyboard
shortcuts
