Akerstroms SESAM 800 CONFIGURABLE User manual
947422-000 -A0
OPERATING MANUAL
SESAM 800
CONFIGURABLE
Table of Contents
1 Introduction __________________________________ 3
2 Scope _______________________________________ 3
3 TechnicalSpecications ________________________ 4
4 Short Description of the System _________________ 5
4.1 Receiver __________________________________________________ 5
4.2 Transmitters _______________________________________________ 5
5 Description of the Receiver______________________ 6
5.1 Indications on the Receiver ___________________________________ 7
6 Installation of the Receiver ______________________ 8
6.1 Mounting Steps ____________________________________________ 8
7 Description of the Transmitter __________________ 11
7.1 Indications on the Transmitter ________________________________ 11
8 Operation ___________________________________ 12
9 Replacing Batteries in the Transmitter ___________ 13
10 Pairing Receiver and Transmitter________________ 14
11 OutputConguration__________________________ 14
12 Receiver Drill Measures________________________ 15
Listofgures
Figure 1. Sesam 800 RXM model indicators, connections and jumper _____ 6
Figure 2. Output LED numbering and relationship with output terminals ____ 7
Figure 3. Conguring internal supply of output power __________________ 9
Figure 4. Numbering of outputs __________________________________ 10
Figure 5. The Sesam 800 M6 transmitter indicator and buttons _________ 11
Figure 7. Batteries inserted in the transmitter________________________ 13
Figure 6. Battery cover and the screws holding the cover ______________ 13
Figure 8. Rear side of the cover inserted in its position ________________ 13
Figure 9. The receiver shall be attached with 4 mm screws... ___________ 15
Introduction 3 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
1 Introduction
This manual only covers the installation of the Sesam radio remote
system. The Sesam system is not a complete remote control system; it
provides only the set of outputs that are driven according to the actions
performed by the operator of the transmitter. The way the set of outputs
is used for controlling the object depends on the specic installation and
is outside the scope of the Sesam.
The approvals for the Sesam radio remote control system are only valid
for the system itself.
The complete remote control system, where the controlled object is one
part, has to be tested and approved according to the standards/norms
that are applicable and specic to the controlled object, it is not the
responsibility of Åkerströms Björbo AB. No liability for the controlled
object or the controlled objects actions will be accepted by Åkerströms
Björbo.
2 Scope
The following guide must be used when installing Åkerströms Sesam
remote control system to ensure secure, safe operation. The installation
must be carried out by a certied electrician.
= This symbol highlights extremely important information.
Technical Specications 4 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
3 TechnicalSpecications
SystemSpecications
Operating frequency band: 869 MHz, 12 channels
Channel separation: 25 kHz
Power output: ≤ 5 mW
Functional sensitivity: Better than -107 dBm BER 10-4
Transmission principle: GMSK, TDMA
Operating Temperature: -25°C - +55°C
Storage Temperature: -40°C - +85°C
Receiverspecications S800RXM
IP- class: IP67
Power Supply: 12-24 V DC 25 mA at 12 V DC (SELV),
must be fused with 3A fuse (SAE J1284)
Conversion box for 230 V AC: 1..6 relays 16A/250 V AC
Max switching capacity of outputs: 3A/24 V DC
Total load on all outputs: Max 3A/24 V DC
Dimensions: 120 x120 x 50 mm
Weight: 350g
TransmitterSpecications S800M6
IP- class: IP67
Dimensions: 100 x 60 x 25 mm
Weight: 130g
Battery type: 2*AA/LR06 Alkaline
Table 1. Technical Specications, Sesam 800 Congurable
Short Description of the System 5 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
4 Short Description of the System
4.1 Receiver
Main features:
- 6 solid state outputs.
- Each output is user congurable as either momentary or remaining.
- Waterproof (IP67).
4.2 Transmitters
M6 is a medium size 6- button transmitter. The transmitter comes in 2
different models, one with no button print and one with the button print
1..6. For the unit with no print there is a default or custom made label
frame. The transmitters are very rugged and waterproof (IP67).
