User Manual
AV104AHD Mobile Digital Video Recorder
activcameras
15 Abingdon Way, Stoke-on-Trent, ST4 8DX
BLANK
3
Guarantee & Warnings
1) Electrical Apparatus Safety
All installation and operation should comply with local electrical safety norms.
2) Transportation
In the process of transportation, storage and installation, please avoid heavy stress, violent vibration, impact
and water splashing.
3) Installation
Install the equipment in accordance with the requirements, handle carefully. Do not heavily press the
equipment before the MDVR installation is nished.
4) Requirements on Engineers & Technicians
All the work of checking and maintenance should be done by qualied technicians and engineers. We do
not undertake any responsibility caused by unauthorized modications.
5) Requirements on Environment
The equipment should be installed and stored in a cool and dry place, away from direct sunlight, ammable
or explosive substances, etc. Keep gaps not less than 3cm around the device to facilitate ventilation for
cooling.
6) Accessories
Make sure to use accessories from the manufacturer recommended in the attachment.
Insulate circuit ground and metal shell for all the peripherals.
Before installation, please open the package and ensure that all parts are included.
If there are any problems, please contact us as soon as possible.
4
Contents
1. PRODUCT CHARACTERISTICS
1.1. OVERVIEW ..................................................................................................................................................... 6
1.2. SPECIFICATIONS ........................................................................................................................................... 7
1.3. SYSTEM DIAGRAM ........................................................................................................................................ 8
1.4. EXTERNAL INTERFACE .................................................................................................................................. 8
1.5. HARD DISK INSTALLATION .......................................................................................................................... 11
1.6. SIM CARD INSTALLATION ............................................................................................................................ 12
1.7. DEFINITION AND PICTURES OF EXTERNAL CABLES ................................................................................. 13
2. LOCAL MANAGEMENT
2.1. LOGIN INTERFACE ........................................................................................................................................ 14
2.2. RECORD SEARCH .......................................................................................................................................... 17
2.3. LOG SEARCH ................................................................................................................................................. 20
2.4. SYSTEM STATUS ........................................................................................................................................... 22
2.5. BASIC SETUP ................................................................................................................................................. 25
2.5.1. REGISTER INFORMATION (SETUP VEHICLE INFORMATION) .................................................................... 25
2.5.2. TIME SETUP ................................................................................................................................................... 26
2.5.3. START UP ....................................................................................................................................................... 28
2.5.4. USER SETUP .................................................................................................................................................. 29
2.5.5. NETWORK ...................................................................................................................................................... 30
2.5.6. APPLICATION ................................................................................................................................................ 34
2.6. SURVEILLANCE .............................................................................................................................................. 35
2.6.1. LIVE VIEW ....................................................................................................................................................... 35
2.6.2. RECORD ......................................................................................................................................................... 36
2.6.3. IPC SETUP ...................................................................................................................................................... 40
2.6.4. PTZ ................................................................................................................................................................. 40
2.7. DATA COLLECTION ....................................................................................................................................... 41
2.7.1. GENERAL ........................................................................................................................................................ 41
2.7.2. SNAP SETTING .............................................................................................................................................. 42
2.7.3. ECO-DRIVING ................................................................................................................................................ 44
2.8. ALARM ........................................................................................................................................................... 45
2.8.1. BASE ............................................................................................................................................................... 45
2.8.2. VIDEO ............................................................................................................................................................. 51
2.8.3. ADVANCE ....................................................................................................................................................... 54
2.9. MAINTENANCE .............................................................................................................................................. 56
2.9.1. CONFIGURATION .......................................................................................................................................... 56
2.9.2. DATA EXPORT ................................................................................................................................................ 56
2.9.3. UPGRADE ....................................................................................................................................................... 57
2.9.4. STORAGE ....................................................................................................................................................... 58
2.9.5. DEFAULT ........................................................................................................................................................ 59
5
3. WEB MANAGEMENT
3.1. LOGIN INTERFACE ........................................................................................................................................ 60
3.2. MAIN INTERFACE .......................................................................................................................................... 61
3.3. PLAYBACK ..................................................................................................................................................... 61
3.4. MAINTENANCE ............................................................................................................................................. 64
3.4.1. BASIC INFORMATION ................................................................................................................................... 64
3.4.2. DEVICE MODULE ........................................................................................................................................... 65
3.4.3. STORAGE DEVICE .......................................................................................................................................... 65
3.4.4. VERSION INFORMATION .............................................................................................................................. 66
3.5. CONFIGURATION .......................................................................................................................................... 67
4. STORAGE CAPACITY CALCULATION ........................................................................................................ 68
5. FREQUENTLY ASKED QUESTIONS ............................................................................................................ 69
6
1. PRODUCT CHARACTERISTICS
1.1. OVERVIEW
The AV104AHD is a Mobile Digital Video Recorder specially designed for vehicle video surveillance and remote
monitoring. It has a high-speed processor and embedded operating system, combined with the most advanced
H.264 video compression/decompression technology, 3G/4G network, GPS positioning technology, as well as
WiFi.
