NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

www.agneovo.com

RX-W22

A smart 22” widescreen surveillance

display with hard glass protection

and Anti-Burn-in™technology

designed speciﬁcally for advanced

security environments.

e RX-W22 redenes the security display with the convenience

and cost-competitiveness of the widescreen format. Features

include NeoV™ Optical Glass protection, image burn-in prevention,

swi 0.8 second switching time, Mask Mode and automatic

recovery of video settings aer a power interruption. e VESA

compatible mounts and thin prole allow for multiple displays to

be installed in any surveillance conguration. Expressly designed

and tested for commercial video security applications, the RX-W22

delivers the performance expected of a high-end security display.

> 22” widescreen format

> High 900:1 contrast ratio

> NeoV™ Optical Glass

> Distinctive bezel design and durable metal casing

> Anti-Burn-in™ technology to prevent image sticking

> Mask Mode to eliminate image distortion

> Quick signal-switching time (≤ 0.8 sec.)

> Real-time image display with no time lag

> Automatic recovery of video settings aer power interruptions

> Video looping output supports auto termination

> Supports NTSC/PAL/SECAM video systems

> Auto-adjustment when VGA input is selected

> Kensington® security socket

> VESA standard wall mount

Speciﬁcations RX-W22

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

22.0” (559 mm)

WSXGA+1680 x 1050

0.282 mm

300 cd/m

2(Typical)

900:1 (Typical)

170°/160° (Typical)

16.2M

5 ms (GTG)

30,000 hrs (Minimum)

Frequency (H/V) H: 24 kHz – 83 kHz

V: 50 Hz - 76 Hz

Max. Pixel Clock 160 MHz

Input Analogue

Digital

BNC Security

15-Pin D-Sub

24-Pin DVI-D

BNC Connector

Input Signal Analogue

Digital

Composite

RGB H.V Sync

TMDS

NTSC/PAL/SECAM

Output Connector BNC Security BNC Connector

Power AC-DC Adaptor

Power

Consumption

External

AC 100 - 240 V, 50 - 60 Hz

< 50 W (On)

< 2 W (Off)

NeoV™

Optical Glass

Thickness

Reﬂection Rate

Transmission Rate

Hardness

3.0 mm (0.18”)

< 1%

> 96%

> 6H (MOH’s Rating)

Plug & Play VESA DDC 1/2B, DDC-CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt 0° ~ +20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

512 x 392 x 155 mm

(20.2” x 15.4” x 6.1”)

586 x 508 x 195 mm

(23.1” x 20.0” x 7.7”)

Weight Product Weight

Packaged Product Weight

6.9 kg (15.2 lbs)

10.5 kg (23.1 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC-B, UL/CUL, NOM, CB, CE,

TUV/Baurt, BSMI, Nordic,

GOST, WEEE, RoHS

Accessories Supplied Quick Guide, CD ROM (user

manual and drivers), power

cord, power adaptor, 15-Pin

D-Sub cable, 24-Pin DVI-D

cable, S-Video cable, CVBS

cable, BNC connector cable

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: RXW200_RXW201 Version 2.0, 20080530

RX-W22

NeoV™ Optical Glass for hard glass protection

and strong metal casing for secure mounting

Looping BNC video connector for multiple

display connections

Specially designed and tested for commercial

video security applications

Anti-Burn-in™ technology prevents image sticking
