ACU-RITE 06088 User manual

Instruction Manual

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Wi-Fi Setup............................ 3

Features & Benets................. 4

Setup .................................... 7

Placement Guidelines ............. 8

Using the Weather Station...... 9

Expand the System................11

Troubleshooting ....................12

Care & Maintenance.............14

Specications........................14

FCC Information ...................14

Customer Support .................15

Warranty..............................15

SAVE THIS MANUAL FOR FUTURE REFERENCE.

This product requires an AcuRite 5-in-1 Weather Sensor

(sold separately) to be operational.

Questions? Contact Customer Support at

www.AcuRite.com/support or email [email protected]

High Resolution

Weather Station Display

model 06088

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LED screen prior to using this

product. Peel off to remove.

Package Contents

1. Display with Tabletop Stand

2. Power Adapter

3. Mounting Bracket

4. Instruction Manual

PRODUCT REGISTRATION

www.AcuRite.com

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

Wi-Fi Setup for Weather UndergroundTM and Dark Sky

Forecast

This weather station features wireless internet connectivity in order to connect and down-

load forecasts from Dark Sky. You also have the option to share your weather data with

Weather Underground, but this is not required to get a forecast.

2. Power on the display using included power cord. If the unit has been powered on for

more than 30 minutes, press and release the “ ”

button to re-activate Wi-Fi setup. *

3. Connect to the Wi-Fi signal (named AcuRite

06088M) of the AcuRite display from

your computer or mobile device.

5. Select or enter your wireless network name and password. Fill in your country and

postal code to download your 2-day forecast from Dark Sky. If you want to send

data to Weather Underground, enter your Station ID and Station Key. Press“Save”

to save your credentials.

NOTE: This weather station display only supports 2.4 GHz wireless networks.

6. A Wi-Fi status message will appear conrming your connection to the display. If the

connection was not successful, please verify your credentials and/or visit the

Troubleshooting section (see page 13).

7. Within an hour after the display is connected to Wi-Fi, forecasts from Dark Sky will

be shown on your display. If you entered your WU credentials, data from your

sensor will automatically begin to upload to Weather UndergroundTM. Monitor

sensor data remotely at www.wunderground.com or from a mobile device using

the Weather UndergroundTM app, available from the iOS App Store or Google

Play Store.

*In order to re-activate Wi-Fi setup, Wi-Fi needs to be set to ON. See “Connections”

sub-menu (page 10).

1. (OPTIONAL) If you do not already have a WU (Weather UndergroundTM) account

and would like to send your data to WU, please create your account at

wunderground.com prior to following the next steps. To add this weather station to

your WU account:

Navigate to My Prole > My Weather Stations > Add New PWS.

Enter all required location info.

When prompted for “Station Hardware”, select “AcuRite Pro Weather Center”.

You will be provided with a WU Station ID and Station Key once you have

submitted all required info (record for step 5, below).

4. Open your web browser on the device that is

connected to the AcuRite display. Type

“192.168.4.1” in the address bar and hit enter to

access the AcuRite Wi-Fi display settings website

(shown right).

BACK OF DISPLAY

1. Plug-in for Power Adapter

2. Display Stand

3. Mounting Bracket

For easy wall mounting.

FRONT OF DISPLAY

4. Button

For menu access and setup

preferences.

5. and

Buttons

For setup preferences and manually

cycling through messages (see

page 6).

Button

For setup preferences.



Button

For viewing high & low records.

4 5 6 5 7

Features & Benets

Display

Features & Benets

Weather Overview Dashboard

78910 11 12

1. 5-in-1 Sensor Signal Strength

2. Sensor Low Battery Indicator

3. Current Wind Direction

4. Current Wind Speed

Background color changes based on

current wind speed.

5. Average Wind Speed

Average wind speed over the past

2 minutes.

6. Peak Wind Speed

Highest speed from the last 60 minutes.

7. Clock

8. Date

9. Today’s Forecast

Includes forecasted high & low

temperatures. Powered by Dark Sky

when connected to Wi-Fi.

10. Chance of Rain Indicator

Indicates the likelihood of rain when

connected to Wi-Fi.

11. Current Indoor Temperature

12. Current Indoor Humidity

13. Barometric Pressure

Arrow icon indicates direction

pressure is trending.

14. Seasonal Information

Heat Index calculation displays when

temperature is 80°F (27°C) or higher

Dew Point calculation displays when

temperature is 79°F (26°C) or lower.

Wind chill calculation displays when

temperature is 40°F (4°C) or lower.

15. Current “Feels Like” Temperature

16. Rainfall History

Displays most recent rainfall and

rainfall records for current week,

month & year.

17. Messages

Displays weather information and

messages (see page 11).

18. Current Outdoor Humidity

Arrow icon indicates direction

humidity is trending.

19. Current Outdoor Temperature

Arrow indicates direction temperature

is trending.

20. Alarm ON Indicator

Indicates alarm is activated to emit an

audible alert when conditions exceed

your presets (see page 9).

21. Icon

Indicates display is connected to your

wireless network in addition to the

signal strength.

22. Tomorrow’s Forecast

(not shown)

Display automatically toggles

between today and tomorrow’s

forecast, or press the button to

manually switch between forecasts.

Includes forecasted high & low

temperatures. Powered by Dark Sky

when connected to Wi-Fi.

Settings

After powering on for the rst time, the display will automatically enter setup

mode. Follow the on-screen instructions to set up the display.

To adjust the currently selected item, press and release the “T” or “

“

buttons.

