AEG BPE748380T User manual
BPE748380T
BPK748380B
BPK748380M
BPK748380T
EN User Manual | Oven
INSTALLATION
(*mm)
min. 550
20
18
min. 578
max. 590
min. 560
594
589
471
4
114
21546
460
595+-1
559+1
1
5
70
33
200200
100
60 520
min. 1500
H05 V V - F
60
33
20
245
490
(*mm)
18
594
589
600
471
4
114
21546
595+-1
460
min. 550
20
min. 560
1
5
559+1
min. 1500
H05 V V - F
245
490
80
200
100
520
60
60
33
33
20
2
Welcome to AEG! Thank you for choosing our appliance.
In our drive to be sustainable, we are reducing paper assets and provide full user
manuals online. Access your full user manual at aeg.com/manuals
Get usage advice, brochures, trouble shooter, service and repair information at
aeg.com/support
For more recipes, hints, troubleshooting download My AEG Kitchen app.
My AEG Kitchen app
ENGLISH 3
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the product in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance and mobile devices with My
Electrolux Kitchen / My AEG Kitchen (if applicable).
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
• If the appliance has a child safety device, it should be
activated.
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
4 ENGLISH
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
• Always use oven gloves to remove or put in accessories or
ovenware.
• Always cook with the oven door closed.
• To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence (if
applicable).
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• Use only the food sensor (core temperature sensor)
recommended for this appliance (if applicable).
• Remove all accessories and excessive spillage from the
appliance before the pyrolytic cleaning.
2. SAFETY INSTRUCTIONS
2.1 Installation and Electrical
connection
WARNING!
Only a qualified person must install and
connect this appliance.
Follow the installation instructions supplied
with the appliance.
Install the appliance in a safe and suitable
place that meets installation requirements.
Do not use the appliance before installing it in
the built-in structure.
Keep the minimum distance from other
appliances and units. Before mounting the
appliance, check if the oven door opens
without restraint.
Do not install or use a damaged appliance.
Remove all the packaging.
Always take care when moving the appliance
as it is heavy. Do not pull the appliance by
the handle. Always use safety gloves and
enclosed footwear.
The appliance is equipped with an electric
cooling system. It must be operated with the
electric power supply.
WARNING!
Risk of fire and electric shock.
Make sure that the parameters on the rating
plate are compatible with the electrical ratings
of the mains power supply.
The appliance must be earthed. Always use a
correctly installed shockproof socket.
ENGLISH 5
Do not use multi-plug adapters and extension
cables.
This appliance is supplied without a main
plug and a main cable.
Do not let mains cables touch or come near
the appliance door or the niche below the
appliance, especially when it operates or the
door is hot.
Use only correct isolation devices: line
protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips
and contactors.
The electrical installation must have an
isolation device which lets you disconnect the
appliance from the mains at all poles. The
isolation device must have a contact opening
width of minimum 3 mm.
For the section of the cable refer to the total
power on the rating plate. You can also refer
to the table:
Cable types applicable for installation or re‐
placement for Europe:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, H05
V2V2-F (T90), H05 BB-F
Total power (W) Section of the cable
(mm²)
maximum 1380 3 x 0.75
maximum 2300 3 x 1
maximum 3680 3 x 1.5
2.2 Use and Maintenance
WARNING!
Risk of injury, burns, electric shock, fire,
explosion or damage to the appliance.
Do not change the specification of this
appliance.
Do not let the appliance stay unattended
during operation. Deactivate the appliance
after each use.
Make sure that the ventilation openings are
not blocked.
If the appliance is installed behind a furniture
panel (e.g. a door) make sure the door is
never closed when the appliance operates.
Heat and moisture can build up behind a
closed furniture panel and cause subsequent
damage to the appliance, the furniture or the
floor. Do not close the furniture panel until the
appliance has cooled down after use.
Be careful when you open the appliance door
while the appliance is in operation. Hot air
can release.
