Aaeon AMB-2003 Series User manual

AMB-2003 Series

Modular System Industrial Panel PCs

Version 2.2for SBC-658

Industrial Panel PCs

Industrial Panel PCs for Industrial Automation

User’s Manual

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Do not use

liquid or spray detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or

letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place

anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire or electrical

shock.

13. Never open the equipment. For safety reasons, only qualified service

personnel should open the equipment.

14. If any of the following situations arises, get the equipment checked by

service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work

according to the users manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS

BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY DAMAGE

THE EQUIPMENT.

Caution:

Dangerofexplosionifbattery is incorrectlyreplaced.Replace only withthesame or equivalenttype

recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s

instructions.

FCC Safety

This device complies with Part 15 FCC Rules. Operation is subject to the

following two conditions: (1) this device may not

cause harmful interference, and (2) this device must

accept any interference received including

interference that may cause undesired operation.

Contents

Chapter1 General Information.........................................5

1.1 Introduction.................................................... 6

1.2 Specifications ..................................................7

General ................................................................................7

Environmental......................................................................7

Power Supply Selection Table.............................................7

Features ...............................................................................8

Specifications ......................................................................9

1.3 Touchscreen (Optional)..................................9

1.4 LCD Specifications....................................... 10

1.5 Dimensions.................................................... 11

1.6 Panel Mounting............................................. 12

1.7 Packing List .................................................. 13

Chapter2 Installation.......................................................14

Chapter3Award BIOS Setup..........................................51

Chapter1 General Information

1.1 Introduction.....................................................6

1.2 Specifications...................................................7

1.3 Touchscreen (Optional) ..................................9

1.4 LCD Specifications........................................10

1.5 Dimensions.....................................................11

1.6 Panel Mounting.............................................12

1.7 Packing List...................................................13

1.1 Introduction

The AMB-2003 series modular system panel PCs, is the PC-base

industrial computer thatspecially designed to keep normal operation under

harsh environment, which meet the entire requirement as an industrial man

machine interface (MMI).

They provide a complete hard ware application and construct a high

quality plastic front panel which meets the toughest industrial and

environmental protection standards

It is afull-function PC-base system with a 10.4” VGA (640 x 480) color

TFT hi-brightness, long-life time LCD display, and compact with different

control modules via a 50-pin cable. The compact dimensions are ideal for

automation applications when the installation space is critical.

These PCs are characterized by their space saving, there are two free slots

for PCI/ ISA. AMB-2003 is heavy-duty steel chassis with a sealed plastic

front panel meets the toughest industrial and environmental standards. All

the controls and connectors are placed on the rear panel; you can connect

the panel PCs to other devices via them.

1.2 Specifications

General

nConstruction:Heavy-duty aluminum chassis & plastic or

aluminum front panel

nDisk drive housing:

a 3.5" HDD ora 2.5”HDD, Slim CD-ROM

& Slim FDD.

nDimensions(AMB-2003): 330(W) x 252(H) x 128mm(D)

nGross Weight: 9.6Kg

Environmental

nOperating temperature:0° to 50°

nStorage temperature: -20° to 60°

nRelative humidity: 5 to 95%, non-condensing

nAltitude: 10,000 ft. (3000 meters)

nVibration:

5 to 17Hz, 0.1" double-amplitude displacement

17 to 500 Hz, 1.5G peak to peak

nShock: 10G-peak acceleration (11-msec. duration)

nEMI: FCC/CE Class A

Power Supply Selection Table

Mode Input voltage

Universal/70W 85-270VAC

24VDC/70W 10-30VDC

Features

AMB-2003 (10.4”LCD + ACS-2303 Control Box)

n10.4” VGA color TFT LCD display

nPlastic front panel and heavy-duty steel chassis

nSupports Socket 370 CPU up to Pentium III

850MHz

nDisk Drive Space for CD-ROM, FDD and HDD

nSupports DiskOnChip and DiskOnModule

nTwo free expansion slotsfor ISA or PCI

nResistive touchscreen (optional)

nRotatable mounting mechanism (optional)

***Expansion IDE port will not functional when both HDD & CD-ROM

install in the machine

Specifications

AMB-2003 (10.4”LCD + ACS2303 Control Box)

nConstruction: Heavy-duty steel chassis &

plastic front panel.

nCPU: Up to Intel Celeron/ P III 850MHz

nMemory: Supports up to 128MB

nDisplay: 10.4”VGA (640 x 480) TFT color LCD

nLCD/CRT controller:

NS Cx5530 Chipset

UMA supports up to 2.5MB display memory

nNetwork (LAN):

Intel 8139B 10/100 Base-T Ethernet controller

nI/O ports:

COM1: RS-232

COM2: RS-232 or RS-422/485(jumper select)

1 parallel port (support ECP/EPP)

1 PS/2 keyboard interface

1 PS/2 mouse interface

nDisk Drive Housing:

3.5”HDD or

2.5”HDD and Slim FDD or

2.5”HDD and Slim CD-ROM

nUSB connector: Dual USB ports

nMounting: Panel mount, Handle mount

nPower supply: Universal 70W switching power

supply

nOS support: MS DOS, Windows 98/SE,

Windows NT4.0, Windows 2000.

1.3 Touchscreen (Optional)

lType: 8-wire, analog resistive

lResolution: 1024 x 1024

lLight transmission: 76%±2

lController: RS-232 interface

1.4 LCD Specifications

Model AMB-2003

Display type TFT color LCD

Size (diagonal) 10.4”

Number of Pixels 640(W) x 480(H)

Dot size

(mm x mm) 0.33(W) x 0.33

View angle (Horizontal) 80°

View angle (Vertical)45°

Luminance (cd/m2)250 (TYP)

Operating Temperature 0 ~ 45 °C

Backlight Life-time (Hrs) 30,000