To save your adjustments, press and release the “ ” button again to adjust

the next preference. The preference set order is as follows:

TIME ZONE (PST, MST, CST, EST, AST, HAST, NST, AKST)

AUTO DST (Daylight Saving Time YES or NO)*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

PRESSURE UNITS (inHg or hPa)

TEMPERATURE UNITS (ºF or ºC)

WIND SPEED UNITS (mph, km/h, knots)

RAINFALL UNITS (inches or mm)

DISTANCE UNITS (miles or kilometers)

AUTO DIM (YES or NO)**

AUTO CYCLE (OFF, 15 sec., 30 sec., 60 sec., 2 min., 5 min.)

ALERT VOLUME

*If you live in an area that observes Daylight Saving Time, DST should be set to YES,

even if it is not currently Daylight Saving Time.

**For more information see page 11, under “Display”.

Enter setup mode at any time by pressing the “ ” button to access the menu,

then navigate to “Setup” and press and release the “ ” button.

Display Setup

Plug Power Adapter into Electrical Outlet

SETUP

Placement for Maximum Accuracy

AcuRite sensors are sensitive to surrounding environmental conditions. Proper

placement of both the display and the sensor are critical to the accuracy and

performance of this unit.

Display Placement

Place the display in a dry area free of dirt and dust. Display

stands upright for tabletop use and is wall-mountable.

Important Placement Guidelines

• To ensure accurate temperature measurement, place units out of direct sunlight

and away from any heat sources or vents.

• Display and sensor(s) must be within 330 feet (100 m) of each other.

• To maximize wireless range, place units away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

• To prevent wireless interference, place units at least 3 feet (.9 m) away from

electronic devices (TV, computer, microwave, radio, etc.).

Using the Weather Station

OPERATION

4 8

Navigate to the main menu at any time by pressing the “ ” button. From the main

menu, you can view records, set alarms, setup an additional sensor and more.

1. Records

Access the “Records” sub-menu to view high and low values recorded

for each location by date and view trends for the sensor’s readings on a

graphic chart.

2. Alarms

Access the “Alarms” sub-menu to set and edit alarm values, including

temperature, humidity, wind speed and rainfall. The display also includes

an alarm clock feature (time alarm) and storm alarm (activated when

barometric pressure drops).

3. Setup

Access the “Setup” sub-menu to enter the initial setup process.

4. Display

Access the “Display” sub-menu to adjust display settings (brightness, contrast,

tint), display mode (screen cycle) and backlight (auto dim, sleep mode).

When auto dim mode is activated in display setup, the backlight automatically

dims the brightness based on the time of day. When “Sleep Mode” is

activated, the display automatically dims during the timeframe you choose

and shows only the most important readings for at-a-glance viewing.

5. Connections

Access the “Connections” sub-menu to add, remove or view information

about a sensor, or enable Wi-Fi setup.

6. Units

Access the “Units” sub-menu to change measurement units for barometric

pressure, temperature, wind speed, rainfall and distance.

7. Calibrate

Access the “Calibrate” sub-menu to adjust display or sensor data. First,

select the display or sensor for which you wish to calibrate readings.

Second, select the reading you wish to calibrate. Lastly, follow the on-screen

prompts to adjust the value.

8. Factory Reset

Access the “Factory Reset” sub-menu to revert the display back to factory

defaults. Follow the on-screen prompts to perform the reset.

Weather Forecast

While connected to Wi-Fi, weather forecasts for today and tomorrow are

downloaded from Dark Sky. Dark Sky is one of the most accurate sources of

hyperlocal weather information. It is backed by a wide range of weather data

sources, which are aggregated together to provide the most accurate forecast

possible for a given location. With down-to-the-minute forecasts, you’ll know

exactly when conditions will change so you can plan your day.

If the weather station is not connected to Wi-Fi, the forecast is generated

using data from the outdoor sensor. Self-calibrating forecasting uses a unique

algorithm to analyze changes in pressure over a time period (called Learning

Mode) to determine your altitude. After 14 days, the self-calibrated pressure is

tuned in to your location and the unit is ready for superior weather prediction.

AUTO DIM MODE: Automatically adjusts display brightness based on time of day.

6:00 a.m. - 9:00 p.m. = 100% brightness

9:01 p.m. - 5:59 a.m.= 15% brightness

Moon Phase

The moon phase is displayed between 7:00 p.m. to 5:59 a.m. when conditions

allow for moon visibility. The phases of the moon are conveyed through simple

lunar phase icons:

FULL

NEW WAXING

CRESCENT

WANING

CRESCENT

1ST

QUARTER

3RD

QUARTER

Table of contents

Other ACU-RITE Weather Station manuals

Popular Weather Station manuals by other brands

Auriol

Auriol AHFL 433 A1 operating instructions

NexSens

NexSens G2-HYDROMET quick start

Hyundai

Hyundai WS 2202 instruction manual

IROX

IROX HBVR761 UV-X user manual

La Crosse Technology

La Crosse Technology C86371 instruction manual

ADE

ADE WS 1711 operating instructions

Auriol

Auriol z29592 Operation and safety notes

Auriol

Auriol 296289 Operation and safety notes

Hyundai

Hyundai WS 2266 instruction manual

La Crosse Technology

La Crosse Technology WS-2210 Operation manual

La Crosse Technology

La Crosse Technology WS-811561 manual

Ventus

Ventus W177 owner's manual

National Geographic

National Geographic VA Colour RC instruction manual

Renkforce

Renkforce 1208067 operating instructions

Levenhuk

Levenhuk Discovery Report WA40 quick start guide

Instant Transmission

Instant Transmission MA 10410 instruction manual

Lutron Electronics

Lutron Electronics PHB-318 Operation manual

WAREMA

WAREMA EWFS Weather station eco Operating and installation instructions