Do not operate the appliance with wet hands
or when it has contact with water.
Do not apply pressure on the open door. Be
careful when you remove the door from the
appliance. The door is heavy.
Do not use the appliance as a work surface
or as a storage surface.
Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
When you place food into hot oil, it may
splash.
Open the appliance door carefully. The use of
ingredients with alcohol can cause a mixture
of alcohol and air.
Do not let sparks or open flames to come in
contact with the appliance when you open the
door.
Do not share your Wi-Fi password (if
applicable).
To prevent damage or discoloration to the
enamel:
• do not put ovenware or other objects in
the appliance directly on the bottom.
• do not put aluminium foil directly on the
bottom of cavity of the appliance.
• do not put water directly into the hot
appliance.
• do not keep moist dishes and food in the
appliance after you finish the cooking.
• be careful when you remove or install the
accessories.
Use a deep pan for moist cakes. Fruit juices
cause stains that can be permanent.
Discoloration of the enamel or stainless steel
has no effect on the performance of the
appliance.
6 ENGLISH
Clean regularly the appliance to prevent the
deterioration of the surface material.
Before maintenance, deactivate the appliance
and disconnect from the mains. Do not clean
the catalytic enamel (if applicable) with
detergents.
Make sure the appliance is cold. There is the
risk that the glass panels can break. Replace
immediately the door glass panels when they
are damaged. Contact the Authorised Service
Centre.
Clean the appliance with a moist soft cloth.
Use only neutral detergents. Do not use
abrasive products, abrasive cleaning pads,
solvents or metal objects.
Do not clean the catalytic enamel with
detergents (if applicable).
If you use an oven spray, follow the safety
instructions on its packaging.
Concerning the lamp(s) inside this product
and spare part lamps sold separately: These
lamps are intended to withstand extreme
physical conditions in household appliances,
such as temperature, vibration, humidity, or
are intended to signal information about the
operational status of the appliance. They are
not intended to be used in other applications
and are not suitable for household room
illumination.
Use only lamps with the same specifications.
This product contains a light source of energy
efficiency class G.
To repair the appliance contact the
Authorised Service Centre. Use original spare
parts only.
2.3 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires / Chemical
Emissions (Fumes) in Pyrolytic Mode.
Do not start the Pyrolysis if the Plus
Steam button is pressed in ( if
applicable).
Before carrying out the pyrolytic cleaning and
initial preheating remove from the oven
cavity:
• any excess food residues, oil or grease
spills / deposits.
• any removable objects (including shelves,
side rails etc., provided with the product)
particularly any non-stick pots, pans, trays,
utensils etc.
Pyrolytic cleaning is a high temperature
operation that can release fumes from
cooking residues and construction materials,
as such consumers are advised to:
• provide good ventilation during and after
each pyrolytic cleaning.
• provide good ventilation during and after
the first use at maximum temperature
operation.
If there are other appliances installed in the
same cabinet, do not use them at the same
time as the pyrolytic cleaning. It can cause
damage to the oven.
Fumes released from all pyrolytic ovens /
cooking residues as described are not
harmful to humans, including children, or
persons with medical conditions.
Keep away small pets from the appliance
during and after the pyrolytic cleaning and
initial preheating. Birds and reptiles can be
highly sensitive to the temperature changes
and emitted fumes.
Non-stick surfaces on pots, pans, trays,
utensils etc., can be damaged by the high
temperature pyrolytic cleaning operation of all
pyrolytic ovens and can be also a source for
low level harmful fumes.
2.4 Disposal
WARNING!
Risk of injury or suffocation.
Disconnect the appliance from the mains
supply. Cut off the mains electrical cable
close to the appliance and dispose of it.
Remove the door catch to prevent children or
pets from becoming trapped in the appliance.
