Air King K52 Service manual

July, 2016

701 Frontier Way,

Bensenville, IL 60106

Phone: (800) 542-3336

Fax : (630) 350-8011 Website: AIR-KING.COM

SERVICE & INSTALLATION FOR

K52 & K552

VACUUM UNIT, AIR / VACUUM UNITS

UNITS 1200 SERIES .

July, 2016

TABLE OF CONTENTS

1. Safety Instructions Page 3

2. Introduction Page 4

3. Service & Warranty Page 5

4. General Specifications Page 6

5. Electrical Requirements Page 7

6. Mounting Instructions Page 8

7. Operating Instructions Page 9

8. Basic Maintenance Page 10

9. Replacement of Parts Page 11-12

10. Trouble Shooting Page 13-14

11. Parts Identification Page 15-18

12. Vacuum Timers Page

13. Wiring Diagrams Page

July, 2016

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE OPERATING

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY:

1. Do not use the vacuum on wet surfaces.

2. Use the vacuum only as described in the manual

3. Only the recommended Manufactures attachments should be

used on the vacuum.

4. Do not handle the vacuum with wet hands

5. Do not put any objects into the openings of the vacuum.

6. Do not vacuum up anything that is burning such as: cigars,

cigarettes, matches, or hot ashes.

7. Do not vacuum up flammable or combustible liquids, such as

gasoline. This will trigger an explosion.

8. Do not use the vacuum in areas where flammable liquids may

be present.

WARNING: VACUUMS EQUIPPED WITH AIR COMPRESSORS (K552-750) OR

VACUUMS EQUIPPED WITH REMOTE AIR SOLENOIDS (K52-9)

1. Over inflation of tires may be dangerous. Please consult your

vehicle owner’s manual for proper tire inflation.

DANGERS:

This vacuum contains equipment that tends to produce arcs and sparks,

which can cause an explosion. This vacuum must be located 18 inches

above grade and at least 25 feet from a fuel dispenser.

The vacuum operates on 120-volt AC single phase, three wires

electrical power. This vacuum must be connected to a grounded metal

permanent wiring system, or an equipment grounding conductor must be

run with the circuit conductors and connected to the equipment grounding

terminal, or lead on the unit.

ALL SERVICING OTHER THAN BASIC MAINTENANCE SHOULD BE PERFORMED BY

QUALIFIED SERVICE PEOPLE.

SAVE THESE SAFETY INSTRUCTIONS

July, 2016

INSTRUCTION

The American Products / Air King Vacuum is manufactured in a variety of configurations to

meet diverse customer needs. This manual has been prepared to aid service personal in

installing, diagnosing and repairing American Products Inc. equipment.

In general they come in one type of cabinet styles and three different models.

1. K52 Standard 2 Motor Vacuum 1200 series cabinet. (vacuum only)

2. K552- Two Motor Vacuum with ¾ H.P. Compressor 1200 series Cabinet.

(Air Vacuum)

3. K52-9 Standard 2 Motor with Remote Air Solenoid 1200 series Cabinet

(Air Vacuum Remote)

The Cabinets for the models listed above are made out of 16 gauge stainless steel.

Each of the basic models comes with a variety of optional features.

1. Models can be set up for free operation or coin operation.

2. Cut resistant hose (Air Vacuum & Air Vacuum Remote units only)

3. Single hose reel assemblies (Air Vacuum & Air Vacuum Remote units only)

4. JB 7 Lock Box for coin box security.

UNIT IDENTIFICATION

The model number and serial number appear on a metal tag, bearing the American

Products Inc. name (See Figure1 below). The identification tag is found inside the upper

compartment.

Figure 1.

Technical Support:

Our technical support staff is available at 1-800-542-3336 during normal business hours to

answer any questions regarding machine operation, components or spare parts. When

calling for technical support it is extremely helpful to have the serial # and machine model #

readily available.

Air King of America, Inc.

710 Frontier Way,

Bensenville, IL 60106

Model #

Serial #

K552-AV-P

1111111

July, 2016

SERVICE AND WARRANTY

WARRANTY STARTS FROM DATE OF INVOICING

1) Air Compressors are warranted for defects in materials and workmanship for 18

months.

