Adventure Extreme Buggy User manual
Instruction
manual
Adventure Extreme Buggy
Keep for future reference.
To reduce the risk of serious injury or death, read this owner’s
manual prior to using this product.
designed in NZ
GENERAL WARNINGS
To greatly reduce the risk of injury or death, please read this owner’s
manual before installing and using this stroller to ensure proper use.
Stroller
• NEVER LEAVE YOUR CHILD UNSUPERVISED IN THE STROLLER.
• ALWAYS APPLY THE PARKING BRAKE WHEN YOU PARK
THE STROLLER OR WHEN TAKING YOUR CHILD IN/OUT OF
STROLLER.
• Make sure children are clear of any moving parts when adjusting the
stroller, otherwise they may be injured. Care should be taken whilst
folding and unfolding the stroller to prevent fingers being trapped.
• This stroller is suitable for one child only. Do not carry extra children
or bags on this stroller. Do not place heavy weights on the handle of
the stroller as it will impact the stability of the frame.
• The seat is suitable from birth up to 17kg.
• The stroller is not intended to be a substitute baby cot or bed. It is
only designed to enable safe transportation of children.
• Always take your child out of the pram when on stairs.
• We do not recommend using the stroller when jogging.
Harness
• To avoid serious injury, always use the safety harness when your
child is in the stroller. Always adjust the straps to suit the size of
your child’s body and to fit firmly. A loose restraint or harness is
DANGEROUS.
• Never leave a harness connected when not fitted to a child in the
stroller. The harness can form loops which may be a strangulation
hazard.
• The buckle SHOULD ALWAYS be easily accessible. It is important
that your child can be released quickly in the event of an emergency.
2
Accessories
• Use the safety strap located on the handle at all times.
• When installing capsule in the stroller, ensure the parking brake is
engaged at all times.
• It is unsafe to use accessories other than those supplied by
Adventure.
Storage
• Keep away from fire and extreme heat. Do not store in areas that
may get particularly hot in summer like roof space or beside shed
walls.
GENERAL WARNINGS (cont.)
3
By following instructions as well as care tips, your stroller will last for many years
to come.
If in doubt, please contact Adventure or your retailer.
Stroller components
4
In this manual we will help you with putting your new stroller together.
Your Extreme should come with the following:
Main components
• Stroller frame with seat unit and sun canopy
• Rear wheel axle
• Car seat capsule
• Car seat capsule adaptors for stroller
• 3 rubber tyres
• Bumper bar
• Parent console
Rear axle and wheels:
To install the axle, insert the axle tubing to the stroller strut tubing. Ensure
it’s installed with the metal button through the hole in the tubing until you
hear a CLICK! See picture (a) below.
To install the wheel, simply insert the rod on the wheel hole located on
each wheel strut until you hear a CLICK! See picture (b) below.
To remove a rear wheel, push down the metal lever on the wheels (as
pictured below) and pull the wheel outwards simultaneously.
Front wheel:
To install the wheel, insert the wheel rod into the frame hole (as pictured
below) until you hear a CLICK!
Wheel installation and removal
5
(a) (b)
Unfolding and folding the stroller
Unfolding:
1. Lie the stroller on the ground with the handle facing towards you (as
pictured in (a).
2. Remove the red locking clip.
3. Lift the handle bar upwards in a quick motion and the buggy will
unfold and CLICK! into place.
Folding:
1. Pull the two sliding levers (as pictured in (b)) just below the
handle bar on each side of the stroller frame, then push the handle
downwards towards the floor.
2. Secure the stroller by using the red locking clip found on the right
hand side.
6
(a) (b)
Car capsule installation and removal
Ensure the buggy seat position is set to recline. This allows room for
the capsule to fit in place. Insert the adaptor tracks into the stroller
frame and click the button simultaneously (as pictured below).
Insert the capsule, in a rear facing position, into the adaptors with the
handle upright (as pictured below) until you hear a CLICK!
Removing the capsule:
Press the two red buttons near the handle hinge (on the edge of the
capsule frame) and simultaneously lift upwards (as pictured below).
7
To install the bumper bar, insert the tracks on each end of the bar into
the stroller tracks until you hear a CLICK!
To remove the bar, press the release buttons located on the underside
of the bumper bar retaining bracket (as pictured below).
Bumper bar installation and removal
8
Seat and leg rest adjustment
Seat recline:
To adjust the recline, pull up the black metal lever at the rear of the seat
upwards (as pictured in (a) below) and raise or lower the seat to the desired
position (lie flat, reclined or seated).
Leg rest height:
To raise or lower the leg rest, press the two buttons on both sides of the leg
rest hinge (as pictured in (b)) until you hear it CLICK! into position.
(a) (b)
Securing and unlocking seat harness
Securing harness:
1. Place your child in the seat. Make sure that your child’s back and
bottom are flat against the seat. This will maximise comfort and allow
the harness to properly secure your child.
2. To fit the harness, link the two right hand fittings together and then
CLICK! into the buckle. Do the same for the two left hand fittings.
Check that the buckle is secure by pulling the buckle. There should be
a strong connection.
Unlocking harness:
1. To remove the harness, press the large button on the front of the
buckle until it releases (as pictured below).
9
Parking brake and front wheel lock
Parking brake:
To engage the brake, with your foot or hand firmly push down the bar
located on the rear wheel axle downwards. This brake locks both rear
wheels. Always check the stroller is firmly located.
To release the brake, lift the lever upwards.
Front wheel lock:
The swivel lock is located near the top of the front wheel.
Locking the front wheel:
Move the lever (as pictured in (a) to the right hand side (when facing
the front of the stroller). The lock will engage when the front wheel is
straight.
Freeing the front wheel:
Turn the lever to the left (when facing the stroller) as pictured in (b).
10
(a) (b)
