AKG 6000H500800 User manual
Crown PCC170 SW SWO 6000H50xxx
AKG Service Department, Lemböckgasse 21-25, A-1230 Wien, Austria.Tel.: (431)86654-0, FAX: (431)86654-1514, e-mail: [email protected] 06/10
1/2
RED
WHT
BLK
2
1
3
4
5
11
10
6
9
8
7
12
PCC170
6000H50100 PCC170SW
6000H50090 PCC170SWO
6000H500800
Wiring
Crown PCC170 SW SWO 6000H50xxx
AKG Service Department, Lemböckgasse 21-25, A-1230 Wien, Austria.Tel.: (431)86654-0, FAX: (431)86654-1514, e-mail: [email protected] 06/10
2/2
Spare Parts
Description Pos. Part number Qty.
PCC170 PCC170SW PCC170SWO
Electronic module PWA 1 139721-1 1 - -
Electronic module PWA
1
132013-2
- 1 -
Electronic module PWA
1
132012-3
- - 1
PCC170 mic capsule assem.
2
M45061-5
1 1 1
PCC170SWO Cable 3 H43523-2 - - 1
Housing
4
132262-1
1 1 1
Grille
5
127345-2
1 1 1
Bottom Rubber Feet
6
D 3565-5
5 5 5
Inlay 7 D 9112-0 1 - -
Logo
8
D 7801-0
1 1 1
Fastener push nut
9
C 8833-3
2 2 2
Mini Male Chassis Connector
10
C 6738-6
1 1 -
Electronic module screws 11 A10086-10404 2 2 2
Membrane switch
12 D 7753-3 - 1 1
PCC Cable (mini-XLR to XLR)
- D 6640-3 1 1 -
