URSUS ACTIVE™
USER MANUAL
ACTIVE WHEELCHAIR
R
5 9 0 3 2 4 0 6 3 2 6 1 9
CAUTION! Manufacturer takes responsibility for proper usage
of the device only when the product was purchased from
qualified Akces-Med employee or at specialized medical store!
CAUTION! AKCES-MED Ltd. reserve the right to introduce
technical and trading changes in the content of the instruction
without warning.
Medical product first class according to the Regulation 93/42/EWG of
European Parliament and Council regarding medical products. For this
product the producer issued relevant declaration of conformity.
Akces-Med. Sp. z o.o. Company introduced quality
management system ISO 13485 regarding production, sales
and service. The system is certified by Det Norske Veritas.
URSUS ACTIVE
CONTENTS
1. .............................................................................................................5
2. Indications for use................................................................................................................5
3. General characteristics of wheelchair...............................................................................6
3.1. Standard equipment....................................................................................................6
3.2. Additional equipment..................................................................................................7
4. Size table.................................................................................................................................8
5. Description how to wheelchair.............................................................................................9
6. Description how to use wheelchair...................................................................................10
6.1 Wheels.........................................................................................................................11
6.2 Brakes..........................................................................................................................12
6.3 Push handle...............................................................................................................13
6.4 Footrest.......................................................................................................................13
6.5 Seat..............................................................................................................................16
6.6 Pelvic and chest pelottes............................................................................................17
6.7 Head support..............................................................................................................19
6.8 Backrest.......................................................................................................................19
6.9 Safety rail...................................................................................................................20
6.10 5 points belts.............................................................................................................20
6.11 Wrench cover............................................................................................................21
7. Additional equipment.........................................................................................................22
8. The user of wheelchair........................................................................................................29
8.1 Preparation of the patient..........................................................................................29
8.2 How to use wheelchair...............................................................................................30
9. Safety rules...........................................................................................................................31
10. Maintenance and cleaning..............................................................................................34
The purpose of user
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
INTRODUCTION
A special and active wheelchair URSUS ACTIVE™ is a perfect device
designed for daily rehabilitation of children with locomotor dysfunction. The
wheelchair can be also very useful for children after surgical treatment requiring
long-term relief of both lower limbs.
Stable construction and extensive system of supports and belts makes
children feel very confidently and safely in URSUS ACTIVE™. Large rear wheels
are equipped with special strings that allow young patients to drive the
wheelchair independently. Consequently, the young patient is able to move on
their own, take a meal, play, learn, and perform therapy exercises in seating or
half-lying position. Angle adjustment of the backrest, seat, and footrest allows
your child to rest in supine or semi-supine position. The wheelchair has been
equipped with anti-tippers wheels that prevent the patients to tip over
backwards.
Optionally, URSUS ACTIVE™ can also be equipped with push handles for
the caregiver. Tilt-in-space function allows to adjust the tilt angle of the seat, to
do so you only need to release the locking mechanism and then lock it in a
desired position.
If you have any questions or remarks, do not hesitate to contact with us:
Medical consultant: mobile +48 508 382 509
Akces-MED Sp. z o.o.: ph. +48 17 864 04 77
e-mail:
Thank you for purchasing our product.is a solid device which makes it possible
for patient to adopt
export@akces-med.com
CAUTION!
familiarize himself/herself with user manual. Remember
that complying with guidelines is highly important. It assures
safety and extends durability as well as aesthetics of the
device.
Before using the product, user is obliged to
URSUS ACTIVE
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
URSUS ACTIVE
for proper usage, preparation, maintenance, cleaning and guarantee conditions
regarding URSUS .
User manual should be kept in easily accessible place. It is designed for
people who look after disabled children, and for both doctors as well as
physiotherapists who operate the device.
Remember that complying with guidelines is highly important. It assures safety
and extends durability as well as aesthetics of the device.
The present user manual contains basic information which is essential
ACTIVE™ wheelchair
INDICATIONS FOR US
The device is recommended for people in the following cases:
nCerebral palsy – various types and forms.
nBrain and spinal cord injuries with lower limbs paralysis and weakness,
balance and motor coordination disorders with different etiology.
nDemyelinating disease (e.g. multiple sclerosis - SM).
nMeningocele.
nMuscles diseases with weakness and paralysis (dystrophy, myasthenia
gravis, myositis).
nGenetic disorders.
nDegeneration and neurological diseases.
nOther condition connected with muscles weakness, paralysis and
musculoskeletal disorders.
nAfter head and spinal cord injuries and spine trauma with paralysis and
paresis.