2) Multi Coin timers part # 1512 & 1515 are warranted for defects in materials and

workmanship for one year.

3) Hoses and air gauge’s are warranted for thirty days from Manufacturer defects

4) All other parts of the unit are warranted for ninety days.

5) Warranty covers parts and materials only, warranty does not include labor or

transportation costs of any kind.

6) If unit or parts are returned to the factory at the customers expense, there will

be no charge for labor.

7) Vandalism or misuse of equipment, or tampering is not covered under warranty.

8) No returns will be accepted without a prior R.G.A. (RETURNED GOODS

AUTHORIZATION).

For Service Call or Write:

Air King of America, Inc.

701 Frontier Way

Bensenville, IL 60106

Phone# 800-542-3336

Fax # 630-350-8011

July, 2016

GENERAL SPECIFICATIONS

AIR KING MODEL K52

1. Four bag filter system for longer life.

2. Two twin stage 1.7 H.P. high performance vacuum motors.

3. 15 foot X 2 inch Industrial grade, crush resistant and clog

resistant hose with nozzle at the end of the hose.

4. Cabinet construction 16 and 11 gauge stainless steel or cold

rolled steel powder coated with a clear coat finish.

5. Separate timer for each function vacuum or air.

6. Money box secured with two medco plug locks on the 1200

series vacuum.

AIR KING MODEL K552-

1. High quality ¾ H.P. Industrial compressor.

2. Choice of standard red hose or cut resistant black hose.

MODEL

COMPRESSOR

H.P.

VACUUM

PEAK

H.P

CFM 2.5

ORIFICE

ELECTRICAL

RATING

(VACUUM)

SHIPPING

WEIGHT

K52

None

Vac Only

1.7 each

109

60HZ

18AMPS

150 LBS

K552

or Remote Air

1.7 each

109

18 AMPS

VAC

13 AMP

Comp.

200 LBS

NOTE ALL SPECIFICATIONS ARE FOR 1200 SERIES VACUUM MACHINES

July, 2016

ELECTRICAL REQUIREMENTS

Model K52 Vacuum only

A. 120 Volts AC Current

B. 20 AMPS Circuit Breaker

C. 60 HZ Single Phase

Model K52-9 Vacuum with Remote Air Solenoid

A. 120 Volts AC Current

B. 20 AMPS Circuit Breaker

C. 60 HZ Single Phase

Model K552- Vacuum with ¾ H.P. Compressor

A. 120 Volts AC Current

B. 40 AMPS Circuit Breaker

C. 60 HZ Single Phase

The use of the recommended wire size is required for proper operation of all models. See

wire size guide below. If using aluminum wire increase gauge on size.

Building Vacuum Machine

Run

Air King Model

Copper Wire Size

0 to 25 Ft

0 to 50 Ft

0 to 100 Ft

0 to 150 Ft

0 to 200 Ft

K52

K52-9

K552

14 GA

8 GA

12 GA

8 GA

10 GA

6 GA

8 GA

4 GA

6 GA

4 GA

Note: The run should be the length from the circuit

Breaker inside the building to the Air/Vac. machine

outside the building.

July, 2016

MOUNTING INSTRUCTIONS AND PATTERN

SEE WIRE SIZE GUIDE IN THE MANUAL FOR

PROPER WIRE GAUGE

SEE WIRE SIZE GUIDE ON

PAGE 7 FOR PROPER WIRE

GAUGE

USE ½ IN DIAMETER

STUDS 3 PLACES

CONDUIT CAN ENTER ANYWHERE IN THIS

CIRCLE, BUT SHOULD NOT EXTEND MORE THAN 1

INCH ABOVE CONCRETE BECAUSE FLOOR OF

VACUUM IS ONLY 2 ½ INCHES ABOVE THE

CONCRETE

ELECTRICAL REQUIREMENTS K52 & K52-9 , 120

VAC 20 AMP CIRCUIT BREAKER, K552-750 120

VAC 40 AMP CIRCUIT BREAKER

CONCRETE BASE SHOULD BE A MINIMUM OF 26 INCHES

LONG BY 26 INCHES WIDE 36 INCHES HIGH. CONCRETE

BASE SHOULD BE BURIED 24 INCHES IN THE GROUND.