It supports not only video recording in 720P, WD1, WHD1, WCIF, D1, HD1 and CIF formats, but also vehicle travel
information recording and wireless data upload. With center software it also achieves alarm linkage central
monitoring, remote management and playback analysis. It is easy to use with simple design, multi-functions,
superior anti-vibration, exible installation and high reliability.
7
1.2. SPECIFICATIONS
Function Overview Preview, Recording, Playback, Network, Locating
System OS Linux 3.0.8
Control Mode Easy Check, Network, CP4, Mouse (3G/4G/WiFi)
Video
Input 4 Channels WD1 + 1 Channel 720P
Output 1 Channel
Total Resource 4x25 FPS WD1@PAL, 4x30 FPS WD1@NTSC, 30FPS 720P
Video Signal Standard Electrical Level: 1Vpp Impedance: 75Ω NTSC/PAL Optional
Audio
Input 5 Channels (1 Channel IPC Audio Input)
Output 1 Channel
Audio Signal Standard Electrical Level: 2Vpp Input Impedance: 4.7kΩ
Display
Display Split 1/4
OSD GPS Information, Alarm, Vehicle No., Speed, Date/Time
Operation Interface Semi-transparent GUI
Recording
Video/Audio Compression Video: H.264
Audio: ADPCM, G.711A , G.711U
Image Resolution
Analog PAL: WD1(928X576), WHD1(928X288), WCIF(464X288),
D1(704X576), HD1(704x288), CIF(352x288);
Analog NTSC: WD1(928X480), WHD1(928X240),
WCIF(464X240), D1(704x480), HD1(704x240), CIF(352x240);
Digital:720P(1280X720)
Image Quality 1-8 Levels Adjustable (1 is best)
Recording Mode Boot up, Manual, Schedule, Alarm
Pre-recording 0-60 Minutes
Post-recording 0-30 Minutes
Playback Playback Channel 1 Channel by Local Playback
Search Mode Date/Time, Channel, Event
Network
3G/4G EVDO/WCDMA/TDD-LTE/FDD-LTE
WiFi 802.11b/g/n
Network connection WiFi/3G/4G Optional
IPC Ethernet 6-pin M12 (10/100M x 1, PON Power Supply)
Locating GPS Location Tracking, Speed Detection and Time Sync
Storage Hard Disk 2.5" SATA Hard Disk x 1
Interface
USB USB 2.0 x 1
SIM SIM Slot x 1
RS232 RS232 x 1 3pin
Sensor 8 Inputs, 2 Outputs
Speed 1 Channel Pulse Speed Detection
Control panel CP4 Optional
Intercommunication 1 Mic Interface
Power
Input DC8-36V, Ignition Signal
Output 5V @1A
Max Power Consumption 32W
Standby Power Consumption ≈0W
Physical Characteristic Dimension (L × W × H) (mm) 206.0 x 170.0 x 70.4
Weight (with hard disk) 1.24Kg
Environment Operating Temperature -40C to +70C (With Heater) or -10C to +70C
Operating Relative Humidity 8% - 90% (No Condense)
8
1.3. SYSTEM DIAGRAM
1.4. EXTERNAL INTERFACE
Dimensions shown in mm
9
Dimensions shown in mm
10
FRONT PANEL
Serial No. Description
1 Hard Disk Module
2 Lock
3 Status LED
4 USB Interface
REAR PANEL
Serial No. Print Description
1 Power DC 8-36 V Power Input
2 Sensor & Serial Serial Port and Switch
3 A/V IN1~4 Audio & Video Input 1-4
4 A/V OUT Audio & Video Output
5 IPC PON Power Supply
6 GPS Antenna Interface
7 3G/4G/WiFi Antenna Interface