Description of the Receiver 6 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
5 Description of the Receiver
1
2
3
PB-Free
5
46
7
8
9
10
11
Figure 1. Sesam 800 RXM model indicators, connections and jumper
1. Power LED
2. Ground
3. Positive (+) 12-24 V DC connector
4. Output power input
5. LED 5
6. LED 6
7. LED 7
8. Jumper J1
9. Learn/Erase button
10. LED indicators for outputs
11. Output connectors 1..6
Jumper J1 should
be in its’ delivery
setting.
Jumper J1 must
be placed in left
position in order to
congure output
functions.
Note! Only during
conguration.
Description of the Receiver 7 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
5.1 Indications on the Receiver
The Sesam 800 RXM model has LED indicators that indicates different
parameters (see g. 1 for positions of the LEDs).
The indications on the LEDs are as follows:
Power LED (see 1in g. 1)
Indicates whether the receiver is powered on or not.
LED 5 Squelch (see 5in g. 1)
Indicates a detected signal on the operating frequency band.
LED 6 Status (see 6in g. 1)
Indicates that information from a transmitter paired with the receiver
has been received.
LED 7 Learn (see 7in g. 1)
Indicates if the transmitter is in Learn Mode. In Learn Mode LED 7 is
lit. In Conguration Mode LED 7 is slowly blinking.
Outputs LEDs (see 10 in g. 1)
Indicates the state of outputs 1..6. Output LED 1 is the bottom one,
output LED 6 is the top one. An activated output is indicated by a LED
in ON state.
6
5
4
3
2
1
Output 6
Output 5
Output 4
Output 3
Output 2
Output 1
Figure 2. Output LED numbering and
relationship with output terminals
Installation of the Receiver 8 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
6 Installation of the Receiver
The permanent installation of the receiver must include fuses that pro-
tect the equipment and wiring from over current and short-circuit. The
power supply to the receiver must be fused with 3A as close to the bat-
tery as possible. The cable must be of outer diameter 6-12 mm and each
the power conductor at least 0.75mm2. Max cable length 5 meters.
6.1 Mounting Steps
Step 1
Select a location that is within the environmental limitations of the
receiver and where it is difcult for unauthorized persons to obtain
access to the receiver. Mount the receiver with the cable glands facing
downwards.
If possible mount the receiver inside a control cabinet. Note that this is
only possible if the cabinet is made out of plastic or materials that not
have a negative effect on radio emissions.
Step 2
Drill 4 holes (for measures see g. 9).
Mount the receiver.
Installation of the Receiver 9 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
Step 3
Connect wiring for output signals and power supply. Use cable ties to
secure the wires and ensure that the wiring will not be affected by abra-
sion, heat and/or exhausts.
Connect 12-24 V DC (+) to position 3 and ground (-) to position 2
(see 3and 2in g 1).
Connect the equipment to be controlled to output terminals 1..6 (see
11 in g. 1) and equipment ground to position 2 (see 2in g. 1). If
the outputs are to be powered by the same 12-24 V DC supply as the
receiver place a jumper between the Output Power Input (SW) and
Positive (+) 12-24 V DC using a 0,75 mm2 cable (see g. 3).
PB-Free
PB-Free
P0
YWW
941551
}
}
Figure 3. Conguring internal supply of output power
Installation of the Receiver 10 (16)
Sesam 800 Congurable Document-ID: 947422-000
Version: A0 Author: SH
Step 4
Connect wiring for output signals and power supply. Use tie wraps to
secure the wire and ensure that the wiring will not be affected by hot
parts and/or exhausts. The power supply (+) to the receiver must be
fused with a system adapted fuse as close to the battery/power supply as
possible.
Figure 4. Numbering of outputs
Output
(see g. 4) 1234 5 6
Button
(see g. 5) 123456
Table 2. Functional diagram for installation of cable
Step 5
System Check
• Ensure that wiring to all components are correct and all loose wires
are cable tied and secure.
• If necessary pair transmitter (see chap. 10).
• By pressing the buttons on the transmitter, verify that all functions
work correctly as described in table 3. Note that some of the but-
tons may be set as remaining (see chap. 11).
