Aspire Notebook Series

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire Notebook Series Quick Guide

Original Issue: 05/2011

Acer recommends...

Productivity Software

Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects

with Office 2010.

Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,

YouTube or Windows Live.

Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more

informed decisions.

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your

computer.

The Aspire User’s Manual contains useful information applying to your

new computer. It covers basic topics such as using the keyboard and

audio, etc.

The Quick Guide introduces you to the basic features and functions of

your new computer. For more on how your computer can help you to be

more productive, please refer to the Aspire User’s Manual. This guide

contains detailed information on such subjects as system utilities, data

recovery, expansion options and troubleshooting. In addition it contains

warranty information and the general regulations and safety notices for

your notebook. It is available from your computer desktop; simply double-

click the Acer User’s Manual icon.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us

show you around your new Acer notebook.

Top view

#Icon Item Description

1Integrated

webcam

Web camera for video communication

(only for certain models).

English

2 Display screen

Also called Liquid-Crystal Display (LCD),

displays computer output (Configuration

may vary by models).

3Power button /

indicator

Turns the computer on and off. Indicates

the computer's power status.

4 Keyboard For entering data into your computer.

5Touchpad

Touch-sensitive pointing device which

functions like a computer mouse.

HDD indicator Indicates when the hard disk drive is

active.

Communication

indicator

Indicates the computer’s wireless

connectivity device status.

Power indicator Indicates the computer's power status.

Battery indicator

Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

7Click buttons (left

and right)

The left and right buttons function like the

left and right mouse buttons.

8 Speakers Deliver stereo audio output.

9 Microphone Internal microphone for sound recording.

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of

the computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the

other key in the hotkey combination.

Hotkey Icon Function Description

<Fn> +

<F3>Communication Enables/disables the computer’s

communication devices.

<Fn> +

<F4>Sleep Puts the computer in Sleep mode.

<Fn> +

<F5>Display toggle

Switches display output between

the display screen, external monitor

(if connected) and both.

<Fn> +

<F6>Screen blank

Turns the display screen backlight

off to save power. Press any key to

return.

<Fn> +

<F7>

Touchpad

toggle

Turns the internal touchpad on and

off.

<Fn> +

<F8>Speaker toggle Turns the speakers on and off.

<Fn> +

<> Brightness up Increases the screen brightness.

<Fn> +

Brightness

down Decreases the screen brightness.

<Fn> +

<> Volume up Increases the sound volume.

<Fn> +

<> Volume down Decreases the sound volume.

English

Closed front view

<Fn> +

<Home>Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>Stop Stop playing the selected media

file.

<Fn> +

<Pg Dn>Previous Return to the previous media file.

<Fn> +

<End>Next Jump to the next media file.

#Icon Item Description

1Multi-in-1 card

reader

Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory Stick

PRO (MS PRO), xD-Picture Card (xD).

Note: Push to remove/install the card.

Only one card can operate at any given

time.

Hotkey Icon Function Description

English

Left view

HDD indicator Indicates when the hard disk drive is

active.

Communication

indicator

Indicates the computer’s wireless

connectivity device status.

Power indicator Indicates the computer's power status.

Battery indicator

Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-

based network.

3External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

4HDMIport Supports high-definition digital video

connections.

#Icon Item Description

23145
