English

A. Hardware connection:

1. Guide to components

2. Turn on the projector

3. Check the information on the splash

screen

Check Projector ID, Projector Name (SSID),

Server IP and WEP on the splash screen. The

Server IP will be assigned by the network

with DHCP enabled. Ask your supervisor for

the wireless connection WEP key when WEP is

enabled.

4. Connect to network

a Switch on your system, and activate your

wireless LAN.

b Scan for avaliable WLAN APs using your

preferred WLAN manager.

c Select and connect to the access point labeled

AcerProjector, or AcerProjectorXXXX.

d Connect the projector to your LAN for a wired

connection.

B. Software installation:

1. The software is stored on the Acer

Projector Gateway.

Please follow the steps below to

download and install:

a Open the internet browser.

b You will automatically be taken to the

welcome page.

c Enter the Server IP address into your browser’s

address bar if you do not see the welcome

page.

1 Mini USB

2 LAN port

3 USB Type A

Projector ID: 7362

Projector Name (SSID) : AcerProjector 001

Server IP : 192.168.100.10

WEP Key : None

321

English

d Click on Download Acer eProjection

Management on the welcome page.

e Click on Run to download and install the

software.

f Click on Next to launch the Welcome to the

Acer Projector Gateway Setup Wizard.

Note: Make sure your personal

firewall doesn’t block the Acer

eProjection Management

application.

2. You can also insert the optional Acer

Plug-and-Show (PnS) token

featuring the windows autorun

function into the USB port on your

system.

Note: Acer PnS token is the

optional accessory.

C. Launch the software

Once the installation is complete or

Acer PnS token is inserted into the USB

port on your system, Acer eProjection

Management will open.

Enter the Projector ID (if needed) and

Username to log in to your Acer

Projector.

Once your’re connected, the PC screen

will be projected.

Note: For more information, please

refer to the online manual. All the

illustrations in this quick guide are

for reference only.