CAUTION! Before using the product, user is obliged to
familiarize himself/herself with user manual.
THE PURPOSE OF USER
5
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
1
2
4
6
7
9
3
5
8
10
11
12
1. Adjustable handle
2. Adjustable backrest
3. Adjustable seat
4. Head support equipped with width adjustment
5. 5 points belts
6. Adjustable side pelottes
7. Safety rail
GENERAL CHARACTERISTICS OF WHEELCHAIR
3.1 Standard equipment
URSUS ACTIVE
Regulating knobs situated at the back of
wheelchair
A. Knobs for adjustment of headrests
C. Knobs for adjustment of backrest tilt angle
D. Knobs for adjustment of backrest height
A
C
D
6
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
8. Adjustable pelvic pelottes
9.Footplate with 5 points feet stabilizing
belts equipped with heel support
10.Soft upholstery with spine load
reducing and ventilating function
11.Rear wheels (22’’ - 26’’), brakes
12.Rear casters
URSUS ACTIVE
3.2 Additional equipment
7
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
LED Lights Soft cover for tray
Pelvic belt Trunk stabilizing belt H Harness
Head-neck support Loins support 6 points safety vest
Trunk belt
Firm headrest made of foam
Thight abduction belts
Chest support
4 points safety
Abduction-adduction thight belts
Abduction block
USA_001 USA_003 USA_101
USA_107 USA_113 USA_114
USA_121 USA_124 USA_125
USA_126 USA_127 USA_128
USA_129 USA_130 USA_131
URSUS ACTIVE
8
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
Lady’s bag
Men’s bag
Bag DeLux
Tray Plexiglas
Hi-Low Frame
Outdoor Frame
Stolik
Stylish spoke covers
Oxygen tank holder
Cotton headrest cover
Narrowing pads 6 cm Narrowing pads 10 cm
USA_134 USA_137 USA_403
USA_410 USA_411 USA_414
USA_426 USA_502
USA_426 USA_503
USA_504 USA_507 USA_606
USA_608
Cup holder
URSUS ACTIVE
SIZE TABLE
4
9
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
Seat width
Symbol Measurement Unit Size 1 Size 2 Size 3
A[cm] 19-25 22-30 24-34
B[cm] 21-26 27-35 34-42
CBack rest height [cm] 44-55 49-59 55-67
EBack rest width [cm] 23 27 32
FDistance from seat to foot rest [cm] 13-29 16-40 16-43
Foot lenght [cm] 20 20 20
Push handle height [cm] 85 85 85
XBack rest angle adjustment [°] 90-180 90-180 90-180
YSeat angle adjustment [°] 0-25 0-25 0-25
ZFoot rest angle adjustment [°] 90-180 90-180 90-180
Max user’s weight [kg] 35 35 50
Weight and dimensions of the device Size 1 Size 2 Size 3
Width [cm] 62 66 70
Length [cm] 100 100 100
Height [cm] 87 92 87
Weight [kg] 18,5 20 22,5
Note: Dimensional tolerance in the table is +1/-1 cm.
A
B
F
X
Y
Z
C
E
Seat depth
Remember that wheelchair needs to be assembled. Manufacturer cannot
assemble this wheelchair due to transportation issues. We will give you
wheelchair which needs to be mounted. It consists of 2 parts: frame and seat . In
order to use the wheelchair please follow these steps:
STEP 1. Activate brakes (look point 6.2, page 12);
STEP 2. Place seat on wheelchair frame in a way that front seat's mounting bar
is placed in catches situated on wheelchair frame (fig.1). Next, it is necessary to
press firmly seat until front or back mounting bar will make a sound ''click'';
Catches
Back seat mounting bar
Front seat mounting bar
URSUS ACTIVE
5DESRIPTION HOW TO MOUNT WHEELCHAIR
10
fig.1
fig.2
: www.akces-med.com '+48 17 864 04 77 *export@akces-med.com
