Akai AK5020NF User manual
MODEL: AK5020NF
User Manual
50” Ultra HD
Smart TV
2
Welcome
Congratulations on your purchase!
This manual tells you all you need to know about using your new AKAI product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by AKAI are manufactured to the highest standards of performance and safety and, as
part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
3
Contents
Networking 17
Connecting to a Wireless Network 17
Connecting to a Wired Network 17
TV Setting Menus 18
Picture 20
Audio 22
General 23
PVR Option 25
Time 27
Network 28
Lock 29
Channel 30
App Settings 32
High Dynamic Range (HDR) 33
Smart TV 34
Smart TV Applications 34
App Portals 35
Welcome 2
Contents 3
Unpack and Prepare 4
What's in the box 4
Important Tips 5
Attaching the stand 6
Wall-mounting the TV 7
Connect to power 8
Connect your antenna 8
Controls and Connections 9
Get to know your TV 9
Buttons on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Buttons on the Remote 14
On-Screen Set Up 16
TV Guide 36
Recording 37
Recording Live TV 38
Scheduled Recording 38
Playback 38
Pause Live TV (Time-shift) 39
USB Mode 40
Set up 40
Troubleshooting 42
Specications 45
Compliance and
Responsible Disposal 46
4 | UNPACK AND PREPARE
See the inside flap of the
box for how to handle the
TV without damaging it!
Unpack and Prepare
What's in the box
In the box you will find:
A. 50" Ultra HD Smart TV
B. Remote Control
C. AAA Batteries
D. TV Stands
E. Screws for TV Stands
F. Warning Sheet
G. TV Toppling Safety Message
H. Quick Start Guide
I. Warranty Certificate
J. General Safety Warnings
K. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
Before installing your new TV, check you have everything needed.
• Antenna cable (to watch live TV)
• Broadband internet connection (to use smart apps)
ABB
C
D
E
F
GHI J
K
UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.
6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit). Make sure the legs are facing away from
each other (not leaning inwards).
Attaching the stand
• This TV is heavy! We recommend asking
someone to help you lift it.
• Unplug the TV from the power outlet before
installing or removing the stand.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
1
2
3
UNPACK AND PREPARE | 7
200mm
200mm
Back of the TV
Wall-mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M6*10mm screws (or longer,
depending on the mounting bracket) to wall-mount this
TV (screws are not included).
• Unplug the TV from the power outlet
before wall-mounting.
• Contact a professional for assistance
with wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M6*10mm
screws (or longer
as required)
The screws in the package are for securing the TV stands
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.
8 | UNPACK AND PREPARE
Free-to-airTVinHD(HighDenition)
High Definition (HD) channels
provide the best viewing quality and
are available with a digital antenna
connection.
TV channels in Ultra HD resolution are
not currently available in Australia.
Therefore when you watch HD
broadcast signals on an Ultra HD TV,
the picture can appear 'soft' and lacks
the detail you see when watching the
same content on a HD TV.
Connect to power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in the TV to the power
outlet. Leave the power switched off until
installation is finished.
CONTROLS AND CONNECTIONS | 9
See next page for more info on the connections.
Controls and Connections
Buttons on the TV
Get to know your TV
On/Standby light and Remote sensor
Bottom view
• When the TV is on standby, press this
button to turn the TV on.
• When the TV is on, press to turn the TV off.
10 | CONTROLS AND CONNECTIONS
Ports on the TV
12 3 4 5 6
1Headphone Jack
SOUND
Connect to your headphones, amplifier or audio device, using an
AUX cable (not included).
2
HDMI
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND
SOUND
COMPUTER
All-digital connection between the TV and any HDMI device.
Supports Ultra HD resolution. Requires a high-speed HDMI cable
(not included).
3AUDIO IN
SOUND
You can use this to connect Audio to your TV for AV or Component
video inputs. Requires a RCA stereo audio cable (not included).
4AV IN CVBS/Y
You can use this to connect your DVD player. Supports Standard
Definition (SD) resolution. Requires an AV cable (not included).
5COMPONENT IN
You can use this to connect your DVD player. Supports Full High
Definition (FHD) resolution. This also requires a component cable
(not included).
6 USB
STORAGE
• PVR record and pause live TV.
• Play your stored media files (supported file codecs and extensions
may vary).
• Software updates.
