AG Neovo L-W27 User manual

www.agneovo.com

L-W27

A 27” LED-backlit display features Full

HD 1920 x 1080 resolution and ultra

high dynamic contrast ratio, ideal

for ofce presentations and home

entertainment.

Featuring LED backlighting with a screen resolution of up to

1920 x 1080 pixels and spacious screen size, the L-W27 brings

crisp image clarity and enhanced rich colour to the multimedia

lovers. Equipped with HDMI connector, the display allows exible

connection to Blu-ray™ players and other digital device for high-

denition multimedia visuals. Coupled with built-in speakers and

slim bezel, the L-W27 is designed for those who are looking for both

value and optimal performance.

> 27” widescreen LED-backlit LCD display

> LED backlight for energy saving and environmental consciousness

> 1920 x 1080 Full HD resolution

> Slim housing design and widescreen format

> Excellent clarity with ultrahigh 20,000,000:1 dynamic contrast ratio

> Superior colour performance and colour contrast

> HDMI input for Full HD connectivity with multimedia devices

> Built-in 2W x 2 speakers

> Energy eciency

> VESA mount standard

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: LW27A0 Version 2.1, 20130701

Specications L-W27

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

LED-backlit TFT LCD

27.0” (686 mm)

Full HD 1920 x 1080

0.311 mm

300cd/m2 (Typical)

20,000,000:1 (DCR)

Hard Coating (3H),

Anti-glare treatment

170°/160° (Typical)

16.7M

3ms (GTG)

Frequency (H/V) H: 30kHz – 83kHz

V: 56Hz – 75Hz

Input Analogue

Digital

HDMI

15-Pin D-Sub

24-Pin DVI-D

HDMI

Audio Audio In

Speaker

3.5mm Audio Line-in

2W x 2

Power Power Supply

Power Requirements

Consumption

Internal

AC 100 – 240 V, 50-60 Hz

< 50W (On)

< 0.5W (Stand-by)

< 0.5W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-25 °C ~ 55 °C

10% ~ 85%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt -4° ~ +18°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

642 x 439 x 210 mm

(25.3” x 17.3” x 8.3”)

730 x 527 x 148 mm

(28.7” x 20.7” x 5.8”)

Weight Product Weight

Packaged Product Weight

5.9 kg (13.0 lbs)

7.7 kg (16.9 lbs)

Regulation

Approval

Certications &

Compliance

FCC, CB, CE, BSMI, GOST-R,

WEEE, RoHS, REACH

Accessories Supplied CD ROM (user manual), 15-Pin

D-Sub cable, audio cable, AC

power cord

L-W27

e slim and glossy frame represents a

stylish design and also save desktop space

Built-in HDMI input makes the L-W27 easy to

be paired with Full HD multimedia advices

VESA standard wall mount allows for secure

mounting almost anywhere
