Advantech UR5i v2 Libratum Installation and operating instructions
Expansion Port
Mounting for v2 Routers
APPLICATION NOTE
Expansion Port Mounting
Used Symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL Licence
Source codes under GPL licence are available free of charge by sending an email to:
Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic.
Document No. APP-0001-EN, revision from November 21, 2018. Released in the Czech Republic.
i
Expansion Port Mounting
List of Figures
1 Router in plastic enclosure .............................. 1
2 Router in metal enclosure .............................. 3
List of Tables
1 Part list for routers in plastic enclosure ....................... 2
2 Part list for routers in metal enclosure ....................... 4
iii
Expansion Port Mounting
1. Safety Instruction
Please, observe the following instructions:
•The expansion port must be used in compliance with all applicable international and
national laws and in compliance with any special restrictions regulating the utilization of
the communication module in prescribed applications and environments.
•Use only the original Advantech B+B SmartWorx company accessories. Thus you will
prevent possible health risks and damage to the devices and ensure compliance with all
relevant provisions. Unauthorised adjustments or use of unapproved accessories may
result in damage to the expansion port and breach of applicable laws. Use of unapproved
adjustments or accessories may lead to cancellation of guarantee, which has no effects
on your legal rights.
•Do not expose the expansion port to extreme conditions. Protect it from dust, moisture
and heat.
2. Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive has been
introduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this product
MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-
tions of your supplier for disposal information.
1
Expansion Port Mounting
3. Expansion Port Mounting
3.1 Plastic Enclosure
Attention! Expansion port PORT1 and PORT2 can be connected only when the router
is switched off.
At first, it is necessary to remove (snap out) front panel (position 5) and then take out
the B-RB-v2 motherboard (position 1). The expansion port PORT1 (position 2) has to be
connected to connector J8 (see figure below) of the router motherboard (B-RB-v2, position
1) from TOP side. The expansion port PORT2 (position 3) has to be connected to connector
J3 (see figure below) of the router motherboard (B-RB-v2, position 1) from TOP side. Attach
each expansion port to the B-RB-v2 board using three pieces of spacers (position 10). After
mounting the expansion port, slide the router (motherboard with expansion ports) to the box
and snap the front panel in.
Figure 1: Router in plastic enclosure
1
Expansion Port Mounting
Part Description Count
1 Router motherboard 1
2 Expansion port PORT 1 1
3 Expansion port PORT 2 1
4 Router box 1
5 Front panel of the router 1
6 Spacers for attaching the expansion port to the motherboard 6
Table 1: Part list for routers in plastic enclosure
2
Expansion Port Mounting
3.2 Metal Enclosure
Attention! Expansion port PORT1 and PORT2 can be connected only when the router
is switched off.
Unscrew four screws (position 11) on the rear panel (position 6) and remove it. Then take
out the B-RB-v2 motherboard (position 1). The expansion port PORT1 (position 2) has to be
connected to connector J8 (see figure below) of the router motherboard (B-RB-v2, position 1)
from TOP side. The expansion port PORT2 (position 3) has to be connected to connector J3
(see figure below) of the router motherboard (B-RB-v2, position 1) from TOP side. Attach each
expansion port to the B-RB-v2 board using three pieces of spacers (position 10). After mount-
ing the expansion port, slide the router (motherboard with expansion ports) to the enclosure,
put the rear panel on the enclosure and screw it using four screws (position 11).
Figure 2: Router in metal enclosure
3
Expansion Port Mounting
Part Description Count
1 Router motherboard 1
2 Expansion port PORT 1 1
3 Expansion port PORT 2 1
4 Left sidewall 1
5 Right sidewall 1
6 Rear panel of the router 1
7 Front panel of the router 1
8 Bottom cover 1
9 Top cover 1
10 Spacers for attaching the expansion port to the motherboard 6
11 Screw for assembling the router enclosure 8
Table 2: Part list for routers in metal enclosure
4
Expansion Port Mounting
4. Recommended Literature
[1] Advantech B+B SmartWorx: Configuration Manual – Cellular Industrial
v2 Routers (MAN-0021-EN)
[2] Advantech B+B SmartWorx: User guide – Expansion port RS232
(MAN-0020-EN)
[3] Advantech B+B SmartWorx: User guide – Expansion port RS485/422
(MAN-0025-EN)
[4] Advantech B+B SmartWorx: User guide – Expansion port ETH
(MAN-0027-EN)
[5] Advantech B+B SmartWorx: User guide – Expansion port CNT
(MAN-0028-EN)
[6] Advantech B+B SmartWorx: User guide – Expansion port MBUSD
(MAN-0030-EN)
[7] Advantech B+B SmartWorx: User guide – Expansion port SWITCH
(MAN-0029-EN)
[8] Advantech B+B SmartWorx: User guide – Expansion port WIFI
(MAN-0031-EN)
[9] Advantech B+B SmartWorx: User guide – Expansion port WMBUS
(MAN-0032-EN)
[10] Advantech B+B SmartWorx: User guide – Expansion port SDH
(MAN-0026-EN)
Product related documents can be obtained on Engineering Portal at
https://ep.advantech-bb.cz/ address.
5