CONRETE BASE SHOULD SIT UP A MINIMUM OF 12 INCHES

ABOVE GROUND LEVEL OR CAR BUMPER HEIGHT.

21 1/8

DIAMETER

July, 2016

OPERATING INSTRUCTIONS

To operate a K52 Vacuum coin operated model follow these instructions:

A. Insert correct amount of coin or coins into the money slot of the machine.

The machine will then start.

B. Take two inch vacuum hose off hose hanger and proceed to vacuum vehicle.

To operate a K52 Vacuum free operated model follow these instructions:

A. To start machine there will be either a toggle switch or pushbutton switch

to turn machine on either move switch up or down to start or simply push

the button to turn vacuum on.

B. Take two inch vacuum hose off hanger and proceed to vacuum vehicle.

To operate a K552- or a K52-9 Air Vacuum and Air Vac. remote follow these

instructions.

A. To operate the Vacuum side insert the correct amount of coin or coins into

the money slot on the right hand side of the vacuum control box. The

vacuum will then start, repeat the step B above and proceed to vacuum

vehicle.

B. To operate Air side insert the correct amount of coin or coins into the

money slot on left hand side of the vacuum control box. The Compressor

will then start. Take hose off of hose hanger or out of reel assembly place

end of hose on valve stem of tire. You will have to hold the end of the hose

on to the valve stem.

C. Depress handle on air gauge and begin to fill tire. To check air pressure

in tire leave hose end on valve stem and let up on handle of gauge. The

gauge will pop out showing the air pressure in the tire.

July, 2016

BASIC MAINTENANCE

1. Removal of Money Box 1200 Series Vacuum

A. Remove the two medeco plug locks with keys on front of the money box

face plate, rotate lock counter clockwise until you hear a click, pull lock

completely out. Use a 5/16 allen wrench to loosen bolts where the locks

were, turning bolts counter clockwise. When bolts are loose remove the

money box faceplate. Coin box or boxes are sitting behind faceplate.

2. Reinstall Money Box 1200 Series Vacuum

A. Replace coin box or boxes in unit, place money box face plate back into

position using 5/16 allen wrench line up bolts and tighten. Replace

medeco plug locks. Turn locks clockwise half of turn until they click.

Remove keys unit is now secured.

3. Cleaning Out Refuse Area 1200 Series Vacuums

A. Refuse area must be cleaned periodically. Refuse area is located behind

lower door on unit. If refuse is caught in the filter bags close lower door

and open top door and shake bags until refuse drops. Finish cleaning

out lower refuse area.

4. Dome Removal 1200 Series Vacuums

A. The dome is held on with four allen head screws. When the screws are

removed the dome may be lifted straight upward and off the unit.

5. Cleaning Exterior of the 1200 Series Vacuums

A. To remove scratches, paint, and dirt use soap and water or a cleaning

solution. Use a nylon scouring pad such as a scotch brite and rub with the

grain of the metal. Do not use steel wool and do not scrub decals.

This manual suits for next models

Table of contents

Other Air King Fan manuals

Air King

Air King FRAK50S User manual

Air King

Air King AK150L User manual

Air King

Air King AKLS Series User manual

Air King

Air King Exhaust Fan AK960 User manual

Air King

Air King DRLC701 User manual

Air King

Air King 9324 Owner's manual

Air King

Air King Exhaust Fan AS60 User manual

Air King

Air King AKLC70DW User manual

Air King

Air King BFQ50 Owner's manual

Air King

Air King AKLC701 User manual

Air King

Air King LEDAK50 Owner's manual

Air King

Air King D4D User manual

Air King

Air King 9312 Service manual

Air King

Air King PNP-150 User manual

Air King

Air King ES80D User manual

Air King

Air King AK964 User manual

Air King

Air King 4C523K Service manual

Air King

Air King BFQ90 User manual

Air King

Air King AKZA130 User manual

Air King

Air King 9214 Service manual

Air King

Air King 9020 Instructions for use

Air King

Air King 9145 Service manual

Air King

Air King AK927 User manual

Air King

Air King D4D User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