ENGLISH 7
3. PRODUCT DESCRIPTION
3.1 General overview
2
7
1
8
4
3
5
6
5
4
3
2
1
Control panel
Display
Socket for the food sensor
Heating element
Lamp
Fan
Shelf support, removable
Shelf positions
4. CONTROL PANEL
4.1 Control panel overview
1 2 3 4 5 6
1ON / OFF Press and hold to turn the appliance on and off.
2Menu Lists the appliance functions.
3Favourites Lists the favourite settings.
4Display Shows the current settings of the appliance.
5Lamp switch To turn the lamp on and off.
6Fast Heat Up To turn on and off the function: Fast Heat Up.
8 ENGLISH
4.2 Display
150°C
12:30
15min START
85°C
G F DE C
A B
Display with key functions set.
A. Wi-Fi
B. Time of day
C. START/STOP
D. Temperature
E. Heating functions
F. Timer
G. Food sensor (selected models only)
Display indicators
Basic indicators - to navigate on the display.
To confirm the selection / setting. To go one level
back in the menu.
To undo the last
action. To turn the options on and off.
Sound alarm function indicators - when the set time of cooking ends, the signal sounds.
The function is on. The function is on.
Cooking stops automatically. Sound alarm is off.
Timer indicators
To set the function: Delayed start. To cancel the setting.
Wi-Fi indicator - the appliance can be connected to Wi-Fi.
Wi-Fi connection is turned on.
Remote operation indicator - the appliance can be controlled remotely.
Remote operation is turned on.
5. BEFORE FIRST USE
5.1 Initial Cleaning
Step 1 Step 2 Step 3
ENGLISH 9
Remove all accessories and remov‐
able shelf supports from the appli‐
ance.
Clean the appliance and the acces‐
sories only with a microfibre cloth,
warm water and a mild detergent.
Place the accessories and the re‐
movable shelf supports in the appli‐
ance.
5.2 First connection
The display shows welcome message after the first connection.
You have to set: Language, Display brightness, Key tones, Buzzer volume, Time of day.
5.3 Wireless connection
To connect the appliance you need:
• Wireless network with the Internet connection.
• Mobile device connected to the same wireless network.
Step 1 To download My AEG Kitchen app: Scan the QR code on the rating plate with the camera on your
mobile device to be redirected to AEG Homepage. The rating plate is on the front frame of the ap‐
pliance cavity. You can also download the app directly from the app store.
Step 2 Follow the app onboarding instructions.
Step 3 Turn on the appliance.
Step 4 Press: . Select: Settings / Connections.
Step 5 - slide or press to turn on: Wi-Fi.
Step 6 The appliance wireless module starts within 90 sec.
Frequency 2.4 GHz WLAN
2400 - 2483.5 MHz
Protocol IEEE 802.11b DSSS, 802.11g/n OFDM
Max Power EIRP < 20 dBm (100 mW)
Wi-Fi module NIUS-50
United Kingdom is covered by the provision of UK SI 2017, No 1206: Radio Equipment
Regulations.
5.4 Software licences
The software in this product contains
components that are based on free and open
source software. AEG acknowledges the
contributions of the open software and
robotics communities to the development
project.
To access the source code of these free and
open source software components whose
license conditions require publishing, and to
see their full copyright information and
applicable license terms, visit: http://
aeg.opensoftwarerepository.com (folder
NIUS).
5.5 Initial preheating
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
10 ENGLISH
This manual suits for next models
3
Table of contents
Other AEG Oven manuals
AEG
AEG BE2000000 User manual
AEG
AEG COMPETENCE B4101-4 Operation manual
AEG
AEG BHP6000M1 User manual
AEG
AEG COMPETENCE E4100-1 User manual
AEG
AEG COMPETENCE B1180-1 User manual
AEG
AEG COMPETENCE B4142-1 Operation manual
AEG
AEG EEB331000M User manual
AEG
AEG BE200300K User manual
AEG
AEG BS9304001M User manual
AEG
AEG BPK842720M User manual
