AEG Electrolux COMPETENCE KB9800E User manual

KB9800E

User manual Electric built-in oven

Dear Customer

Thank you for choosing one of our high-quality products.

With this appliance you will experience the perfect combination of functional

design and cutting edge technology.

Convince yourself that our appliances are engineered to deliver the best

performance and control - indeed we are setting the highest standards of

excellence.

In addition to this you find environmental and energy saving aspects as an integral

part of our products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfectly

and most efficiently. To refer to this manual any time you need to, we recommend

you to keep it in a safe place. And please pass it to any futureowner of the appliance.

We wish you much joy with your new appliance.

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how

to avoid damaging the appliance.

General information and tips

Environmental information

Contents

Operating instructions 6

Safety information 6

Electrical safety 6

Children's safety 6

Safety during use 6

How to avoid damage to the appliance 7

Description of the appliance 8

General view 8

Control panel 9

Oven layout 9

Accessories Oven 10

Before using for the first time 10

Setting and changing the time 10

Cleaning for the first time 11

Getting to know the appliance 12

Operating the oven 12

The electronic oven controls 12

The display field 12

The control panel 13

Selecting the oven function 14

Changing the oven temperature 14

Thermometer symbol 14

Changing the oven function 15

Switching the oven off 15

Fast Warm Up 15

Oven Functions 16

Inserting the oven shelf and baking tray 16

Grease filter Inserting/Removing the 17

Additional functions 17

Baking and Roasting Programmes 17

Memory function 18

Clock functions 19

Countdown 20

Cook Time 21

Contents 3

315 7850 13-D-30062007

End Time 22

Cook Time and End Time combined 23

Other functions 24

Switching off the display 24

Child safety device 25

Button Beep 26

The oven's automatic switch-off 26

Usage, Tables and Tips 26

Baking 26

General instructions 27

Baking Table 28

Tips on baking 30

Bakes and Gratins Table 31

Frozen Ready Meals Table 31

Roasting 32

Roasting Table 32

Low temperature cooking 34

Low Temperature Cooking Table 34

Single economy grill 35

Grilling Table 35

Rotitherm Roasting 36

Oven function: Rotitherm Roasting 36

Defrosting 36

Defrosting Table 36

Drying 37

Making preserves 37

Preserves table 38

Programmed recipes 39

LEMON SPONGE CAKE 1000 G 39

QUARK MANDARIN SLICE 40

WHITE BREAD 600-800 G 41

ROLLS 40 G EACH (12-16) 42

PIZZA 42

QUICHE LORRAINE 43

POTATO GRATIN 44

FISH FILLET 45

SADDLE OF VEAL 45

LASAGNE 46

4Contents

ROAST PORK 47

CHICKEN 1200 G 47

Cleaning and care 48

The outside of the appliance 48

Oven interior 48

Oven interior 49

Oven roof with catalytic self-cleaning surface 49

Accessories 49

Grease filter 50

Side rails 50

Removing the side rails 50

Replacing the side rails 51

Oven lighting 51

Oven door 52

Removing the oven door from its hinges 53

Hanging the oven door back on its hinges 53

What to do if... 54

Installation instructions 55

Safety information for the installer 55

Disposal 60

Guarantee/Customer Service 60

GREAT BRITAIN & IRELAND 60

European Guarantee 62

www.electrolux.com 63

Service 65

Subject to change without notice

Contents 5

315 7850 13-D-30062007

Operating instructions

Safety information

Important safety instructions

Read carefully and keep for future use.

Electrical safety

•This appliance must only be connected by a qualified installation engineer.

• In the event of a fault or damage to the appliance: Take the fuses out or switch

off.

•Repairs to the appliance must only be carried out by qualified service en-

gineers. Considerable danger may result from improper repairs. If repairs

become necessary, please contact our Customer Care Department or your dealer.

Children's safety

• Never leave children unsupervised while the appliance is operating.

• This appliance is fitted with a child safety device.

Safety during use

• This appliance should be used only for normal domestic cooking, roasting and

baking of food.

• Be careful if connecting electrical appliances to sockets near to this appliance.

Electrical leads must not be caught under the hot oven door.

•Warning: Risk of burns! The interior surfaces of the oven become very hot

during use.

• If you use ingredients containing alcohol in the oven, a slightly flammable mix-

ture of alcohol and air may ensue. In this case, be careful when opening the

door. Do not handle any sources of heat, sparks or naked flames when doing so.

• People (including children), who because of their physical, sensory or mental

capabilities or their inexperience or ignorance, are not able to use the appliance

safely, should not use this appliance without supervision by or instruction from

a responsible person.

6Safety information

Information on acrylamides

According to the latest scientific studies, intensive browning of food, especially in

products containing starch, can constitute a health risk due to acrylamides. There-

fore we recommend cooking at the lowest possible temperatures and not browning

foods too much.

How to avoid damage to the appliance

• Do not line the oven with aluminium foil and do not place baking trays, pots,

etc. on the oven floor, as the heat that builds up will damage the oven enamel.

• Fruit juices dripping from the baking tray will leave stains, which you will not

be able to remove. For very moist cakes, use a deep tray.

• Do not put any strain on the oven door when open.

• Never pour water directly into the oven when it is hot. This could cause damage

to and discoloration of the enamel.

• Rough handling, especially around the edges of the front panel, can cause the

glass to break.

• Do not store any flammable materials inside the oven. These could ignite when

the oven is switched on.

• Do not store any moist foods inside the oven. This could cause damage to the

enamel.

• Do not leave dishes uncovered in the oven after switching off the cooling fan.

Moisture may form inside the oven or on the glass door and also get onto the

units.

Information on the oven enamel

Changes to the colour of the oven's enamel surface as a result of use do not affect

the appliance's operation. correct use. They therefore do not constitute a defect in

terms of warranty law.

Safety information 7

Description of the appliance

General view

1Control panel

2Door handle

3Full glass door

8Description of the appliance

Control panel

1Oven displays

2Oven functions buttons

Oven layout

1Grill heating element

Description of the appliance 9

2Oven lighting

3Grease filter

4Rear wall heating element fan

5Side rails, removable

6Oven shelf levels

Accessories Oven

Oven shelf

For cookware, cake tins, roasts and grilling

food.

Baking tray

For cakes and biscuits.

Before using for the first time

Setting and changing the time

The oven only operates when the time has been set.

When the appliance has been connected to

the electrical supply or when there has been

a power cut, the symbol for the time

automatically flashes.

1. To change a time that has already been

set, press the clock functions button

repeatedly until the symbol for the time

flashes.

10 Before using for the first time
